B A B - 4 3 0 / 4 3 1 / 4 3 3 / 4 3 4

Universal Graphic Module and

Display Adapters

Hardware Manual

Revision 1 A

Table of Contents

Need help?

Do you have a question about the BAB-430 and is the answer not in the manual?

Questions and answers

Summary of Contents for ELTEC BAB-430

Page 1 elektronik mainz B A B - 4 3 0 / 4 3 1 / 4 3 3 / 4 3 4 Universal Graphic Module and Display Adapters Hardware Manual Revision 1 A...
Page 2 ELTEC reserves the right to make changes to any products to improve reliability, function or design. ELTEC does not assume any liability arising out of the application or use of any product or circuit described in this manual;...
Page 3: Table Of Contents
1.3.6.1 Connectors on BAB-430 ........
Page 4 A.2 BAB-433/434............. . 41 A.3 Adaption of the BAB-430/433/434 to new Displays ......47 A.4 Calculating of Contrast Voltage Range .
Page 5: List Of Tables
BAB-430 Supported Display Types ........
Page 6 Figure 3: Location of Jumpers and Connectors (BAB-433/434) ......17 Figure 4: Location of Switch S201 and Connectors on BAB-430 ......18...
Page 7: Scope Of Delivery
V-BAB.-A434 Universal display adapter for 5 V displays with CMOS level The last letter of the order numbers refers to the hardware revision and is subject to changes. Please contact ELTEC for information about valid order numbers. Example: V-E16.-B105 Revision number, subject to change!
Page 8: Options
Options / Related Products BAB-430/431/433/434 Options Description: Order No.: None Related Products Description: Order No.: Documentation: Hardware Manual for BAB-430/431/433/434 V-BAB.-A439 Hardware Manual BAB-40/60 V-BAB.-A490 Service Manual BAB-40/60 V-BAB.-A491 Additional Documentation: 65548 Data Sheet Phoenix MultiKey/42 Technical Reference Hardware: Basic Automation Board BAB-40 V-BAB.-A400...
Page 9: Conventions
BAB-430/431/433/434 Conventions Conventions If not otherwise specified, addresses are written in hexadecimal notation and identified by a leading dollar sign ("$"). Signal names preceded by a slash ("/"), indicate that this signal is either active low or that this signal becomes active with the trailing edge.
Page 10: How To Use This Manual
How to Use this Manual BAB-430/431/433/434 How to Use this Manual Document Structure This manual is divided into the following chapters: Chapter 1 Specification contains a list of distinguishing features, a block diagram with a general description, a description of the main building blocks and the board parameters.
Page 11: Specification
BAB-430/431/433/434 1 Specification 1 Specification 1.1 Main Features BAB-430: •Flatpanel resolution 800 x 600 and 640 x 480 pixels •Video resolution 640 x 480, 800 x 600, or 1024 x 768 with 70 Hz frame rate •16 or 256 colors out of...
Page 12 BAB-430/431/433/434 •DC/DC converter for variable contrast voltage -30 V to -20 V or +20 V to +30 V without additional power supply •Contrast voltage adjustable via DAC on BAB-430 •Power switching for display and inverter •Support for 3.3 V displays •Support for 5 V displays with TTL level input (i.e.
Page 13: General Description
Flatpanel Adapter 40-pin The BAB-430 is graphic module for the BAB-40/60 CPU boards. It features the connection of video monitors and flatpanel displays. The BAB-431/433/434 flatpanel display adapter has to be mounted on top of the BAB-430. The display adapter enables the flatpanel mode simultaneous to the video mode.
Page 14: Technical Details
