Caltta ZXIMCU PT01 P200 Operation Manual

Portable emergency command system
Table of Contents

Advertisement

Quick Links

ZXIMCU PT01 P200 Portable
Emergency Command System
Operation Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZXIMCU PT01 P200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Caltta ZXIMCU PT01 P200

  • Page 1 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual...
  • Page 3 The copyright of this document belongs to Caltta Technologies Co.,Ltd. Text contains proprietary information owned by Caltta Technologies Co.,Ltd., without the written permission of Caltta Technologies Co.,Ltd., any unit or individual shall not use or leak any document and Figures, this document contains tables, Figure, data and other information.
  • Page 4: Table Of Contents

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual INDEX 1 OVERVIEW..............................1 2 ZXIMCU PT01 P200 VERSION 3.0....................... 1 2.1 INTRODUCTION OF ZXIMCU PT01 P200 VERSION 3.0............. 1 2.2 ZXIMCU PT01 P200 CONNECTION OPERATION..............4 3 NETWORK ARCHITECTURE INTRODUCTION................7 4 DISPATCHING PC CONFIGURATION....................8 4.1 IP ADDRESS SETTING........................8...
  • Page 5 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 5.2.2 VIDEO PULL........................32 5.2.3 VIDEO DISTRIBUTION....................34 5.2.4 LOCATION........................37 6 CARD ALLOCATION AND NUMBER ALLOCATION..............39 6.1 HAND-HELD TERMINAL NUMBER ALLOCATION.............. 39 6.1.1 LOGIN TO THE UNIFIED OMM................. 39 6.1.2 USER AUTHENTICATION INFORMATION CONFIGURATION......40 6.1.3 USER NUMBER ALLOCATION..................41...
  • Page 6 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure Index Figure 2- 1 ZXIMCU PT01 P200 MPU....................1 Figure 2- 2 ZXIMCU PT01 P200 RRU.....................2 Figure 2- 3 ZXIMCU PT01 P200 Power Line..................3 Figure 2- 4 ZXIMCU P200 device......................4 Figure 2- 5 Connection between MPU and RRU with the the power line.........
  • Page 7 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 20 Forced release by the dispatcher..................23 Figure 5- 21 Forced insertion by dispatcher..................23 Figure 5- 22 Dynamic regroup........................ 24 Figure 5- 23 Temporary group call......................25 Figure 5- 24 Emergency call........................
  • Page 8 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 6- 13 Input user information......................48 Figure 6- 14 Enter to expert diagnosis mode on the unified OMM interface........49 Figure 6- 15 Add CPE IP Pool and IP Segment..................50 Figure 6- 16 Create CPE Authorization Profile..................
  • Page 9: Overview

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Overview This manual covers introduction and operating instruction of Caltta LTE Emergency Command System, which includes configuration and operation methods for MDS, core network, base station, terminals and peripheral supporting products. Please select the corresponding operation steps according to the actual system and device.
  • Page 10 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 1) Network Interface 1: used for connecting with dispatch console or backhaul device 2) Handle: convenient to carry 3) Network Interface 2: used for connecting with dispatch console or backhaul device 4) Optoelectronic Input Interface: connect with RRU via power line.
  • Page 11 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 1) Power Input Interface: power input and connect with MPU 2) RF Antenna Interface 3) Handle 4) RF Antenna Interface Figure 2- 3 ZXIMCU PT01 P200 Power Line 1) A Connector : Waterproof connector with large size diameter, connect to RRU...
  • Page 12: Zximcu Pt01 P200 Connection Operation

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual ZXIMCU PT01 P200 Connection Operation Step 1: Take out the device as shown below Figure 2- 4 ZXIMCU P200 device Step 2: Connect the A connector of the power line to RRU, connect B connector to...
  • Page 13 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Step 4: Connect GPS Antenna (no need to connect if the device is used as a stand-alone station): Connect one end of the GPS feeder to the GPS antenna interface of MPU, the other end to the GPS antenna...
  • Page 14 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Step 5: Connect the C connector of the power line to the Power Input Interface (100-240V AC, 50/60Hz), then turn on the main power switch of the device. The main power switch is on the side of the RRU.
  • Page 15: Network Architecture Introduction

