PRODUCT MANUAL
PNUMATIC ASSIST ARM
For TMG-TC28 Tire Changer
MODEL:TMG-PAT
Please read the product manual completely before assembly
Check against the parts list to make sure all parts are received
Wear proper safety goggles or other protective gears while in assembly
Missing parts or questions on assembly?
Please call: 1-877-761-2819 or email: cs@tmgindustrial.com
Do not return the product to dealer, they are not equipped to handle your requests
WW W. T M G I N D U S T R I A L . C O M
T ol l Fr e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9
Advertisement
Table of Contents
Summary of Contents for TGM TMG-PAT28
- Page 1 PRODUCT MANUAL PNUMATIC ASSIST ARM For TMG-TC28 Tire Changer MODEL:TMG-PAT Please read the product manual completely before assembly Check against the parts list to make sure all parts are received Wear proper safety goggles or other protective gears while in assembly Missing parts or questions on assembly? Please call: 1-877-761-2819 or email: cs@tmgindustrial.com Do not return the product to dealer, they are not equipped to handle your requests...
- Page 2 Installation Instructions 1. After unpacking, check the following components Description Quantity Description Quantity Arm assembly Pressing wheel arm Bent arm Angel steel Tray arm Connecting rod Supporting bar W W W . T M G I N D U S T R I A L . C O M P 0 2 / 0 8 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 3 2. Installation Bent arm (2) on the Arm assembly (1), Locking the bolt 3. Installation Supporting bar (4) on the Arm assembly (1)， Locking the bolt W W W . T M G I N D U S T R I A L . C O M P 0 3 / 0 8 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 4 4. Open the side plate of the tire changer machine (TMG-TC28), find the A and B hole, the Connecting rod (7) through two holes. Noted: To keep the connecting rod from falling, yon need apply double-sided adhesive tape on the two sides of Bolt Holder .
- Page 5 6. Installation Arm assembly (1) on the tire changer machine(TMG-TC28)， Locking the bolt 1. Connect Arm assembly (1 ) to Connecting rod (7), and lock the bolt. 2. Connect Arm assembly (1 ) to Angel steel (6) , and lock the bolt. W W W .
- Page 6 7. Installation Tray arm (3) and Pressing wheel arm (5) on the Arm assembly (1)， Locking the bolt 8. Pipe connection: The end is connected to the Side Tee . the close the side plate. W W W . T M G I N D U S T R I A L . C O M P 0 6 / 0 8 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 7 Explosion Diagram W W W . T M G I N D U S T R I A L . C O M P 0 7 / 0 8 T o l l F r e e : 1 - 8 7 7 - 7 6 1 - 2 8 1 9...
- Page 8 ITEM# DESCRIPTION ITEM# DESCRIPTION Sliding seat welding Lift cylinder assembly Column welding Internal thread piston rod Welding of six-square pressing rod The piston 100-25 Conical pressing roller External thread piston rod Large gasket 8 Lift cylinder screw M10X550 Internal hexagon-cylindrical head Cylinder barrel 100 screw M8X16 Stand rod Angle...