BGB offers a memory bandwidth of about 9 MB per second. To improve graphic performance the BitBLT engine of the 65548 can be used. Since the 65548 has direct access to the DRAM the BAB-430 offers then a better overall performance than the BAB-410 graphic module.
Page 15: Dac For Contrast Control
BAB-430/431/433/434 1 Specification 1.3.4 DAC for The BAB-430 offers a 8-bit DAC that is intended for contrast control of Contrast dualscan displays. By writing $00 to $FF into the DAC the output voltage Control changes linear from 0 V to about 3.2 V. The DAC is write-only.
Page 16: Table 2: Flatpanel Connector X202 (And X101 On Bab-431/3/4)
1 Specification BAB-430/431/433/434 X202 is used to connect to a flatpanel display via the appropriate display adapter (e.g. BAB-431/433/434). Table 2: Flatpanel Connector X202 (and X101 on BAB-431/3/4) Name Description +5V to supply display adapter +5V to supply display adapter...
Page 17: Table 3: Keyboard Connector X301
BAB-430/431/433/434 1 Specification X301 is a mini-DIN connector used to connect a PS/2 keyboard to the BAB-430. Table 3: Keyboard Connector X301 Name Description KBDATA Keyboard data reserved Ground KBVCC Keyboard supply voltage KBCLK Keyboard clock 6-pin mini-DIN reserved female connector...
Page 18: Connectors On Bab-431
1 Specification BAB-430/431/433/434 1.3.6.2 Connectors on X101 of the BAB-431 has the same layout as X202 of the BAB-430. BAB-431 X102 is intended to connect to a 800 x 600 dualscan color display (SHARP LM80C20PX). Table 4: 800 x 600 Dualscan Color Display Connector X102...
Page 19: Table 5: 800 X 600 Tft Color Display Connector X103
BAB-430/431/433/434 1 Specification X103 is intended to connect to a 800 x 600 TFT color display (SHARP LQ11DS01). Table 5: 800 x 600 TFT Color Display Connector X103 Name Description Data Input Clock Ground Ground HSYNC Horizontal Synchronous Signal VSYNC...
Page 20: Connectors On Bab-433/434
1 Specification BAB-430/431/433/434 X104 is used to connect either a SHARP AA605 inverter to pin 1-5 or a TDK CXA-K10L-FS inverter to pin 6-10. P101 (100K) can be used to adjust the brightness of the CFL. Table 6: Inverter Supply Connector X104...
Page 21: Table 8: Universal Display Connector X201
BAB-430/431/433/434 1 Specification Table 8: Universal Display Connector X201 Name Description P(23) Data Bit 23 P(22) Data Bit 22 P(15) Data Bit 15 P(14) Data Bit 14 n.c. Ground P(6) Data Bit 6 n.c. TPVEE_I Panel Vee In (used if external supply necessary)
Page 22: Definition Of Board Parameters
CRT Display •Up to 1024 x 768 resolution with 4 or 8 bit per pixel •Up to 80 MHz dotclock •16 or 256 out of 256K colors 1.4.2 Flatpanel Table 9: BAB-430 Supported Display Types Display Manufac- Name Type Resolu-...
Page 23: Mtbf Values
BAB-430/431/433/434 1 Specification 1.4.3 MTBF Values •BAB-430: 38 056 h (computed after MTL HDBK-217E) 509 950 h (realistic value from industry standard experience) •BAB-431: 637 294 h (computed after MTL HDBK-217E) - 8 539 740 h (realistic value from industry standard experience) •BAB-433/434:...
Page 24 1 Specification BAB-430/431/433/434 Hardware Manual...
Page 25: Installation
BAB-430/431/433/434 2 Installation 2 Installation 2.1 Introduction •Carefully remove the board from the shipping carton. - Save the original shipping container and packing material for storing or reshipping the board. Avoid touching integrated circuits except in an electrostatic free environment. Electrostatic discharge can damage circuits or shorten their lifetime.
Page 26: Figure 2: Installation Diagram