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Network Architecture Introduction Caltta LTE portable emergency command system is based on All-IP flat network architecture. The system follows B-TrunC Broadband Trunking standard, integrates LTE core network iEPC, professional voice and video trunking network DSS, multimedia dispatching server MDS, base station system and terminals, and provides end-to-end multimedia command and dispatch solution.
  • Page 16: Dispatching Pc Configuration

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual LTE core network iEPC is a common LTE core network device complying to 3GPP standard specification, consists of MME, S/P-GW, and HSS, which is used for providing common LTE services. Trunking core network system DSS is composed of PDS and DAS. PDS provides trunking services for trunking users.
  • Page 17: Ie 11 Browser Setting

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 4- 1 Adding Route IE 11 Browser Setting Login to the OMM system via browser. Support both IE and Chrome browser. If using IE browser, version 11 is required. Before logging in, make sure the PC has been installed with Adobe flash player and the IE settings are correct, otherwise the OMM interface may not open.
  • Page 18: Trunking Services Operations

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Input the OMM server address in the CMD window, which defaults to 192.168.90.129. Figure 4- 3 Trusted site script setting of IE browser Press Enter button after inputting the IP address, the script will set up automatically.
  • Page 19: Dispatch Console Login

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 1 Downloading client and plug-ins of the dispatch console 5.1.2 Dispatch Console Login Double click the DAS dispatch console icon and open the software. The DAS software will pop up the IP selection interface if the fixed IP address changes or for first time login.
  • Page 20 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 3 Login interface of the dispatch console Input the account number and password on the login interface of dispatch console , select Remember Password and click the setting icon...
  • Page 21: Dispatch Console Interface Introduction

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 2. Method 2: Modify the configuration file in the DAS software installation directory. Change the local IP address by modifying the localIP=192.168.13.160 in the "config.ini" file. 5.1.3 Dispatch Console Interface Introduction...
  • Page 22 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 5.1.3.1 Dispatch Console Interface Layout Figure 5- 5 Dispatch console interface layout The dispatch console interface is divided into four areas as shown above, introduction of each (marked with number) is as follows: Area 1: Menu area, with five icons of Dispatch, GIS, Video, History and Setting, ...
  • Page 23 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Select the user / group / dispatch console that needs to be dispatched on the user information list, double click to add the user / group / dispatch console to the dispatching operation area.
  • Page 24 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Sound channel selection: When the dispatch console dispatches users, groups or dispatchers, it supports switching between balance channel model and exclusive main channel model. Right click the user/group/dispatcher and select Sound channel from the shortcut menu.
  • Page 25 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 10 Group call attribute setting Dispatcher call attribute setting: Move cursor to the dispatch console, right click and select Call attribute from the shortcut menu to select the call attribute as required.
  • Page 26 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 12 GIS interface of the dispatch console The dispatch console supports both online and offline maps. Make sure the dispatching PC has been connected to the map server before logging to the dispatch console.
  • Page 27: Dispatch Console Initiates A Half-Duplex Voice Private Call

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 13 Video dispatch interface 5.1.4 Dispatch Console Initiates a Half-duplex Voice Private Call Move cursor to the user on the trunking dispatch interface, right click and select Call attribute from the shortcut menu and and uncheck the "Full duplex" option;.
  • Page 28: Dispatch Console Initiates A Full-Duplex Voice Private Call.20

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 5.1.5 Dispatch Console Initiates a Full-duplex Voice Private Call Move cursor to the user (Call attribute defaults to Full duplex) and click the Call origination icon in the middle, then the dispatch console and corresponding terminal will ring.
  • Page 29: Dispatch Console Initiates A Voice Group Call

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 5.1.7 Dispatch Console Initiates a Voice Group Call Move cursor to a group and click Initiate Call in the middle, the terminals in the group will automatically answer the call and establish a voice group call. By default, the dispatch console has the floor.
  • Page 30: Sending Sms And Mms

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 18 Dispatch console initiates a video group call 5.1.9 Sending SMS and MMS Move cursor to an online user in the user list, right click and select Send Message from the shortcut menu to send SMS and MMS to the terminal.
  • Page 31: Dynamic Regroup

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Select the ongoing call, and click to forcibly release the call. Figure 5- 20 Forced release by the dispatcher Forced Insertion Forced insertion is only applicable to group call. When a terminal initiates a group call...
  • Page 32: Temporary Group Call

