- Page 1 DION ENGINEERING LTD. Bulgaria, Ruse 7019, 8 Nikola Tabakov Street Phone: 00359 82 86 70 80; Fax: 00359 82 86 70 91; E-mail: dion@dion.bg OPERATION AND MAINTENANCE INSTRUCTIONS: PRE-CHILLING MODEL: PCHM-2...
-
Page 2: Table Of Contents
TABLE OF CONTENTS: INFORMATION ABOUT THE INSTALATION IDENTIFICATION AND TECHNICAL INFORMATION DECLARATION OF CONFORMITY MACHINE IDENTIFICATION SUMMARY: INTRODUCTION APPLICATION SAFETY TRANSPORT AND STORAGE INSTALLATION: 4.1. PREPARATION FOR INSTALLATION 4.2. GENERAL DESCRIPTION OF THE INSTALLATION 4.3. GENERAL SCHEME OF THE INSTALLATION 4.4. -
Page 3: Declaration Of Conformity
DECLARATION OF CONFORMITY Undersigned: “ Dion Engineering “ Ltd Address: 8 , Nikola Tabakov str. , Rousse 7019 , Bulgaria +359 82 86 70 80 ; Fax : +359 82 86 70 91 ; E – mail : Phone : dion@dion.bg... -
Page 4: Machine Identification
1.2. MACHINE IDENTIFICATION... -
Page 5: Introduction
1.3. ADDRESS OF THE MANUFACTURER DION ENGINEERING LTD. 8, Nikola Tabakov Str. Russe, 7019, Bulgaria Phone: 00359 82 86 70 80; Fax: 00359 82 86 70 91; E-mail: dion@dion.bg GENERAL INFORMATION: THIS MANUAL HAS TO BE READ CAREFULLY BEFORE USING THE INSTALLATION... -
Page 6: Application
2.2. APPLICATION FIELD OF APPLICATION: The current installation is meant for continuous filling of liquids such as egg mélange, egg yolk, egg white, juice, milk and other similar in composition and viscosity fluids. 2.3. SAFETY ONLY PERSONNEL FAMILIAR WITH THE SAFETY RULES MUST BE ALLOWED TO OPERATE THE INSTALLATION. -
Page 7: Transport And Storage
This is at least 1 meter between the installation and any other object or wall. 4.2. GENERAL DESCRIPTION OF THE INSTALLATION PRE-CHILLING MODUL MODEL PCHM-2 regulate the cooling fluid ( propylene glycol) coming from chiller and goes to devices ( pasteurizer PHE or water jacket tank) to be always with defined temperature ℃. -
Page 10: Operating The Machine
OPERATING THE MACHINE After the final installation - switching to the electric and connected to the other installations that meet the assembly requirements, with observing of all safety requirements, you can proceed towards the pre-chilling machine putting into operation. HOW TO ACTIVATE THE PRE-CHILLING FROM THE CONTROL PANEL? Unlock the control panel and take up all safety fuses. - Page 11 Photo 2 Second parameter is in degrees ( ℃ ) , and show in ( ℃ ) the desired temperature. ( photo 3). You can to change this temperature from control buttons to be suitable for your process. For example for pasteurizer PHE the temperature is good to be 1 or 2 (℃) degrees and for water jacked tank around 2 -4 degrees (℃) Photo 3...
- Page 12 Security pressure valve Dranage valve...
- Page 13 4.3. EXTERIOR AND INTERIOR VIEW OF THE CONTROL PANEL...
- Page 15 4.4. PID –DIAGRAM 4.4.1. Electric diagram...
- Page 16 4.5. REQUIREMENTS OF THE SUPPLEMENTARY INSTALLATION AND DIMMENSION SUPPLEMENTARY INSTALLATION PRE-CHILLING MODEL PCHM-2 Power supply 380 V, three phases, 50 Hz, 16 A, 4kW Grounding - 1 ͯ 16 m copper cable Debit propylene glycol min: 20 l/min Debit propylene glycol max.
-
Page 17: Warranty
(3) years, under the conditions that all the requirements for transport, assembly, correct operation and storage are fulfilled. 2. This warranty is only valid if the assembly and commissioning is done by a team of the company “Dion Engineering” Ltd.
