Cool Energy
Swimming Pool Series
inverPool
R32 Heat Pump Water Heaters
Version 6.7
Installation and Users Guide
IMPORTANT SAFETY INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
RETAIN FOR FUTURE REFERENCE
Customer Service and Technical Support
(Open from 9am-4pm Monday- Friday)
Phone: 01472 867497
Email:
sales@coolenergyshop.com
Address: Office & Showroom - 163 Cleethorpe Road, Grimsby, DN31 3AX
Website: www.coolenergyshop.com
Advertisement
Table of Contents
Related Manuals for Cool Energy inverPool CE-iVP6
Summary of Contents for Cool Energy inverPool CE-iVP6
- Page 1 Cool Energy Swimming Pool Series inverPool R32 Heat Pump Water Heaters Version 6.7 Installation and Users Guide IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS RETAIN FOR FUTURE REFERENCE Customer Service and Technical Support (Open from 9am-4pm Monday- Friday) Phone: 01472 867497 Email: sales@coolenergyshop.com...
-
Page 2: Manual Handling
Under the Consumer Protection Act 1987 and the Health and Safety at Work Act 1974, it is required to provide information on substances hazardous to health (COSHH Regulations 1998). Cool Energy takes every reasonable care to ensure that these products are designed and constructed to meet these general safety requirements, provided they are properly installed and used. - Page 3 Transport of Heat Pump When transporting your heat pump, it’s important to keep it upright. The refrigeration system inside contains oil, gas and liquids which can be disturbed when moving your heat pump. If at any stage during transporting your unit, it is inclined more than a 45°...
-
Page 4: Product Overview
Electric, Oil or Gas boilers, Cool Energy heat pumps produces up to 50% less CO² whilst saves up to 80% on running costs. Cool Energy heat pumps are not only highly efficient, but also easy to install and safe to operate. -
Page 5: Materials Needed For Installation
Section 2 Installation The following general information describes how to install the air source heat pump. Note: Before installing this product, read and follow all warning notices and instructions. Only a qualified / competent person should install the heat pump. Materials needed for Installation: The following items are needed and are to be supplied by the installer for all heat pump installations:... -
Page 6: Installation Of Outdoor Unit
Note: For detailed specifications of the units please refer to name plate on the units. Correct installation is required to ensure safe operation. The requirements for Cool Energy heat pumps include the following: 1. Appropriate site location and clearances. 2. Wiring to conform to 18 edition wiring regulations. - Page 7 The installation space should be referred as follows: Intake and outlet should not be obstructed. The wall the unit is to be mounted on should be strong enough to bear the weight and vibrations of the unit. Allow for proper clearances around the unit. Location should allow easy access for maintenance. For any further guidance on heat pump installations for planning purposes, please consult the latest version of the MCS guidelines or your local authority.
-
Page 8: Water Connections
Example Installation Method: Water Connections... -
Page 9: Plumbing Installation Requirements
Water connections at the heat pump ABS / PVC pipe fittings are recommended to be installed on the flow and return connections. 50mm female fittings are provided which can be adapted to 1 ½” if required. The water inlet and outlet connections to the heat pump, are made by 2 x ABS flanged couplers (provided). -
Page 10: Electrical Connections
Electrical Connections WARNING – Risk of electrical shock or electrocution. Ensure that all high voltage circuits are disconnected before commencing heat pump installation. Contact with these circuits could result in death or serious injury to users, installers or others. CAUTION – Label all wires prior to disconnection when servicing the heat pump. Wiring errors can cause improper and dangerous operation. -
Page 11: Wiring Diagram
Wiring Diagram:... -
Page 12: Power Supply
Power Supply 1. If the supply voltage is too low or too high, it can cause damage and/or result in unstable operation of the heat pump unit, due to high in rush currents on start up. 2. The minimum starting voltage should be above 90% of rated voltage. The acceptable operating voltage range should be within ±10% of the rated voltage. -
Page 13: Operating Your Heat Pump
Operating Your Heat Pump Cool Energy User-Friendly Interface Controller General Instructions The Cool Energy inverPool operation panel features: 1. Touch keys for higher operating sensitivity and unlimited key operations. 2. Minimal electromagnetic susceptibility and interference. 3. Stylish appearance of easy viewing purposes. -
Page 14: Controller Setup
Controller Set-Up power button: Short press of power key can be used to exit current menu and return to the main screen. When in the main interface, long press for 3 seconds to turn heat pump on or off. Mode key: In the power-on state, long press of key for 3 seconds to switch between heating and cooling mode. - Page 15 Status Interface: In the main interface, long press of the key for 3 seconds to enter the unit status parameter interface. Then use the & keys to scroll through the readings. Press key to exit menu. Code Description Display range Inlet water temperature -30~99℃...
