Page 1
NOUHAUS LIFESTYLE MASSAGE CHAIR USER MANUAL Classic Type 1.5 N-0003H Life Curation...
Page 2
(주)누하스의 안마의자를 구입해 주셔서 감사합니다. 사용 전에 이 사용설명서를 잘 읽으신 후 바르게 사용해 주십시오. 읽으신 후에는 항상 볼 수 있는 곳에 보관해 주십시오. 사용설명서에 제품 보증서가 포함되어 있습니다. 본 제품은 가정용 안마의자이므로 상업용 또는 산업용 등으로는 사용을 금해주시길 바랍니다. 본사는...
Page 3
NOUHAUS LIFESTYLE MASSAGE CHAIR USER MANUAL 누하스 안마의자 사용설명서 Classic Type N-0003H...
안전을 위한 주의사항 다음에 표기되어 있는 안전 관련 주의사항들을 제품에 안전하고 정확하게 사용하여 예기치 못한 위험이나 손해를 사전에 방지하기 위한 것입니다. 설치할 때 서비스 기사 외에는 절대로 개조, 분해, 수리하지 마십시오. 화재, 감전의 원인이 됩니다. 평평한 곳에서 사용하십시오. 고장이나 사고의 원인이 됩니다. 설치...
Page 7
N-0003H 젖은 손으로 전원 플러그를 만지지 마시고, 제품 청소나 손질 시 전원 플러그를 콘센트에서 분리하십시오. 감전 사고의 위험이 있습니다. 본 제품은 교류 220V 전용입니다. 전원 플러그는 반드시 접지된 220V 전용 콘센트를 사용하십시오. 콘센트의 이상 발열로 인한 화재의 위험이 있습니다. 멀티탭 사용 시 반드시 접지형 콘센트를 사용하십시오.
Page 8
· 당뇨병 등에 의해 고도의 말초순환장애가 있어 온도 감각이 상실된 사람 · 골수염 또는 구(拘) 우려가 있는 사람 *구(拘) 온몸의 근육이 오그라들고 팔과 다리를 펴지 못하는 증상 · 의사 표현 및 신체의 움직임이 자유롭지 못한 사람 · 디스크 증세가 있거나 치료 중인 사람 ·...
Page 9
N-0003H · 제품의 과도한 사용 및 압력으로 인한 근육 및 힘줄, 신경, 척추 손상 등 · 피부 질환 및 화상 등 - 골절 및 탈구, 염좌 등 · 호흡기, 소화기 장애 및 질식 등 엉덩이 및 허벅지를 마사지할 때는 바지 주머니에 물건을 넣은 채로 사용하지...
조립 방법 1. 박스 내 동봉된 모든 부품을 안전하게 꺼내십시오 (남겨진 부품이 없는지 확인하시기 바랍니다.) 2. 평평한 바닥에 놓아 흠집이 생기지 않도록 하십시오. 3. 제품을 앞으로 눕힌 후 중앙 연결 지지대를 제품 밑면 결합 홈에 끼우십시오. 주의 : '중앙 연결 지지대'의 첫 번째 면을 결합 고정 장치에 맞추어 끼우십시오. 4.
리모컨 사용방법 음량 조절 어깨 위치 조절 6 단계 자동 모드 (활력, 목/어깨, 허리/골반, 수면, 회복, 딥마사지) 전신 이동 부분 이동 마사지 마사지 3 단계 온열 모드 정방향/역방향 ( 1 , 2 , 3 단계) 주무름 마사지 두드림 마사지 복합 마사지(주무름&두드림) 허리...
Page 13
N-0003H 범위 설정 기능 설정 어깨 위치 조절 버튼 정방향/역방향 주무름 마사지 버튼 1 click : 5cm 높게 2 click : 5cm 낮게 1 click : 정방향 주무름 3 click : 기본위치 2 click : 역방향 주무름 3 click : 정지...
관리 및 보관방법 안마의자 관리 시에는 반드시 전원 플러그를 콘센트에서 분리하십시오. 또한 젖은 손으로 만지지 마십시오. · 감전이나 부상의 우려가 있습니다. 벤젠 시너(희석제), 알코올로 닦거나 살충제를 뿌리지 마십시오. · 변색, 변질, 화재의 원인이 됩니다. 물세탁은 불가하며, 천연가죽 제품에 사용되는 가죽클리너를 사용하여 부드럽게...
문제 해결 N-0003H 제품 사용 중 문제 발생 시 다음의 해결 방법을 참고하십시오. 문제가 지속될 경우, 전원을 끄고 전원 플러그를 콘센트에서 분리한 후 고객센터에 문의하십시오. 사용자가 임의로 제품을 분해, 수리해서는 절대로 안 됩니다. 임의 분해 및 수리로 인해 제품이 손상되면 제품 보증을 받으실 수 없으며, 누하스는...
Q1 . 등 쪽만 안마를 받을 수 있나요? 주무름 마사지 버튼을 누른 후 전신 이동 마사지 버튼을 눌러 마사지 받고 싶은 부위에서 다시 한번 눌러주시면, 마사지 볼이 고정됩니다. Q2 . 텐션 조절은 가능한가요? 설치 시 지급된 육각렌치를 이용하여 텐션 조절이 가능합니다. 육각렌치를...
