Bruker BioSpin CryoProbe RF CRP RF UNIT Technical Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CryoProbe RF
ELECTRONICS
Technical Manual
003
Version
Bruker BioSpin

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CryoProbe RF CRP RF UNIT and is the answer not in the manual?

Questions and answers

Related Manuals for Bruker BioSpin CryoProbe RF CRP RF UNIT

Summary of Contents for Bruker BioSpin CryoProbe RF CRP RF UNIT

  • Page 1 CryoProbe RF ELECTRONICS Technical Manual Version Bruker BioSpin...
  • Page 2 The information in this manual may be altered without notice. Bruker BioSpin accepts no responsibility for actions taken as a result of use of this manual. Bruker BioSpin accepts no liability for any mistakes contained in the manual, leading to coinciden- tal damage, whether during installation or operation of the in- strument.

  • Page 3: Table Of Contents

    RF UNIT 1H13C2H15N Technical Data ....21 General ................21 Power Consumption ............21 Transmit-/Receive Bias Currents ........22 Service Information ..........23 General ................23 Basic System Checks ............23 Block Diagrams (HPPR and HPPR/2 family) ...... 24 Technical Manual Index 003 Bruker BioSpin 3 (33)
  • Page 4 Contents Figures ..............29 Tables ..............31 4(33) Bruker BioSpin Technical Manual Index 003...

  • Page 5: General Description

    HPPR CRP MODULEs respectively HPPR/2 MODULEs - Improved spectral purity of the rf pulses by using the built-in filters of the HPPR CRP MODULEs (HPPR/2 MODULEs) - Probe tuning of all nuclei - PICS (Probe Identification System) Technical Manual Index 003 Bruker BioSpin 5 (33)

  • Page 6: Crp Rf Unit Vs Hppr Crp (Hppr/2) Module

    - is used for probe tuning and matching - selects the received signal FT-REC - has full functionality for conventional probes • CRP RF UNIT: - contains transmit/receive switches - contains cryocooled preamplifiers - filters received signal - PICS 6 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 7: Rf Wiring For A Cp Dul C/H-D Or Cp Dui H/C-D (Hppr Crp)

    / to X-BB19F 2HS MODULE or 13C CRP MODULE (plugged at the SELECTOR manually) 1H RF IN 2H RF IN Connect the HPPR CRP FILTER SET 1H13C2H to the ‚XBB RF-IN‘ BNC-cable jack CP DUL C/H-D Technical Manual Index 003 Bruker BioSpin 7 (33)

  • Page 8: Rf Wiring For A Cp Dul C/H-D Or Cp Dui H/C-D (Hppr/2 Family)

    RF IN). Figure 1.2. RF wiring for a CP DUL C/H-D or DUI H/C-D (HPPR/2 family) Connect the HPPR CRP FILTER SET 1H13C2H to the ‚13C RF-IN‘ BNC-cable jack CP DUL C/H-D 8 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 9: Rf Wiring For A Cp Txi H-C/N-D (Hppr Crp)

    CONFIGURATION OF X-BB THE SELECTOR PREAMPLIFIER - SELECTOR from / to X-BB19F 2HS MODULE or 13C CRP MODULE (plugged at the SELECTOR manually) 1H RF IN 2H RF IN CP TXI H-C/N-D Technical Manual Index 003 Bruker BioSpin 9 (33)

  • Page 10: Rf Wiring For A Cp Txi H-C/N-D (Hppr/2 Family)

    1. The HPPR/2 XBB19F 2HS MODULE is used ONLY for operation with a con- ventional probe. 2. In general, no external filters are required between the HPPR/2 MODULEs and the CryoProbe. Figure 1.4. RF wiring for a CP TXI H-C/N-D (HPPR/2 family) CP TXI H-C/N-D 10 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 11: Rf Wiring For A Conventional Probe (Hppr Crp)

    TUNING - SPLITTER CONFIGURATION OF X-BB THE SELECTOR PREAMPLIFIER - SELECTOR from / to X-BB19F 2HS MODULE or 13C CRP MODULE (plugged at the SELECTOR manually) 13C PASS 2H STOP 15N PASS 2H STOP Technical Manual Index 003 Bruker BioSpin 11 (33)

  • Page 12: Rf Wiring In Case Of Existing Standard Hppr Modules

    Combination with HPHP 19F/1H/3H & X-BB MODULEs 1.9.4 Installation: • Power the HPHP 19F/1H/3H and X-BB HP MODULE by the ribbon cables leading from the HPPR CRP COVER MODULE to every single HPPR MOD- ULE. 12 (33) Bruker BioSpin Technical Manual Index 003...
  • Page 13 • Connect the rf cables of HPHP 19F/1H/3H MODULE to the 19F-connectors of the HPPR SELECTOR/TUNING-SPLITTER. • Connect the rf cables of HPHP X-BB MODULE to the UB-connectors of the HPPR SELECTOR/TUNING-SPLITTER. Technical Manual Index 003 Bruker BioSpin 13 (33)
  • Page 14 General Description 14 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 15: Operation

    The internal CryoProbe preamplifier may be bypassed for debugging purpose as follows: • xwinnmr -e UniTool hppr • [P]reamplifier module • [5] 1H, [7] 2H or [8] 13C • [S]et Force-State • [0] off, [4] cold, [8] bypass • [Q], [Q], ... Technical Manual Index 003 Bruker BioSpin 15 (33)

