Like a day at the beach!
Just re-designed, this lighthouse replica engages the user with a red
light at the top, seagull calls, rotating windmill-style sails, and a cool
breeze. Press and sustain the integrated switch to see and hear the
action. Wonderful for teaching cause and effect, this sensory toy also
encourages listening skills and relaxation. Use as a jumping off point
for storytelling and imaginative play. Can also be activated by your
own external capability switch. Requires 4 AA and 2 C Batteries. Size:
9"L x 9"W x 14"H. Weight: 3 lbs.
Operation:
1. Harbor Breeze requires 4 AA batteries and 2 C batteries (Not
included). Use alkaline batteries only (e.g. Duracell or Energizer
brand). Do not use rechargeable batteries or any other type of
batteries because they supply lower voltage and the unit will not
perform properly. Never mix old and new batteries together or
different brands or types together.
2. The battery compartment is located on the bottom of the unit. To
remove the battery compartment cover, unscrew the two small
Phillips Head screw on each side of the battery cover, and lift the
cover off. Install new batteries, being careful to observe proper (+)
& (-) battery polarity. Replace cover and screws. Turn the
On/Off/Volume knob clockwise to turn the unit On.
3. To attach the fan blades to the Windmill first lay the Harbor
Breeze on a flat surface with the black fan hub facing up. Peel off
the adhesive backed tape on the inside of the black fan hub. Next
place each blade in an upward facing direction and press down on
the tape to hold it in place. Each blade is, keyed to fit in one
direction. Finally put the red fan blade cover on top and secure
with the Phillips Head screw. Do not over tighten.(See photos on
Back page).
4. Push on the blue gumball switch or activate your own external
switch and watch the windmill blades go round and round to feel
the gentle breeze while ocean sounds and music plays. Connect
Harbor Breeze to any external capability switch via the jack,
located on the side of the unit. Harbor Breeze is equipped with a
1/8-inch jack, for use with capability switches with a 1/8-inch plug.
If you need to use a 1/4- to 1/8-inch adapter, it must be a mono
adapter, like our #1170, not stereo.
5. If you are using an external capability switch, make sure that the
connections between the external capability switch and the
adapter (if applicable) and the jack on the Harbor Breeze are
plugged in all the way. There should be no gaps.
Troubleshooting:
Problem: Harbor Breeze does not work.
Action #1: Make sure the On/Off/Volume is turned ON and the
Volume is set to an auditable level.
Action #2: Check all batteries for proper (+) & (-) battery polarity.
Action #3: Check to make sure noting is blocking or restricting the
movement of the activation switch.
Action #4: Try your external capability switch with another toy/device
to rule out the switch as the source of the problem.
Action #5: Replace any dead or weak batteries with fresh new
batteries. Never mix different brands or old and new batteries.
Care of Unit:
Harbor Breeze can be wiped clean with any household multi-purpose
cleaner and disinfectant. We recommend Simple Green, which is a
non-toxic biodegradable all-purpose cleaner.
When finished playing with the Harbor Breeze turn the On/Off/Volume
knob to Off to help prevent battery drain. For prolonged storage we
recommend removing the batteries.
Do not submerge the unit, as it will damage the contents and the
electrical components.
Do not use abrasive cleaners, as they will scratch the surface of the
unit.
Rev 12/7/2022
