- Page 1 USER'S MANUAL Upright Bike KH63...
- Page 2 CONTENTS Considerations Tools and accessories explosive view and part list ···························· 3/4 Installation steps Direction For Use Maintenance and troubleshooting...
- Page 3 To ensure your safe, reliable and comfortable use of this series of exercise bikes, please read the following important matters and all operation instructions before use. The company shall not be liable for any personal injury or property loss caused by the use of this product. Consult your doctor before starting a plan or other exercise program.
- Page 4 Tools and accessories...
- Page 5 Explosive View...
- Page 6 Part list Descripti Descripti Rear foot tube Square cap Front foot-cover ARC washer Rear foot cover Pull ROD Main frame adjusting rod Front foot tube Adjust slice Flat Washer Ф6 Front cover Spring washer Ф6 Handlebar support Hand bar Nut M6 Ф25Ball plug Cap nut M8 Foam grip...
- Page 7 Spring knob Pedal belt Bearing set Screwdriver S=5 Pressing wheel bracket Multiple wrenches Pressing belt wheel Wrench 4V Belt Flywheel 8-section tension control resistance cable Pedal(Left & Right) Handbar cover Spacer T knob Crank Decorative Cover Hole plug shot knob Seat cushion adjustable bracket...
- Page 8 Installation steps 2.With 2 sets M8×75 bolts（56）、Ф8 spring washer（42）、Ф8 flat washer （59）、M8 cap washer（49）attach front foot tube（5）on main frame（4 ）。 3.With 2 sets M8×75 bolts（56）、Ф8 spring washer（42）、 Ф8 flat washer（59）、 M8 cap washer（49）attach rear foot tube on main frame（4）。 A. Connect the connector (16) and (17) of the upper and lower sections of the electronic table connection, and then connect the terminal terminal of the lower end of the eight-section spinner body (31) firmly with the output fine-tuning connection (32).
- Page 9 a. Insert the heart rate line (12) through the side hole on the handlebar welding part (7) and through the upper end; Then cover the heart rate line (18) with the threading hole plug (38), plug the hole on the welding joint (7), and then cover the hand handle pipe (8) in the clamping tube hoop on the welding joint (7), as shown in the figure, then cover the overhand handle decorative sleeve (34) and the spacer sleeve (35), and lock it with the hand-wheel (36).
- Page 10 on the seat cushion welding piece (15); Then insert the stretch hand (25) into the hole and tighten the handwheel. (See Figure 6) Put the seat cushion adjusting frame (40) on the upper （2） end of the seat cushion adjusting frame (15) according to the direction shown in the figure.
- Page 11 METER ： 1 、 functionality, 2 、 1. Speed: Display in window A. The measurement is instantaneous speed, reflecting the speed of running, and the measurement range is 0.0 to 99.9 km/h. (or Max. 1500 RPM). 3 、 Time: window display.
- Page 12 12: There are key sounds when operating MODE key, SET setti ng key or RESET RESET key. Stand still for 8 minutes (no operation, no movement), the meter will be automatically shut down and reset all data, and the treadmill will be displayed automatically by pressing the button or starting the treadmill. 6.
- Page 13 MALFUNCTIONS AND TREATMENT (1) Maintenance 1. Regularly check whether the bolts and nuts of each part are fastened, whether the adjusting knob is locked, whether the rotating part is flexible, and whether there are any worn or damaged parts. Ensure that all parts are in good condition to ensure the safety of the equipment.
- Page 14 Change the bearing set. ■ Running belt is slippery. ■ The bearing set is damaged.
