Summary of Contents for Aimecor Hello BM-YY01
- Page 1 Video Baby Monitor BM-YY01 User Manual...
- Page 3 Ca talog Safety Instructions ......................Overview ..........................2.1 Components ......................2.2 Product Overview ....................2.3 Menu Options ......................Getting Started ........................3.1 Powering Camera/Baby Unit ................3.2 Wall Mounting Camera/Baby Unit ..............3.3 Charging and Powering the Monitor/Parent Unit ........3.4 Registration ..................
-
Page 5: Safety Instructions
1. Safety Instructions STRANGULATION HAZARD - Children have STRANGLED in cords. Keep this cord out of the reach of children. NEVER PLACE THE CAMERA OR CORD IN OR NEAR CRIB OR PLAYPEN. Secure the cord away from the crib or playpen. CHOKING HAZARD - This product contains small parts which may cause choking. - Page 6 2. Overview 2.1 Components...
- Page 7 2.2 Product Overview...
- Page 8 2.3 Menu Options Overview (Upper Screen Bar) Sta tus Indication Description Options Signal Strength Indicator levels Camera Selected scan Sound Level levels (on/off) Night Vision (on/off) Zoom (OFF/1/2/3/4/ Lullaby Selected (on/off) (on/off) Talk-Back (on/off) Current Camera Unit / 32-122 0-50 Temperature levels or flashing red Battery Power...
-
Page 9: Getting Started
3. Getting Started Camera/Baby 3.1 Powering Unit Connect the Camera Power Adapter to the Camera/Baby Unit. The Power LED light on the Camera/Baby Unit will illuminate green. Position your Camera/Baby Unit away from your baby ’ crib. Ensure the power cord is not within reach of your baby. NOTE Only use the Camera Power adapter provided. - Page 10 Plug the USB Adapter into the electrical outlet. Connect the small end of USB Power Cable to the USB DC Jack of the Monitor/Parent Unit. The Power LED Indicator will illuminate red. Press and hold the POWER button for seconds to turn ON the Monitor/Parent Unit.
- Page 11 3.4 Registration The Camera/Baby Unit is pre-registered to your Monitor/Parent Unit. You don ’ need to register it again unless the Camera/Baby Unit loses its link with the Monitor/Parent Unit. To re-register your Camera/Baby Unit, or new Camera/Baby Unit, follow the procedure below: register MENU button of the Monitor/Parent Unit and the menu Press the...
-
Page 12: Using The Baby Monitor
4. Using the Baby Monitor 4.1 Set UP Place the Camera/Baby Unit in convenient location (e.g. on table or shelf) and point the camera toward the area you want to monitor. NOTE Do not place the Monitor/Parent Unit within baby ’ reach. - Page 13 4.5 Sleep Mode / Audio Only Mode ( Video OFF with Audio ON ) Short press the button to turn the screen OFF POWER while keeping the audio ON. This mode conserves power. Short press the POWER button to turn screen back on.
- Page 14 Brightness Press the MENU button and the menu bar will pop up. Brightness icon is highlighted. Press the UP button or DOWN button to select the desired brightness level from level 1~5 Alarm Press the MENU button and the menu bar will pop up. Press the LEFT button or RIGHT button until...
- Page 15 Camera Control Delete camera Press the MENU button and the menu bar will pop up. Press the LEFT button or RIGHT button until Cam icon is highlighted, and the Scan/View/Add/Del menu will pop up. Press the UP button or DOWN button to select the Del icon and press the OK button to confirm.
- Page 16 NOTE Camera/Baby Unit can only be registered to one Monitor/Parent Unit at any one time. View camera Press the MENU button and the menu bar will pop up. Press the LEFT button or RIGHT button until Cam icon is highlighted, and the Scan/View/Add/Del menu will pop up. Press the UP button or DOWN button to select the View icon and...
- Page 17 Press the MENU button and the menu bar will pop up. Press the RIGHT button until VOX icon is highlighted. Press the UP button or DOWN button to select ON or OFF. NOTE VOX can not work based on Scan Mode Volume Press the VOLUME+ button or...
-
Page 18: Troubleshooting
6. Troubleshooting Confirm that the Camera/ aby Unit and Monitor/Parent Unit Product does are ON (check Power LED not switch on The battery may be depleted; recharge battery. Confirm that power adapters are properly connected. The Camera/Baby Unit and Monitor/Parent Unit may be too far apart. - Page 19 Night vision LED may be ON. Night vision mode operates Picture in black and white. black Turn on room lights to force monitor out of night vision mode. and white Try moving the Camera/Baby Unit closer to the Monitor Unit. Remove obstructions between the Camera/Baby Unit and The picture Monitor/Parent Unit.
- Page 20 Unit Confirm that the Camera/ aby Unit and Monitor/Parent Unit are paired. If the above troubleshooting guide did not help you solve your problem, please feel free to email us by support@aimecor.com. We will respond all inquiries within 24 hours.
- Page 21 support@aimecor.com...