2 Installation BAB-430/431/433/434 Figure 2: Installation Diagram 3..0 BAB-430 BAB-431/433 E128 Compatible Dualscan Inverter ELTEC Hardware Manual...
Page 27: Figure 3: Location Of Jumpers And Connectors (Bab-433/434)
BAB-430/431/433/434 2 Installation Figure 3: Location of Jumpers and Connectors (BAB-433/434) Hardware Manual...
Page 28: Figure 4: Location Of Switch S201 And Connectors On Bab-430
2 Installation BAB-430/431/433/434 Figure 4: Location of Switch S201 and Connectors on BAB-430 Hardware Manual...
Page 29: Installation Crt Display
1. Set all switches S301 to off. 2. Set S902 on the BAB-40/60 to "0". 3. Remove bolts from X201 of BAB-430. 4. Plug the BAB-430 into BGB connector of the BAB-40/60. 5. Mount bolts for X201 of BAB-430. 6. Plug BAB-40/60 into the rack.
Page 30: Installation Flatpanel Display
7. Plug the BAB-430 into BGB connector of the BAB-40/60. 8. Mount bolts for X201 of BAB-430. 9. Plug display adapter into X202 of the BAB-430 and the BEB of the BAB-40/60. 10. Mount screws M2.5x4 so that the BAB-430 and the display adapter are fixed together.
Page 31: Interface Cable
BAB-430/431/433/434 2 Installation 2.4 Interface Cable When ordinary flat cable is used the distance between the BAB-431/433/ 434 and the display should not exceed 0.6 m. Especially with TFT displays cable length is critical. With cable where every signal is shielded and terminated at the display side cable length may be extended up to some meters.
Page 32: Table 10: Interface Cable Connections
2 Installation BAB-430/431/433/434 Table 10: Interface Cable Connections HITACHI TOSHIBA TLX-8062S-C3; HITACHI LMG5278XUFC-00T, X201 ORION LMG9460XUCC LMG7550XUFC; OEM-6448C-2, OEM-64C30-1 ORION OEM-6448 Name Name Conn./Pin Name Name P(23) P(22) P(15) CN2/2 P(14) CN2/3 n.c. 27, 30 CN2/1 P(6) CN2/7 n.c. TPVEE_I...
Page 33: Jumpers And Switches
BAB-430/431/433/434 2 Installation 2.5 Jumpers and Switches 2.5.1 Jumpers J101 is used to select whether the flatpanel display operates with 5 V or (BAB-433 only) 3.3 V supply. Table 11: Display Voltage Select J101 Jumper J101 Function 1 - 2...
Page 34: Display Type Switch
2 Installation BAB-430/431/433/434 J202 is used to select the source of the contrast voltage for a dualscan flatpanel display. Table 14: Contrast Voltage Source Select J202 Jumper J202 Function open Contrast Voltage supplied externally at TPVEE_I Contrast Voltage supplied by internal DC/DC converter Contrast Voltage directly from DAC 2.5.3...
Page 35: Recommended Setup
BAB-430/431/433/434 2 Installation 2.5.4 Recommended Table 16: Recommended Setup for Various Displays Setup Display J201 J202 S201 RMon Screen Resolution SHARP LM80C20P 800 x 600 36kHz 58Hz SHARP LM80C20PX SHARP LQ11DS01 800 x 600 36kHz 58Hz HITACHI LMG5278XUFC-00T 640 x 480 31kHz 60Hz...
Page 36 2 Installation BAB-430/431/433/434 Hardware Manual...
Page 37: Programmers Reference
BAB-430/431/433/434 3 Programmers Reference 3 Programmers Reference 3.1 Address Map Table 17: BAB-430 Address Map Address Name Description Access ** $0410.0000-$041F.FFFF* 1 MByte Frame Buffer B/W/L r/w $FEC6.0060 KBDATA Keyboard Data B r/w $FEC6.0064 KBCSR Keyboard Control/Status B r/w $FEC6.03B4-$FEC6.03C2*...
Page 38: Version Registers
3 Programmers Reference BAB-430/431/433/434 3.2 Version Registers The version registers LSVER and MSVER can be used to identify the BAB-430 graphic module. Table 18: Version Registers LSVER and MSVER (read only) LSVER at $FEC6.2000 MSVER at $FEC6.2004 Version BAB-410 BAB-411...
