Redline Communications RAS-Extend M Installation Manuallines

Auto-acquire wireless tcp/ip solution

Hide thumbs

Table of Contents

Quick Links

Download this manual

Virtual Fiber™

Outdoor Wireless TCP/IP Transport

Important Notices ................................................................... 8

System Features ................................................................... 14

Materials ................................................................................ 27

Site Survey ............................................................................ 28

Site Preparation .................................................................... 34

Assemble Kits ....................................................................... 37

Install Equipment .................................................................. 42

70-00174-04-00

RAS-Extend M

Platform

Auto-Acquire Wireless

TCP/IP Solution

Installation Guidelines

Page

of 53

July 9, 2014

Table of Contents

Summary of Contents for Redline Communications RAS-Extend M

Page 1: Table Of Contents
Installation Guidelines Important Notices ..............8 System Features ..............14 Materials ................27 Site Survey ................28 Site Preparation ..............34 Assemble Kits ............... 37 Install Equipment ..............42 70-00174-04-00 Proprietary Redline Communications © 2014 Page of 53 July 9, 2014...
Page 2 This manual describes operation using software release v2.27 and may include features that are different or unavailable in previous software releases. Some RAS-Extend M features are controlled by options keys and are available only on specific revisions of hardware systems. Refer to the individual product Release Notes for information about required software and availability of features.
Page 3 RDL-3000 RAS-Extend M Installation Guidelines Revision Log Date Item Description of Changes 20140707 First draft 70-00174-04-00 Proprietary Redline Communications © 2014 Page of 53 July 9, 2014...
Page 4 Lightning Protection / Protection Contre la Foudre ........11 WEEE Product Return Process ............... 12 Service & Warranty Information ..............13 System Features ..............14 RAS-Extend M Wireless Terminal ..............17 Control & Power Out ..................17 Data and Power In ..................17 GPS Antenna In ................... 17 RF-1 / RF-2 ....................
Page 5 RDL-3000 RAS-Extend M Installation Guidelines 2.11 GPS Antenna Kit ....................26 Rover GPS Antenna ..................26 Base GPS Antenna ..................26 Materials ................27 Site Survey ................28 General layout Options ..................28 Survey for RF Access to Sector Controllers ..........29 Survey for GPS Satellites ................
Page 6 Figure 2: Features: RAS-Extend M System ..............14 Figure 3: Components: RAS-Extend M Deploy Equipment ..........15 Figure 4: Components - RAS-Extend M Wireless Terminal Ports ........17 Figure 5: Components: RAS-Extend M Wireless Terminal Dimensions ......18 Figure 6: Components: RAS-Extend M Antenna Positioner Ports ........19 Figure 7: Components: Antenna Positioner Dimensions ..........
Page 7 RDL-3000 RAS-Extend M Installation Guidelines Figure 33: Assembly: UHF Antenna Kit ................. 37 Figure 34: Assembly: Antenna RF Jumper Kit ............... 38 Figure 35: Assembly: Stand-Alone Wireless Terminal Bracket Assembly ...... 38 Figure 36: Assembly: Positioner + Antenna Weatherproofing ........39 Figure 37: Assembly: - GPS Antenna System Kit ............
Page 8: Important Notices
RDL-3000 RAS-Extend M Installation Guidelines Chapter 1 Important Notices Important Deployment Information IMPORTANT: Refer to the RDL-3000 Family User Manual for detailed regulatory information. Refer to this document before deploying and powering RDL-3000 family systems in the field. Service & Safety Safety Warnings ...
Page 9: Warning Symbols
RDL-3000 RAS-Extend M Installation Guidelines Warning Symbols These symbols may be encountered during installation or troubleshooting. These warning symbols mean danger. Bodily injury may result if you are not aware of the safety hazards involved in working with electrical equipment and radio transmitters. Familiarize yourself with standard safety practices before continuing.
Page 10: Radio Frequency Safety / Sécurité Des Fréquences Radio
WARNING: THIS EQUIPMENT STARTS AUTOMATICALLY.. WARNING: HOT SURFACE. DO NOT TOUCH. The RDL-3000 RAS-Extend M system is rated for operation at extreme ambient temperatures. When operating in high temperature conditions, the chassis surface area can be higher than the ambient temperature and personal thermal protection should be employed for any maintenance or inspection activity.
Page 11: Ul Information