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual To remove a dynamic member, click under the corresponding member. Figure 5- 22 Dynamic regroup 5.1.12 Temporary Group Call Different from dynamic regroup, temporary group call is to temporarily create a group.
  • Page 33: Emergency Call

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 23 Temporary group call 5.1.13 Emergency call In case of emergency, you can press the SOS emergency call button on the terminal to send an emergency call to the dispatch console and other terminals in the group.
  • Page 34 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Click Location to locate the terminal user. When the terminal has displayed the positioning status, click Cancel Location to end the positioning. Figure 5- 25 Dispatch console location operation The location is successful if the terminal information is shown on the map. Move cursor to a terminal on the map, the detailed location information will be displayed in the following red box 1 .
  • Page 35: Frame Select And Dispatch On The Map

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 26 Map interface display and operation 5.1.15 Frame Select and Dispatch on the Map Frame select terminals on the map to make a temporary group call. Figure 5- 27 Frame select on the map Tick the terminals in the pop-up box that need to be called, and click Call to start the group call.
  • Page 36: Dispatch Console Initiates Video Pull

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 28 Frame select and dispatch on the map 5.1.16 Dispatch Console Initiates Video Pull. Select Dispatch on the system menu, and then switch to the Video Dispatch interface. Move cursor to a user, the user will be highlighted. Right click the user to display the operation menu.
  • Page 37 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 29 Dispatch console initiates a video pull Adjust the number of terminal videos to be displayed on the upper area of the Video interface. Click to customize the display mode.
  • Page 38: Dispatch Console Initiates Video Distribution

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 30 Toolbar of the video display window 5.1.17 Dispatch Console Initiates Video Distribution Pull a terminal video to the dispatch console first, and then move cursor to the video display window, the toolbar will be shown.
  • Page 39: Operations Of Multimedia Dispatch System

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 31 Dispatch console Initiates video distribution Operations of Multimedia Dispatch System The Multimedia Dispatch System (MDS) client supports independent client operations. It’s required to install the client before logging.
  • Page 40: Dispatcher Login

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 5.2.1 Dispatcher Login Open the CS dispatch console client. If the the PC has multiple IP addresses, the client will prompt you to select the IP address. Select the correct IP address of PC that accesses with the client, and then turn to the login interface.
  • Page 41 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 34 Operations of the multimedia dispatch video pull After the video is pulled, the video captured by the user's camera can be viewed on the dispatch console. See the following figure: Click at the lower right corner of the video window to end the video pull.
  • Page 42: Video Distribution

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 35 Multimedia dispatch video display window 5.2.3 Video Distribution Dispatch console can distribute the pulled videos to terminals and groups. Select a video that has been pulled on the interface of the dispatch console, click on the lower right corner of the window, then the distribution page will pop up.
  • Page 43 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 36 Multimedia dispatch video distribution Click Start Distribution to distribute the video. For example, after a video is successfully distributed to user 5903, the pull and distribution status will be displayed on both the user list and the distribution list.
  • Page 44 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual After the video is successfully distributed, the screen of terminal will display the video source, as shown below: Figure 5- 38 Video is distributed to the receiving terminal. Click End on the Terminal who is receiving video to end the video distribution.
  • Page 45: Location

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 5.2.4 Location Terminals and groups can be located at the Map interface of the dispatch console. Select the terminal to be located, and select Location from the shortcut menu, see the following figure.
  • Page 46 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 5- 41 MDS location display Right click the contact list of the terminal and select to view the historical track replay of the terminal, as the following figure. Figure 5- 42 Viewing historical track of the terminal Input the Start time and End time on the Historical Track page, and click Search to query the historical track of the terminal.
  • Page 47: Card Allocation And Number Allocation

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Click to pull the video, see the following figure. Figure 5- 43 Dispatching the terminal on the Map interface Card Allocation and Number Allocation Hand-held Terminal Number Allocation 6.1.1 Login to the unified OMM Login to the unified OMM via IE browser (IE 11).
  • Page 48: User Authentication Information Configuration

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 6- 1 Unified OMM interface 6.1.2 User Authentication Information Configuration , select Authentication, and switch to the Step1: Click Operation Management Authentication information interface. Select Add card under the menu to add the...
  • Page 49: User Number Allocation

