Steren AUD-799 - Bluetooth Headphone Manual

CAUTIONS

• Before using the headphones, make sure the device volume is moderate. Sounds with high volume can cause serious damage to the ear.
• Avoid using the headphones while doing any activity that requires your attention. It is dangerous to increase the volume too much by not being able to hear the sounds from outside.
• Before using them, charge the battery 100%.
• Do not use or store the headphones in places where there are leaks or splashes.
• Wipe with a soft and dry cloth or a soft bristle brush.
• This device is not intended for use by persons (including children) whose physical, sensory or mental abilities are different or reduced, or who lack experience or knowledge.
• Children should be supervised to make sure they do not use the device as a toy

Operation of this device is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference, including interference that may cause undesired operation.

DESCRIPTION

1. Micro SD memory slot
2. Microphone
3. 3,5 mm input
4. LED indicator
5. Micro USB port
6. Mode switching
7. Next track / Increase volume
8. Turn on and off / Play and pause / Answer and hang up
9. Previous track / Decrease volume
10. 3.5 to 3.5 mm AUX cable


11. Micro USB to USB cable


HOW TO CHARGE THE BATTERY

Before using the headphones for the first time, connect them via the micro USB to USB cable to a power adapter (5V 1A max.)
* To charge the battery, for 4 continuous hours. For subsequent times, the estimated charging time is 2 hours.

During the charging process, the LED indicator will remain lit red; When the charge finishes, it will turn off

HOW TO PLACING HEADPHONES

Separate the headphone from the headband, carefully, to make the adjustment at the height of your ears.

Remember to decrease the volume before you start using the device.

CONNECTION OPTIONS

Bluetooth connection

1. Press and hold the button until the LED indicator flashes red and blue.

2. Activate Bluetooth on your smartphone. Find the Steren AUD-799 device and select it to pair it.

   If the pairing has been successful, the LED indicator will flash slowly
   In case it is required by your device, enter the password 0000

Each time you turn on the headphones, they will automatically connect to the last paired device

Aux in connection

Use the AUX cable 3.5 to 3.5 mm to connect the headphones to your smartphone.

The headphones functions are not available in this type of connection.

MicroSD memory player

HOW TO USE

Turn on and off / Mode switching
Press and hold to turn the headphones on or off.
Press once to switch between Bluetooth and microSD memory player modes.

Music playback (only via Bluetooth * and microSD)

Press once to play or pause.
Press and hold to increase the volume / Press once to change to the next track.
Press and hold to lower the volume / Press once to change to the previous track.

Hands free*

Press once to answer or hang up a call.
Press and hold to reject a call.
Press and hold to increase the volume.
Press and hold to decrease the volume.

* These functions may vary depending on the model and the operating system version of your mobile device.

SPECIFICATIONS

Input: 5 V 1 A (x USB)
Battery capacity: 3.7 V 300 mAh

Headphone

Frequency response: 20 Hz – 20 kHz
Speaker sensitivity: 115 dB +/- 3 dB

Impedance: 32 Ω
Driver unit: 40 mm
Power output: 40 mW

Microphone

Frequency response: 50 Hz – 16 kHz
Sensitivity: -58 +/- 3 dB

Specifications may vary without previous notice.

WARRANTY

Product: Bluetooth Headphones
Part number: AUD-799
Brand: Steren

This Steren product is warranted under normal usage against defects in workmanship and materials to the original purchaser for three months on the battery and one year on the other parts from the date of purchase.

CONDITIONS

1. This warranty card with all the required information, invoice or purchase ticket, product box or package, and product, must be presented when warranty service is required.
2. If the product is in the warranty time, the company will repair it free of charge. The supplier will pay for transportation charges.
3. The repairing time will not exceed 30 natural days, from the day the claim was received.
4. Steren sell parts, components, consumables and accessories to customer, as well as warranty service, at any of the addresses mentioned later.

THIS WARRANTY IS VOID IN THE NEXT CASES

If the product has been damaged by an accident, acts of God, mishandling, leaky batteries, failure to follow enclosed instructions, improper repair by unauthorized personnel, improper safe keeping, among others.

1. The consumer can also claim the warranty service in the purchase establishment.
2. If you lose the warranty card, we can reissue it, if you show the invoice or purchase ticket.

RETAILER INFORMATION

Name of the retailer
Address
Serial number
Product

In case your product fails or have questions, please contact your nearest dealer.
If you are in Mexico, please call to our Call Center.
Call Center: 01 800 500 9000