RDL-3000 RAS-Extend M Installation Guidelines Table 1: Notice - Electrical Safety Specifications Class I EN 60950-1 All External Circuits TNV-1 as defined in EN 60950-1 All equipment must be grounded Le RDL-3000 du matériel a été testé pour la conformité aux normes de sécurité...
Page 12: Weee Product Return Process
WEEE Product Return Process In accordance with the WEEE (Waste from Electrical and Electronic Equipment) directive, 2002/96/EC, Redline Communications equipment is marked with the logo shown below. The WEEE directive seeks to increase recycling and re-use of electrical and electronic equipment. This symbol indicates that this product should not be disposed of as part of the local municipal waste program.
Page 13: Service & Warranty Information
RDL-3000 RAS-Extend M Installation Guidelines Service & Warranty Information  Refer all repairs to qualified Service personnel. Removing the cover panel or modifying any part of this device will void the factory warranty.  Locate the serial numbers and record these for future reference. Use the space below to affix serial number stickers.
Page 14: System Features
The RAS-Extend M auto-acquire wireless system delivers secure high-speed TCP/IP Ethernet network access to vessels and floating platforms operating anywhere in a Redline wireless coverage area. The RAS-Extend M mounts on a prepared mast and provides touchless continuous antenna alignment.
Page 15: Figure 3: Components: Ras-Extend M Deploy Equipment
RAS-Extend designed manufactured Redline Communications, a world leader in design and production of outdoor wireless TCP/IP transport for mission critical applications. Figure 3: Components: RAS-Extend M Deploy Equipment 70-00174-04-00 Proprietary Redline Communications © 2014 Page of 53 July 9, 2014...
Page 16: Table 3: Components- Ras-Extend M System Components
RDL-3000 RAS-Extend M Installation Guidelines Table 3: Components- RAS-Extend M System Components Item Description Wireless Terminal RAS-Extend M wireless terminal. Antenna Positioner RAS-Extend M antenna positioner. IMPORTANT: The installer must provide a fabricated mounting plate properly affixed to the mast top and prepared with bolt holes positioned as described in this document.
Page 17: Ras-Extend M Wireless Terminal
RF signals from attached (active) GPS antenna systems. The GPS system is used to determine the location, speed and direction of the RAS-Extend M system. Pre- terminated cables are provided to connect the wireless terminal to the GPS antennas.
Page 18: Figure 5: Components: Ras-Extend M Wireless Terminal Dimensions
RDL-3000 RAS-Extend M Installation Guidelines Figure 5: Components: RAS-Extend M Wireless Terminal Dimensions 70-00174-04-00 Proprietary Redline Communications © 2014 Page of 53 July 9, 2014...
Page 19: Ras-Extend M Antenna Positioner
The RAS-Extend M antenna positioner unit controls the alignment of the antenna for the RAS-Extend M system. Two pairs of RF ports conduct the RF signals between the static base ports and the moving platform. Control signals and power are provided by the RAS-Extend M wireless terminal.
Page 20: Figure 7: Components: Antenna Positioner Dimensions
RDL-3000 RAS-Extend M Installation Guidelines Figure 7: Components: Antenna Positioner Dimensions Figure 8: Components: Antenna Positioner Dimensions 70-00174-04-00 Proprietary Redline Communications © 2014 Page of 53 July 9, 2014...
Page 21: Data & Power Adapter
RDL-3000 RAS-Extend M Installation Guidelines Data & Power Adapter The RAS-Extend M Data & Power Adapter unit provides the Ethernet connection to the local network and the primary power input for the RAS-Extend M system. Figure 9: Components: Data & Power Adapter Ports Power In Port The Power In port (3-pin circular / M) for 120/240 VAC reliable power.
Page 22: Mimo Directional Antenna System
RDL-3000 RAS-Extend M Installation Guidelines MIMO Directional Antenna System The RAS-Extend M UHF system uses a 475 mm (19 in) directional antenna. Figure 11: Components: UHF MIMO Antenna Ports RF-1 / RF-2 The two RF ports (TNC / F) conduct RF signals between the antenna system and the wireless terminal.
Page 23: Wireless Terminal Mounting Bracket
RDL-3000 RAS-Extend M Installation Guidelines Wireless Terminal Mounting Bracket Figure 13: Components: Wireless Terminal Mounting Bracket Dimensions AC Power Plug Figure 14: Components: Power Plug Dimensions 70-00174-04-00 Proprietary Redline Communications © 2014 Page of 53 July 9, 2014...
Page 24: Antenna Rf Jumpers
Figure 15: Components: RF Jumper Cables Ethernet Cable The RAS-Extend M Ethernet cable conducts data between the RAS-Extend M system and the local network. This cable connects to the RAS-Extend M Data & Power Adapter unit. Figure 16: Components: Ethernet Data Cable The Ethernet cable and connector are shielded.
Page 25: Power, Control & Rf Cable