Page 39: Keyboard Interrupt Enable
BAB-430/431/433/434 3 Programmers Reference 3.4 Keyboard Interrupt Enable The keyboard controller 82C42 has two interrupt outputs named IRQ1 (pin 11) and IRQ12 (pin 13). Interrupts from these two outputs can be enabled separately via the keyboard interrupt register KBINT at $FEC6.2060.
Page 40 3 Programmers Reference BAB-430/431/433/434 Hardware Manual...
Page 41: Appendix
BAB-430/431/433/434 Appendix Appendix Hardware Manual...
Page 42: Bab-430
A.1 BAB-430 BAB-430/431/433/434 A.1 BAB-430 Table A.1: Parts List BAB.-A430.0 Part No. Count Part Type Case Socket Comment C100..112 C,C,100NF-0805 C0805B C115..116 C,C,22PF-2R C1206B Q101 XTAL,14.318-MINI XTAL R101 R,150-SMD R1206B R102 R,1K-SMD R1206B R103 R,470-SMD R1206B R104 R,1M-SMD R1206B R105...
Page 43 BAB-430/431/433/434 A.1 BAB-430 Table A.1: Parts List BAB.-A430.0 (Continued) Part No. Count Part Type Case Socket Comment R207..208 R,22-0805 R0805B R209 R,270-SMD-1% R1206B R210 PTC425 PTC425 R211..212 R,10-SMD R1206B RN201..202 RN,4X33-743 8R743B RN203 RN,4X4K7-743 8R743B S201 S,4-POS-MDIL-SMD 8SOMSWB U201 65548VLB 208PQV U202..203...
Page 44 A.1 BAB-430 BAB-430/431/433/434 Hardware Manual...
Page 45 BAB-430/431/433/434 A.1 BAB-430 Hardware Manual...
Page 46 A.1 BAB-430 BAB-430/431/433/434 Hardware Manual...
Page 47 BAB-430/431/433/434 A.1 BAB-430 Hardware Manual...
Page 48 A.1 BAB-430 BAB-430/431/433/434 Hardware Manual...
Page 49 BAB-430/431/433/434 A.1 BAB-430 Hardware Manual...
Page 50 A.1 BAB-430 BAB-430/431/433/434 Hardware Manual...
Page 51: Bab-433/434
BAB-430/431/433/434 A.2 BAB-433/434 A.2 BAB-433/434 Table A.2: Parts List BAB.-A433.0/434.0 Part No. Count Part Type Case Socket Comment C101..106 C,C,100NF-2R C1206 C110..139 C,C,22PF-2R C1206 J101..102 J,1X3 1X3J J101 not used on BAB-434 P101 R,100K-TRIM TRIM,100K-ST R101..102 PTC425 PTC425 R103..106 R,10K-SMD R1206 RN101..108...
Page 52 A.2 BAB-433/434 BAB-430/431/433/434 Table A.2: Parts List BAB.-A433.0/434.0 (Continued) Part No. Count Part Type Case Socket Comment R210 R,1K5 2RES4 U201 LT1172CN8 8DIP3 U202 TLP595G 6DIP3 X201 X,PFLEST-40 40PLST Hardware Manual...
Page 53 BAB-430/431/433/434 A.2 BAB-433/434 Hardware Manual...
Page 54 A.2 BAB-433/434 BAB-430/431/433/434 Hardware Manual...
Page 55 BAB-430/431/433/434 A.2 BAB-433/434 Hardware Manual...
Page 56 A.2 BAB-433/434 BAB-430/431/433/434 Hardware Manual...
Page 57: Adaption Of The Bab-430/433/434 To New Displays
For initialization of a particular display RMon uses a table that is located at offset $1A00 + (n-1)*$50 in the RMon firmware EPROM. Where n is the position of S201 on the BAB-430. This table contains the numbers and values for all extension registers of the 65548 that are different from CRT setup.
Page 58 12. Modify the table at the desired offset ($1E60 is recommended for user-defined displays, which belongs to position 15 of S201 on the Bab-430) with the values you found in steps 4 to 10. 13. Program new EPROM and mount it on the BAB-40/60.
Page 59: Calculating Of Contrast Voltage Range
BAB-430/431/433/434 A.4 Calculating of Contrast Voltage Range A.4 Calculating of Contrast Voltage Range The following C program calculates the neccessary values of R202 and R204 of the contrast voltage DC/DC converter on the BAB-433 from the desired output voltages. #include <stdio.h>...
Page 60: Index
A.5 Index BAB-430/431/433/434 A.5 Index Numerics 65548 ......1, 4, 11, 47 Address Map ......27 BitBLT .
