Entity EN0481 Instruction Manual

This report describes the features and operation of the board EN0481
Voltage Monitor is a device that displays the measurement of the voltage and frequency of power supply by using different color LEDs.
Description Front
LED LED LED
1 2 3
Links
Connect the Voltage Monitor to the power supply that you want to
measure.
Indication of the voltage:
Depending on the value of the supply voltage detected, the LEDs 4-6, as shown in
the table opposite.
Indication of the frequency value:
Depending on the value of power frequency detected, the LEDs 1 to 3, as shown in the tables below. Voltage Monitor can work in two different
ranges of values of frequency around 50 Hz and about 60 Hz The device automatically sets the range at power up.
If the device is
Indication of the value of frequency,
initially powered
range of values around 50 Hz
with a frequency
Frequency values
lower than 55 Hz,
To 48 Hz
the display
From 48,5 to 50,5 Hz
indications have
From 50,8 to 51,8 Hz
the values shown in
From 52 Hz forward
the table opposite.
Operating Specifications
Minimum operating voltage
Maximum operating voltage
Accuracy of measurement
EN0481
Indication of the value of power
frequency:
LED from 1 to 3
LED 1 color yellow
LED 2 color green
LED 3 color red
Mechanical dimensions: 36 x 72 mm; 50 mm depth.
LED LED LED
Container for electronic products according to DIN 43700 in self-extinguishing
4 5 6
material in black color.
LED:

 


= led on
100 V
260 V
5%
Operation
For every time the instrument is tested to verify proper operation of all
LEDs.
Once the test on the LEDs, the device starts its operation.
Voltage value
To 210 V
From 211 to 220 V
From 221 to 235 V
From 236 to 245 V
From 246 V forward
If the device is
Indication of the value of frequency,
initially powered at
range of values around 60 Hz
a frequency of 55
Frequency values
Hz, and the
To 58 Hz
frequency ranges
From 58,5 to 60,5 Hz
have the values
From 60,8 to 61,8 Hz
shown in the table
From 62 Hz forward
opposite.
Minimum frequency of operation
Maximum frequency of operation
Accuracy of measurement
1
Instruction Manual - version 1.1
Indication of the value of the supply
voltage:
LED from 4 to 6
LED 4 color yellow
LED 5 color green
LED 6 color red
LED:


 


LED:

 


40 Hz
70 Hz
= led on
= led on
5%
versione 1.1