RDL-3000 RAS-Extend M Installation Guidelines Power, Control & RF Cable The Power, Control & RF Cable is the main connection between the RAS-Extend M wireless terminal and the RAS-Extend M antenna positioner. The 10-pin to 43-pin cable transfers power and control signals from the wireless terminal to the antenna positioner unit.
Page 26: Gps Antenna Kit
RDL-3000 RAS-Extend M Installation Guidelines 2.11 GPS Antenna Kit The RAS-Extend M uses a set of two (2) active-type GPS antennas. The two RF ports (TNC / F) conduct RF signals between the GPS antenna system and the wireless terminal.
Page 27: Materials
Materials Review list of materials to be provided by the installer Installation of the RAS-Extend M equipment requires additional equipment and materials supplied by the installer. The following list is a guideline only, and additional materials may be required based on local conditions at each installation site.
Page 28: Site Survey
Site Survey General layout Options The preferred installation configuration is to mount the GPS antenna bracket on the same mast (below) the RAS-Extend M antenna positioner and wireless terminal. Figure 22: Survey: General Layout Options 70-00174-04-00 Proprietary Redline Communications © 2014...
Page 29: Survey For Rf Access To Sector Controllers
Survey for RF Access to Sector Controllers For best results: Mount the RAS-Extend M in a location that provides a relatively unobstructed view of the horizon in 360 degrees. Avoid mounting the RAS-Extend M antenna close to metal objects that may block or reflect the signal.
Page 30: Survey For Gps Satellites
It is important to conduct a site survey before installing the GPS antenna. A poorly installed or badly located GPS antenna can cause interference and will not provide the necessary information for correct operation of the RAS-Extend M system. Figure 24: Survey: GPS Antenna The GPS antenna must have a clear view of the sky, preferably to within 10 degrees of horizon in all directions.
Page 31: Survey Network (Ethernet) Connection
RDL-3000 RAS-Extend M Installation Guidelines Survey Network (Ethernet) Connection A pre-terminated Ethernet cable is supplied with the RAS-Extend M system. This cable is pre-terminated with shielded RJ-45 connectors and a pre-assembled weatherproof gland for connection to the Data & Power Adapter.
Page 32: Survey Power Source
Survey Power Source The installer must: 1. Provide a compatible power source for the RAS-Extend M system. 2. Provide a power cord from the AC source to the Data & Power Adapter. A mating weatherproof plug is provided for connection to the adapter. Use the following system...
Page 33: Survey Spatial Requirements
RDL-3000 RAS-Extend M Installation Guidelines Survey Spatial Requirements The installer must prepare and install a mast for mounting RAS-Extend M antenna positioner, wireless terminal and GPS antenna system. Some installations may require a separate mast for the GPS antenna bracket.
Page 34: Site Preparation
Site Preparation Mast & Mounting Plate for Antenna Positioner The installer must prepare a mounting platform for the RAS-Extend M antenna positioner. The mast diameter must be 45 - 120 mm (1.75 - 4.5 in). Table 6: Preparation: Mast Loading Incl.
Page 35: Optional Second Mast For Gps System Arm
Optional Second Mast for GPS System Arm Based on the results of the GPS site survey, It may be desired to mount the GPS antenna arm separately form the RAS-Extend M antenna positioner and wireless terminal. The antenna mounting bracket is compatible with masts 45-120 mm (1.75-4.50 in) in diameter.
Page 36: Mounting Plate For Data & Power Adapter Unit
RDL-3000 RAS-Extend M Installation Guidelines Mounting Plate for Data & Power Adapter unit. The installer must prepare a flat mounting platform or shelf for the RAS-Extend M Data & Power Adapter unit. This unit may be mounted using the supplied metal feet, on plate prepared for direct mount, or with appropriate strapping.
Page 37: Assemble Kits
RDL-3000 RAS-Extend M Installation Guidelines Chapter 6 Assemble Kits Assemble Antenna Positioner and Antenna The UHF antenna and antenna positioner are supplied as two separate kits. Locate all parts from both kits before assembling the unit. 6.1.1 Antenna Positioner Kit Figure 32: Assembly- Antenna Positioner Kit 6.1.2...
Page 38: Antenna Rf Jumper Kit
Figure 34: Assembly: Antenna RF Jumper Kit 6.1.4 Assemble UHF Antenna on Positioner The RAS-Extend M antenna positioner may be installed with the UHF antenna oriented in the out-of-box position. Figure 35: Assembly: Stand-Alone Wireless Terminal Bracket Assembly Table 7: Assembly: UHF Antenna to Antenna Positioner...
Page 39: Figure 36: Assembly: Positioner + Antenna Weatherproofing
RDL-3000 RAS-Extend M Installation Guidelines Figure 36: Assembly: Positioner + Antenna Weatherproofing IMPORTANT: Do NOT support the antenna positioner by holding only the UHF antenna. ALWAYS provide direct support when lifting and moving the antenna positioner 70-00174-04-00 Proprietary Redline Communications © 2014...