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Step 2: Input the IMSI number and SIM card authentication information (User key, Authentication management domain and OPC, can directly copy the existing card information) on the Add card page. Click Save to complete operation, as the...
  • Page 50 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 6- 4 Add user Step 2: On the pop-up Add user page, input the IMSI number, User number (beginning with 1880755), tick Activated data service, select iepc.com as the data...
  • Page 51 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 6- 5 Input user information-1 Figure 6- 6 Input user information-2 Note: Select the user to be operated, click to edit or delete the user. All rights reserved © 2021 Copyright Caltta Technologies Co.,Ltd.
  • Page 52: Add Group

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 6.1.4 Add Group Step1: Click Operation Management ->Group and switch to the Group management interface, and select ZiLTE group under menu on the right to add group: Figure 6- 7 Add group Step 2: Input Group number (beginning with 6880755), Group short number, and Group name on the Add group interface.
  • Page 53: Add Group Member

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 6- 8 Group account information setting Note: Select the group to be operated, click to edit or delete the group. 6.1.5 Add group member Select the group that need to add group members, and click the number in the Group member column, see the following figure.
  • Page 54 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Click on the right of the group member page to display the page for editing group members, see the following figure. Figure 6- 10 Add group member-2 Select the member to be added from the available members list, and click to add the group member, see the following figure.
  • Page 55: Cpe Terminal Number Allocation

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Select the group member to be edited, and click to display the page for editing group member attributes. Modify the information, and click Save. The group member attribute will be modified.
  • Page 56: User Number Allocation

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual 6.2.3 User Number Allocation Step 1: Click Operation Management -> User and switch to the user management interface, select ZiLTE under menu on the right to add user. This step is the same as that of hand-held terminal number allocation.
  • Page 57: Apn Configuration

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 6- 14 Enter to expert diagnosis mode on the unified OMM interface. 6.2.5 APN Configuration The APN configuration mainly include CPE Access Terminal IP Pool Configuration and CPE Terminal Authorization Profile Configuration.
  • Page 58 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual IP Segment Start:45.45.x.1 IP Segment End: 45.45.x.254 Mask: 255.255.0.0 x represents any number of 0-254. The x of the IP Segment Start is the same as the IP Segment End. Figure 6- 15 Add CPE IP Pool and IP Segment.
  • Page 59: Synchronize Data

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual CPE IP: The IP address used by the CPE to obtain wireless signal, which is the corresponding IP address inside the IP pool (recommend: 45.45.x.2, where x is the IP network segment of the corresponding address pool).
  • Page 60: Dispatcher Management

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 6- 17 Show CPE access status Dispatcher Management Step1: Select Operation Management -> Dispatcher, switch to the dispatcher management interface. Click on the right side to show interface of adding a dispatcher.
  • Page 61 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Step2: Input the corresponding information according to the interface requirements (the dispatcher number beginning with 8880755, 11 digits), and click Save at the bottom to complete the operation of adding a dispatcher, see the following figure:...
  • Page 62: References

    ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual References Manually Add Trusted Sites to the IE Browser IE 11 (win 7 32-bit operating system) is used for the login and related operations of the dispatch console and OMM of the ZiLTE system. It’s required to configure the IE...
  • Page 63 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Return to the page of Internet Options [Security], select Trusted sites and click Custom level to enter the Security Settings - Trusted Sites Zone page to set the security level of the trusted sites. Set all the sub-items under ActiveX controls and plug-ins to Enable, see the following figures.
  • Page 64 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 7- 3 Security settings of trusted sites-2 Select Enable for "Allow script-initiated windows without size or position constraints", click OK. Figure 7- 4 Security settings of trusted sites-3 Page 56 ©...
  • Page 65 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Return to the page of Internet Options [General], and click Settings to enter the Temporary Internet Files page. Select [Every time I visit the webpage] -> [OK], see the following figure.
  • Page 66 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 7- 6 Uncheck "Turn on Pop-up Blocker" Switch to the page of the Internet Options [Advanced] . tick “Use software rendering instead of GPU rendering”, click OK. Page 58 © 2021 Copyright Caltta Technologies Co.,Ltd.
  • Page 67 ZXIMCU PT01 P200 Portable Emergency Command System Operation Manual Figure 7- 7 Advanced Setting of Internet Option Restart the IE browser to validate the configuration. Appendix A.1.1 7.2.1 Appendix A.1.1.1 Attention Precautions: All rights reserved © 2021 Copyright Caltta Technologies Co.,Ltd.