Page 17
N-0003H Q6 . 가죽 교체가 가능한가요? 헤드쿠션, 등시트, 에어백 시트 등 외관부분 유상교체 가능합니다. Q7 . 매장에서 체험했을 때와 다르게 작동음이 더 큰 것 같아요. 매장에서는 주변 소음으로 인하여 안마의자 작동음을 느끼지 못하셨을 수 있습니다. 비교적 조용한 주거공간에서는 안마의자 작동 시 기계 동작음이 들리실 수 있으나, 이는...
고객서비스 안내 02 3409 9500 무상 A/S 품목 1. 안마의자 내부의 마사지부를 운용하는 기계/기구류 2. 메인보드류, 각종 모터류, 에어펌프류 3. 내부 전기, 전자 배선 및 에어 호스류 유상 A / S 품목 1. 외부 시트 및 내부 시트, 내•외피 전체 2.
Page 19
N-0003H 교환 및 반품 안내 단순 변심에 의한 교환 및 반품은 반드시 설치 일로부터 2 주 이내에만 가능하며, 왕복 배송비(지역에 따라 금액 상이)와 설치비반환금이 청구됩니다. 제품 설치 시 중대한 수리를 요하는 하자일 경우 2 주 이내 무상교환을 원칙으로 합니다. 교환 및 환불 불가 안내...
제품 규격 제품명 누하스 클래식 안마의자 모델명 N - 0003H 안마의자 크기 W66 x D101 x H95 . 5 cm 오토만 크기 W49 x D39 x H48 cm 순중량 33 . 1kg (안마의자), 4 . 2kg (오토만) 약 49kg 총중량(박스 포함) 사용...
제품 보증서 N-0003H 1. 본 제품에 대한 품질은 보증서에 기재된 기간 조건 하에서 보증 혜택을 받습니다. 2. 무상 서비스 기간은 설치 일로부터 산정되므로 설치 일자를 기재 받으시기 바랍니다. 3. 사용에 의한 기능 저하, 파손, 소모 및 소모품의 교환은 무상서비스에 해당되지 않습니다.
Page 22
Thank you for purchasing NOUHAUS LIFESTYLE MASSAGE CHAIR. Please read this user manual carefully to ensure correct usage. After reading, keep this manual where you can easily find and refer to it. This product is a massage chair for home use and is not intended for commercial or industrial use.
Page 23
NOUHAUS LIFESTYLE MASSAGE CHAIR USER MANUAL NOUHAUS LIFESTYLE MASSAGE CHAIR USER MANUAL Classic Type N-0003H...
Page 25
CONTENTS Safety Precautions Assembly Instructions Components and Descriptions Instructions for Use Care and Storage Troubleshooting Specification Classic Type N-0003H...
Safety Precautions The following safety precautions are intended to prevent unexpected danger or damage by ensuring safe and accurate use of the product. When Installing Remodeling, disassembly, or repairs should not be performed by anyone other than service personnel. Can cause fire or electric shock. Use the product on a flat surface.
Page 27
N-0003H Check the rated voltage of the product and use a grounded outlet. There is a risk of fire due to overheating of the outlet. When using a power strip, use a grounding-type outlet. Using a non grounding-type outlet may cause electric shock or injury.
Page 28
· Those whose temperature sensation is lost due to severe peripheral circulation disorders such as diabetes, etc. · Those who have a risk of osteomyelitis or rickets *Rickets: Symptoms of shrinking muscles throughout the body and an inability to stretch arms and legs ·...
Page 29
N-0003H If you experience any of the following side effects while using the product, stop using it: · Abrasions, strains, bruises, stinging/burning, or cuts caused by the product · Damage to muscles, tendons, nerves, spine, etc. due to excessive use and pressure from the product ·...
Assembly Instructions 1. Safely remove all the parts enclosed in the box (Please make sure that there are no parts left behind). 2. Place it on a flat surface to avoid scratching. 3. Lay the product forward, and then insert the center connecting support into the groove on the bottom of the product.
Components and Descriptions N-0003H Bluetooth speaker Head cushion Seat back SL frame Thermo- massage Waist airbag area Pelvis airbag Remote control Remote control pocket Remote control terminal Connection terminal groove Power terminal Four-foot support USB port Fuse Power port...
Instructions for Use Volume adjustment Shoulder position 6 -step automatic mode adjustment (Vitality, Neck/Shoulder, Waist/Pelvis, Sleep, Recovery, Deep Massage) Full-body massage Partial movement massage 3 -level thermomassage Forward/Reverse kneading massage (Levels 1, 2, 3) Tapping Complex massage (Kneading & Tapping) massage Waist air Pelvis air massage...
Page 33
3 clicks: Stop You can use the speaker by connecting a device with Bluetooth functionality to the main body. (ID: N-0003H / PW: 0003) * If it is paired to another device, be sure to disconnect it before connecting. 3 -level thermomassage button...
Information on natural leather NOUHAUS uses natural cow leather. It is a natural phenomenon that each natural leather differs in texture and color, and marks such as scars and wrinkles are characteristics of genuine leather.
If any problem occurs while using the product, refer to the following solutions. Users should never disassemble or repair the product at their own discretion. NOUHAUS is not responsible for any damage to the product caused by disassembly or repair at the user’s discretion. Problem Solution The product does not work.
Q1. Can I get a massage on my back only? After pressing the kneading massage button, press the Full-body massage button and press it again when the massage balls reach the targeted area. Then the massage balls will be fixed. Q2.
Specification Product name Nouhaus Classic Massage Chair Model name N-0003H × × Size of the massage W 66 D 101 H 95.5 cm chair × × Size of the ottoman W 49 D 39 H 48 cm Net weight 33.1 kg (massage chair), 4.2 kg (ottoman)