-
Page 16: Clock Setting
6. Clock setting： Long press of & together for 3 seconds to enter the clock setting mode. First, the hour digit flashes, indicating that the hour value of the current time can be adjusted using the & keys. Each time you press the key, the hour increases by one, and each time you press , the hour decreases by one. - Page 17 9. Frequency mode switching： When the unit is first powered on form the mains supply, press the key to switch the frequency mode: Silent, Smart, or Strong mode. Silent mode: will always try and operate at the lowest possible compressor frequency and fan speed to meet the required setpoint.
- Page 18 Wi-Fi Settings: Press the & keys at the same time for 3 seconds to enter the "default mode" network configuration, the icon will flash quickly when this mode is entered. Press the & keys at the same time for 3 seconds to enter the "compatibility mode"...
- Page 19 IOS System 2. Start the APP After the installation, click the icon on the device to start the app.
-
Page 20: Register And Login
Smart Life 3. Register and Login Register: Users without account can apply by clicking the "Register" function on the login page: Register, Agree the privacy policy, Enter the mobile number, Get the verification code, Enter the verification code, Set the password, Complete, as shown in the following figure: After registration, you need to create a family: family management, family adding, family name setting, location setting, room adding, complete. - Page 21 You can login directly if you have a Smart life account, the sequence as follows: After creating a family or login, enter the Smart Life App. 4. Wi-Fi module pairing...
- Page 22 Step 1. Within 10s after turning on mains power to the heat pump press and hold the & keys at the same time for 5 seconds to enter the pairing mode. The icon flashes indicating it is ready to be paired to the app. (Note, after 3 minutes.
- Page 23 Enter the home Wi-Fi password that the mobile phone is connected too. (This must be consistent with the Wi-Fi connected to the mobile phone and the WIFI must be 2.4G WiFi network). After automatic process “Add device successful” will be shown. You can change the name of the device and choose the installation location.
- Page 25 The heat pump can be renamed in here and shared to other users if needed.
- Page 26 App Timer setting Click “ ” on the main interface of the device and enter the timing setting interface. As shown in the figure below, click Add Timing. Enter the timing settings, sliding up and down hours/minutes to set the required times.
- Page 27 Remove device from Wi-Fi Network If you need to remove the device from your network or pair to a new one, press together for 5 seconds, the device is removed and re-entered into the pairing mode. icon flashes for 3 min to be re-paired to a new network.
- Page 28 Service & Maintenance – Service Engineer Inspection and Service Cool Energy air source heat pumps are designed and built to provide long life and performance, when installed and operated properly under normal conditions. Periodic inspections are important to keep your heat pump running safely and efficiently.
-
Page 29: Troubleshooting
Homeowner Inspection Cool Energy recommends that inspections on heat pumps are done frequently, especially after abnormal weather conditions. The following basic guidelines are suggested for your inspection: Make sure the front of the unit is accessible for service. Keep the top and surrounding areas of the heat pump clear of all debris. - Page 30 SERVICE RECORD It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. Service Provider Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer’s specified spare part when replacing controls.
- Page 31 Cool Energy Holding Ltd. 163 Cleethorpe Road, Grimsby, DN31 3AX. Email: sales@coolenergyshop.com www.coolenergyshop.com...