  • Page 16: Cryoprobe Operation With Hppr Crp Assembly

    XWIN-NMR selection of observe and decoupling nuclei (HPPR CRP only) 2.2.2 The observing nucleus can be selected in XWIN-NMR by the command ‚edasp’ and by selecting the corresponding F1 nucleus. The decoupling nuclei should be 16 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 17: Hppr Crp Cover Rf Selection Control

    SEMBLY provided that NOT MORE THAN 300 W is used for the HPPR 13C CRP or HPPR 15N CRP MODULE. Otherwise you have to check whether your possi- ble already existing HPPR XBB19F 2HS MODULE is able to handle 400 to 500W. Technical Manual Index 003 Bruker BioSpin 17 (33)
  • Page 18 - wobbling of observe channels (e.g. 1H, 13C, 15N), 2H lock operation. Note: After tuning and matching of a CryoProbe, the RF path routing must be re- set by the ‘crpon‘ command. 18 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 19: Rf Unit 1H13C2H Technical Data

    GND PIN 3 GND PIN 9 GND PIN 4 +15V (POWER Connector (LEMO), Pin 5) + 200 mA +15V PIN 5 -15V (POWER Connector (LEMO), Pin 6) - 50 mA -15V PIN 6 Technical Manual Index 003 Bruker BioSpin 19 (33)

  • Page 20: Transmit-/Receive Bias Currents

    ~ 25mA for ECL 00.05 and higher 500: Z003472 750: Z003475 500: Z003300 500: Z003897 600: Z003473 800: Z003476 600: Z003301 600: Z003898 800: Z003904 700: Z003474 900: Z003477 700: Z003914 900: Z100112. 20 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 21: Rf Unit 1H13C2H15N Technical Data

    GND PIN 3 GND PIN 9 GND PIN 4 +15V (POWER Connector (LEMO), Pin 5) + 200 mA +15V PIN 5 -15V (POWER Connector (LEMO), Pin 6) - 50 mA -15V PIN 6 Technical Manual Index 003 Bruker BioSpin 21 (33)

  • Page 22: Transmit-/Receive Bias Currents

    ~ 25mA for ECL 00.05 and higher 500: Z003472 750: Z003475 500: Z003300 500: Z003897 600: Z003473 800: Z003476 600: Z003301 600: Z003898 800: Z003904 700: Z003474 900: Z003477 700: Z003914 900: Z100112. 22 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 23: Service Information

    ING mode you get a traceable sweeped signal). With help of the oscilloscope, the following block diagram and a HPPR Technical Manual you can trace the tuning rf signal and all necessary trigger pulses at the HPPR and CryoProbe interface connectors. Technical Manual Index 003 Bruker BioSpin 23 (33)

  • Page 24: Block Diagrams (Hppr And Hppr/2 Family)

    Power Supply (BNC) 1H RF-OUT (BNC) 2H RF-OUT (BNC) 13C RF-OUT ± 5V COIL - SYSTEM (SMB) 13C COIL 2H COIL 1H COIL HPPR CRP FILTER SET 1H13C2H (BNC) (SMA) (SMA) (SMA) 24 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 25: Figure 5.2. Block Diagram Cp Dul C/H-D Or Cp Dui H/C-D (Hppr/2 Family)

    (±15V / SDA / SCL) Power Supply (BNC) 1H RF-OUT (BNC) 2H RF-OUT 13C RF-OUT (BNC) COIL - SYSTEM 13C COIL 1H COIL 2H COIL (BNC) POWER CABLE / I2C (±15V / SDA / SCL) Technical Manual Index 003 Bruker BioSpin 25 (33)

  • Page 26: Figure 5.3. Block Diagram Cp Txi H-C/N-D (Hppr Crp)

    (±15V / SDA / SCL) (BNC) (BNC) (BNC) Power Supply 1H RF-OUT 2H RF-OUT ± 5V COIL - SYSTEM (SMB) 1H COIL 2H COIL 13C COIL 15N COIL (BNC) (SMA) (SMA) (SMA) (SMA) 26 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 27: Figure 5.4. Block Diagram Cp Txi H-C/N-D (Hppr/2 Family)

    (±15V / SDA / SCL) Power Supply 1H RF-OUT 2H RF-OUT COIL - SYSTEM 1H COIL 2H COIL 13C COIL 15N COIL (BNC) POWER CABLE / I2C (±15V / SDA / SCL) Technical Manual Index 003 Bruker BioSpin 27 (33)
  • Page 28 Service Information 28 (33) Bruker BioSpin Technical Manual Index 003...

  • Page 29: Figures

    Block Diagram CP DUL C/H-D or CP DUI H/C-D (HPPR/2 family) ..............25 Figure 5.3. Block Diagram CP TXI H-C/N-D (HPPR CRP) ..... 26 Figure 5.4. Block Diagram CP TXI H-C/N-D (HPPR/2 family) ....27 Figures Tables Technical Manual Index 003 Bruker BioSpin 29 (33)
  • Page 30 Figures 30 (33) Bruker BioSpin Technical Manual Index 003...
  • Page 31 Table 4.1. Power Consumption ............21 Table 4.2. Cryoprobe T/R-switch bias current for the HPPR CRP ..22 Table 4.3. Cryoprobe T/R-switch bias current for the HPPR/2 family 22 Service Information Figures Tables Technical Manual Index 003 Bruker BioSpin 31 (33)
  • Page 32 Tables 32 (33) Bruker BioSpin Technical Manual Index 003...
  • Page 33 Lastpage Technical Manual Index 003 Bruker BioSpin 33 (33)

This manual is also suitable for:

Cryoprobe rf hppr crpCryoprobe rf hppr/2
