Summary of Contents for Soundtronics M2SYNTH 102

  • Page 1 SOUNDTRONICS M²SYNTH User Manual 102 102 Chord VCO...
  • Page 2 102 Chord VCO  Soundtronics Ltd Unit 29 Webb Ellis Business Park Woodside Park Rugby Warwickshire CV21 2NP www.m2synth.com www.soundtronics.co.uk...
  • Page 3 T able of Contents Overview ................2 Features ................3 Panel Controls ..............4 Basic Operation ..............5...
  • Page 4 Chapter Overview The 102 Chord VCO is one of the many modules from the Soundtronics modular analogue synth – the M²Synth. While most modules require very little introduction, the 102 Chord VCO has features that users may be less familiar with.
  • Page 5 Chapter Features Main features and specifications of the 102 Chord VCO. Size  Height 5U (222.25mm)  Width 2U (88.9mm)  Depth 45mm behind panel Electrical  Supply voltage +/-12V  Supply current J9 +26/-30mA, J10 +64/-36mA (Total +90/-66mA) Panel Features ...
  • Page 6 Chapter Panel Controls Coarse Frequency Control Fine Frequency Control Auto-Tune Button External Pulse PWM Level LED Status, peak brightness indicates optimum frequency for Press to adjust step quantizing auxiliary voltage Chord Selection De-tune VCOs from each other Start / stop sequencer 2 VCOs in chord only or all Paraphonic Output Level Waveform selection...
  • Page 7 Chapter Basic Operation The Chord VCO 102 is similar to the VCO 101 and VCO 105 except that this VCO contains 4 individual VCOs that are controlled in such a way as to produce preset chords. As with any analogue VCO, they are not precise unlike their digital equivalents but this is often viewed as an advantage.
  • Page 8 {3,7,9}, Minor 6th {4,8,10}, 7th Sharp 5th {4,6,10}, 7th Flat 5th {3,7,11}, Major 7th Flat {5,7,10}, Dominant 7th Suspended 4th {3,6,9}, C Diminished 7 {7,12,0}, C5 Power chord The numbers in the {} indicate the number of semitones above the root note the second, third and fourth VCO frequencies are set.
