SMALL-SIZE INFRARED GAS SENSOR
MIPEX-02-X-RX-X.1 G
Non EX version
USER MANUAL
ESAT.100200.00.06 UM
ESAT.100200.00.06 UM
September 23, 2021
Page 1 of 43

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIPEX-02 and is the answer not in the manual?

Questions and answers

Related Manuals for Mipex MIPEX-02

Summary of Contents for Mipex MIPEX-02

  • Page 1 SMALL-SIZE INFRARED GAS SENSOR MIPEX-02-X-RX-X.1 G Non EX version USER MANUAL ESAT.100200.00.06 UM ESAT.100200.00.06 UM September 23, 2021 Page 1 of 43...
  • Page 2 Corrected description of <CCS>, <CFS>, <CKS> and <INIT> commands (see Appendix C.2.1, Appendix C.2.4). February 08 Released version. 2018 ESAT.100200.00.06 UM September 23, 2021 Page 2 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 3: Table Of Contents

    Appendix D.2. Temperature dependence of zero adjustment ..........39 Appendix E. Dust filter attaching ....................40 Appendix F. Troubleshooting ....................41 ESAT.100200.00.06 UM September 23, 2021 Page 3 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 4: Introduction

    “<” and “>”. ESAT.100200.00.06 UM September 23, 2021 Page 4 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 5: Description

    3.4 µm carbons. The presence hydrocarbons, see of methane is negligible. Fig. 8. ESAT.100200.00.06 UM September 23, 2021 Page 5 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 6: Technical Specifications

    To provide metrological properties during sensor lifetime, zeroing and span calibration should be performed periodically, at least once in 30 months (see Appendix D.1). ESAT.100200.00.06 UM September 23, 2021 Page 6 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 7 For variability in the whole operating temperature range for any sensor modification, see Table 6. ESAT.100200.00.06 UM September 23, 2021 Page 7 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 8: Handling Precautions

    RoHS 2 Compliant Directive 2011/65/EU. • It is strictly prohibited to remove label from sensor. ESAT.100200.00.06 UM September 23, 2021 Page 8 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 9: Installation And Service

    It is recommended to use dust filter (available as an option; see Appendix E). Filter has to be checked regularly and replaced when fouling is significant. ESAT.100200.00.06 UM September 23, 2021 Page 9 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 10: Electrical Conditions

    Maximum output current of UART is not more than 25 mA. Fig. 1. Typical current consumption waveform after power up ESAT.100200.00.06 UM September 23, 2021 Page 10 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 11 Fig. 2. Typical current consumption waveform Fig. 3. Typical current consumption waveform when UART is active (<@> command) ESAT.100200.00.06 UM September 23, 2021 Page 11 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 12 Fig. 5. Typical current consumption waveform (3.3 V input, R = 30 Ohm, C = 20 µF) ESAT.100200.00.06 UM September 23, 2021 Page 12 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 13: Getting Started

    (see Appendix C). Connection diagram of multiple sensors to single UART line is shown on Fig. 6. ESAT.100200.00.06 UM September 23, 2021 Page 13 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 14 – maximum high logic level voltage (2.7 V); – maximum output current of sensor microcontroller (25 mA). ESAT.100200.00.06 UM September 23, 2021 Page 14 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 15: Storage And Transportation

    Table 2. Ambient atmosphere should be free of any harmful impurities that can cause corrosion. ESAT.100200.00.06 UM September 23, 2021 Page 15 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 16: Warranty

    For warranty information or additional assistance, please contact support service (see Chapter 8). ESAT.100200.00.06 UM September 23, 2021 Page 16 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 17: Contacts

    2B, Valkas iela, Daugavpils, Latvia, 5417 Tel/fax: +371 26179021 web: www.mipex-tech.com e-mail: info@mipex-tech.com support: support@mipex-tech.com ESAT.100200.00.06 UM September 23, 2021 Page 17 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 18: Appendix A. Sensor Types And Characteristics