Page 40: Assemble Gps Antenna Kit
RDL-3000 RAS-Extend M Installation Guidelines Assemble GPS Antenna Kit Figure 37: Assembly: - GPS Antenna System Kit Figure 38: Assembly: GPS Arm Assembly Drawing - Detail 70-00174-04-00 Proprietary Redline Communications © 2014 Page of 53 July 9, 2014...
Page 41: Figure 39: Assembly: Gps Antenna System Assembly Drawing
RDL-3000 RAS-Extend M Installation Guidelines Figure 39: Assembly: GPS Antenna System Assembly Drawing Install GPS Antenna Cable on Arm It is recommended to install the GPS antenna cable before mounting the antenna arm on the mast. Depending on the antenna cable length to be installed, use the following diagram to determine the correct cabling method.
Page 42: Install Equipment
RDL-3000 RAS-Extend M Installation Guidelines Chapter 7 Install Equipment It is recommend to install the system components in the order presented in this section. Mount Antenna Positioner on Mast Figure 41: Installation: Mount Antenna Positioner 70-00174-04-00 Proprietary Redline Communications © 2014...
Page 43: Mount Gps Antenna System
RDL-3000 RAS-Extend M Installation Guidelines Mount GPS Antenna System 7.2.1 Basic GPS Antenna Alignment (Base and Rover) Figure 42: Installation: Mount GPS Antenna System Installing the 6 m GPS Antenna Cables Check the following items before routing the antenna cable: ...
Page 44: Gps Antenna Alignment (Base And Rover)
RDL-3000 RAS-Extend M Installation Guidelines 7.2.2 GPS Antenna Alignment (Base and Rover) For accurate tracking the GPS antenna system must be correctly aligned with the movement of the vessel/platform. Important: The Base and Rover GPS antennas establish the orientation of the antenna positioner system.
Page 45: Mount Wireless Terminal
RDL-3000 RAS-Extend M Installation Guidelines Mount Wireless Terminal If the GPS antenna arm is mounted directly below the RAS-Extend M positioner, the wireless terminal is mounted directly on the GPS mounting bracket. Figure 44: Installation: Mounting Wireless Terminal Figure 45: Installation: Wireless Terminal Mounting Detail 70-00174-04-00 Proprietary Redline Communications ©...
Page 46: Figure 46: Installation: Stand-Alone Wireless Terminal Bracket Kit
RDL-3000 RAS-Extend M Installation Guidelines If the GPS antenna arm is mounted remotely from the RAS-Extend M system, the wireless terminal must be mounted using the stand-alone mounting bracket supplied with each system. Figure 46: Installation: Stand-Alone Wireless Terminal Bracket Kit...
Page 47: Install Power, Control & Rf Cable
RDL-3000 RAS-Extend M Installation Guidelines Install Power, Control & RF cable The Power, Control & RF Cable is the main connection between the RAS-Extend M wireless terminal and the RAS-Extend M antenna positioner. The 10-pin to 43-pin cable transfers power and control signals from the wireless terminal to the antenna positioner unit.
Page 48: Install Data And Power Cable (To Power Adapter)
RDL-3000 RAS-Extend M Installation Guidelines Install Data and Power Cable (to Power Adapter) The RAS-Extend M Power & Data cable conducts data between the RAS-Extend M power adapter and the wireless terminal. The 11-pin circular connectors are weatherproof when installed.
Page 49: Install Ethernet Cable
RDL-3000 RAS-Extend M Installation Guidelines Install Ethernet cable A pre-terminated Ethernet cable is supplied with the RAS-Extend M system. This cable is pre-terminated with shielded RJ-45 connectors and a pre-assembled weatherproof gland for connection to the Data & Power Adapter.
Page 50: Install Power Cable & Power Plug
RDL-3000 RAS-Extend M Installation Guidelines Install Power Cable & Power Plug The installer must prepare the power cord for attachment to the RAS-Extend M Data & Power Adapter unit. The AC power adapter is supplied with a non terminated weatherproof power connector. The installer must provide the power cable and terminate the cable to the power plug in accordance with the following wiring and assembly diagrams.
Page 51: Figure 52: Installation: Data & Power Adapter Ac Power Connector
RDL-3000 RAS-Extend M Installation Guidelines Figure 52: Installation: Data & Power Adapter AC Power Connector 70-00174-04-00 Proprietary Redline Communications © 2014 Page of 53 July 9, 2014...
Page 52: Install System Grounding
RAS-Extend M wireless terminal, antenna positioner and Data & Power Adapter unit. Use these connections to terminate grounding wires. All RAS-Extend M systems must be properly grounded to protect against power surges and accumulated static electricity.
Page 53 Virtual Fiber™ Outdoor Wireless TCP/IP Transport 302 Town Centre  Markham, Ontario  Canada  L3R 0E8 www.rdlcom.com 70-00174-04-00 Proprietary Redline Communications © 2014 Page of 53 July 9, 2014...
