- Page 1 Installation & Operations Manual Emergency Call Box 2100-986CDMA Series N56 W24720 N. Corporate Circle Sussex, WI 53089 RP8500986CDMA 866-850-8854 262-246-4828 (fax) Ver. 1 Made in the USA www.rathsecurity.com 2 Year Warranty 05/14...
- Page 2 Welcome to Rath Security Thank you for purchasing Rath’s Emergency Call Box. We have been manufacturing phones for over 35 years and are the largest Emergency Phone manufacturer in North America. We take great pride in our products, service, and support. Our Emergency Phones and Towers are of the highest quality.
- Page 3 See Drawing on Page 3. 6. Run the phone line to the Call Box. Connect a modular jack to phone cable and plug the Rath supplied modular cable into the jack. Or, connect a modular RJ11 plug onto the phone cable and attach directly to the RJ11 jack on the SmartPhone.
- Page 4 Call Box Installation – Without Optional Strobe L N G 12V to CDMA Line Cord to CDMA White Wire, Neutral Black Wire, Hot 110V Connection pg. 3 www.rathsecurity.com...
- Page 5 Call Box Installation – With Optional Strobe Strobe 12V to CDMA L N G Line Cord to CDMA White Wire, Neutral Black Wire, Hot 110V Connection pg. 4 www.rathsecurity.com...
-
Page 6: Programming The Phone
Programming the Phone: 1. You can program the phone on-site or remotely. 2. If programming on-site, open back access panel located directly behind front stainless steel face plate. Use the #10 spanner bit provided to remove the 6 security screws. 3. -
Page 7: Adjusting The Volume
Reinstall the cover on the NEMA enclosure and secure the rear access panel. Suggested Ongoing Testing of the Phone: Rath recommends that the Emergency Call Station be tested and maintained on a monthly basis to ensure proper operation. For testing, follow the procedure outlined in “Testing of the Phone”. -
Page 8: Troubleshooting
Troubleshooting: Problem Possible Cause & Fixes No dial tone when the • Check to make sure the phone line is connected. button is pushed: • Verify dial-tone and voltage on phone line going into unit. Audio is low from the •...