    2. C * See Table 5 for details. ** See Table 6 for details. ESAT.100200.00.06 UM September 23, 2021 Page 18 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 19 Typical sensor sensitivity to other hydrocarbons is shown on Fig. 7 and Fig. 8. ESAT.100200.00.06 UM September 23, 2021 Page 19 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 20 Table 6 is provided within a temperature range determined by a sensor RX-code (see Table ESAT.100200.00.06 UM September 23, 2021 Page 20 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 21 Fig. 8. Typical sensitivity of MIPEX-02-2-RX-D.1 G (target and calibration gas is C ) to other hydrocarbons ESAT.100200.00.06 UM September 23, 2021 Page 21 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 22 SMALL-SIZE INFRARED GAS SENSOR MIPEX-02-X-RX-X.1 G Fig. 9. MIPEX-02-B-RX-1.1 G (housing type “1”) overall dimensions in millimeters ESAT.100200.00.06 UM September 23, 2021 Page 22 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 23 SMALL-SIZE INFRARED GAS SENSOR MIPEX-02-X-RX-X.1 G Fig. 10. MIPEX-02-B-RX-2.1 G (housing type “2”) overall dimensions in millimeters ESAT.100200.00.06 UM September 23, 2021 Page 23 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 24 SMALL-SIZE INFRARED GAS SENSOR MIPEX-02-X-RX-X.1 G Table 7. Sensor pinout Purpose UART, TxD output UART, RxD input – ESAT.100200.00.06 UM September 23, 2021 Page 24 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 25: Appendix B. Connection Diagram

    INPUT NET OUTPUT NET – TxD output RxD input Fig. 11. Connection diagram for MIPEX-02 ESAT.100200.00.06 UM September 23, 2021 Page 25 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 26: Appendix C. Uart Communication Protocol

    2 seconds after the submission of the corresponding commands from the communication protocol. ESAT.100200.00.06 UM September 23, 2021 Page 26 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 27: Appendix C.2. Communication Protocol Commands

    Otherwise, it may result in malfunction of sensor. • In earlier versions of the firmware, some commands are unavailable. ESAT.100200.00.06 UM September 23, 2021 Page 27 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 28: Appendix C.2.1. Commands For Requesting Measured Data

    DATAE2 concentration C , two status bytes and symbol (see Table 11). CRC value. ESAT.100200.00.06 UM September 23, 2021 Page 28 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 29 If bits of status bytes are true, check their meanings in Table 12 and perform recommended operations. High and low bytes structure is presented on Fig. 12. ESAT.100200.00.06 UM September 23, 2021 Page 29 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 30 Status word is contained in response to command <F> (see Table 16). ESAT.100200.00.06 UM September 23, 2021 Page 30 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 31: Appendix C.2.2. Commands For Controlling Operating Mode

    Returns sensor serial number SRAL? symbol. (SN). SREV? Sensor firmware version. Returns the firmware version. ESAT.100200.00.06 UM September 23, 2021 Page 31 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 32: Appendix C.2.4. Commands For Sensor Configuring And Span Calibrating

    To achieve cross-coefficients contact support. ESAT.100200.00.06 UM September 23, 2021 Page 32 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 33 C and ZERO2 FAULT values are zeroed and ratio becomes equal 1 by this command. ESAT.100200.00.06 UM September 23, 2021 Page 33 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 34 -0003 8003 mode; zero shifts to calibration or zeroing. negative value. ESAT.100200.00.06 UM September 23, 2021 Page 34 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 35: Appendix C.2.5. Commands For Configuring Net Address

    Allows assigning and storing NETON sensor’s net address by using NETON FAULT <%AABB> command. ESAT.100200.00.06 UM September 23, 2021 Page 35 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 36: Appendix D. Sensor Configuration

    2.3. stop feeding CGM #1 into sensor atmosphere; ESAT.100200.00.06 UM September 23, 2021 Page 36 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 37 For methane C ( h ) = 4.4% vol.; for propane C ( h ) = 1.7% vol. Table 14. CGMs used for CH span calibration ESAT.100200.00.06 UM September 23, 2021 Page 37 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 38 Standard % vol. designation – – ISO 2435-73 0.85 (50) ±0.05 ±0.015 ГОСТ 5328-90 ESAT.100200.00.06 UM September 23, 2021 Page 38 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 39: Appendix D.2. Temperature Dependence Of Zero Adjustment

    Sensor’s metrological characteristics are guaranteed only for temperature range determined with RX-code (see Appendix A). ESAT.100200.00.06 UM September 23, 2021 Page 39 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 40: Appendix E. Dust Filter Attaching

    For housing type “2” perform the same operation on the side surface. ESAT.100200.00.06 UM September 23, 2021 Page 40 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.

  • Page 41: Appendix F. Troubleshooting

    ESAT.100200.00.06 UM September 23, 2021 Page 41 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 42 Status word (see Table 17 for details) Hex: “09” 62-69 Hex: “09” Hex: “09” Hex: “0D” ESAT.100200.00.06 UM September 23, 2021 Page 42 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
  • Page 43 To view all parameter values, use command <DATAE2>. ESAT.100200.00.06 UM September 23, 2021 Page 43 of 43 THE SOLE PROPERTY OF SIA MIPEX. ANY REPRODUCTION WITHOUT THE WRITTEN PERMISSION OF SIA MIPEX IS PROHIBITED.
