Summary of Contents for iControl Standard

  • Page 4 Thank you for purchasing the iControlStandard panel from iControl panel range. The iControlStandard is a complete control panel that enables control over the classic functionality of a pivot using the swit- ches on the dashboard. The iControlStandard panels are manufactured to the ri-...
  • Page 5 Table of con- tents Safety General Instructions Low-Voltage Electrical Safety Key to the iControStandard Panel Switches Indicator lights Measuring Devices Functions of the iControlStandard Main Switch Manual Operation Automatic Operation Auto-Reverse Auto-Stop Percentage timer Irrigation Control Pivot direction Safety Override First application Starting the pivot Procedure for stopping and disconnecting the pivot...
  • Page 6 Safety...

  • Page 7: General Instructions

    SAFETY 01.1 General Instructions • Only authorized persons who have received proper training may install, maintain or repair the control panel. • Operatives should always wear appropriate, approved personal protection equipment. • Respect the signs and keep the workplace clean. •...
  • Page 8 Key to the iControl Standard panel...
  • Page 9 KEY TO THE iControlStandard PANEL 02.1 Switches Main switch Dry, Wet, Aux Auto-Start or Manual Mode Start Switch Direction and Auto-Reverse Switch Safety Override iControlRemote 02.2 Indicator lights Machine activated Last tower moving Counterclockwise or clockwise Safety 02.3 Measuring Devices The iControlStandard panel incorporates the following measuring devices: •...
  • Page 10 Functions of the iControl Standard...

  • Page 11: Main Switch

    FUNCTIONS OF THE iControlStandard The iControlStandard is an easy-to-use control panel that enables the basic functionality of a pivot to be controlled using switches: 03.1 Main Switch This disconnects the entire control panel from the electrical supply, both the power connection (460/380 VAC) and the control voltage connection (120/110 VAC) Note: The control panel cannot be opened unless this switch is turned to OFF.
  • Page 12 FUNCTIONS OF THE ICONTROL BASIC 03.5 Auto-Stop The Auto-Stop function is an inherent feature of Auto-Reverse. In those positions ( ) the pivot will stop at its barrier. 03.6 Percentage timer This timer is used to regulate the speed of advance of the pivot, determining in turn the depth of water to be applied per cycle.
  • Page 13 FUNCTIONS OF THE iControlStandard 03.8 Pivot direction Sets the direction and enables the Auto-Reverse feature. Clockwise (forward). Auto-Stop at barrier. Counterclockwise (reverse). Auto-Stop at barrier. WARNING: For change of direction to work properly with the iControlRemote, this should be set to Auto-Reverse. 03.9 Safety Override The iControlStandard is fitted with a manual override for the safety system of the machine.

  • Page 14: First Applica- Tion

    First Applica- tion...
  • Page 15 FIRST APPLICATION 04.1 Starting the pivot It must be kept in mind that the pivot can be started in either Manual or Automatic mode. The following starting sequence should be used: • Turn the Main Switch to “ON”. • The panel voltmeter should indicate the supply voltage at that moment. •...
  • Page 16 FIRST APPLICATION 04.2 Procedure for stopping and disconnec- ting the pivot The following stopping sequence should be used: • Set the Start Switch to “OFF” • Turn the Main Switch to “OFF”. • Disconnect the automatic differential inside the panel or at the pumping station when the machine is not going to be used some time.

  • Page 18: Specifications

    Specifications...
  • Page 19 SPECIFICATIONS The following information is facilitated to prevent damage to the control panel. Working outside these parameters could damage the panel. Please follow these recommendations: Material: Stainless Steel. Dimensions: 610 x 535 x 295 mm Weight: 43 kg Voltage: 380 to 400 VAC / 50 Hz 460 to 505 VAC / 60 Hz Protection rating: IP56 rated Impact resistance rating: IK10...

  • Page 20: Circuit Diagram

    Circuit diagram...

  • Page 21: Before Installation

    CIRCUIT DIAGRAM 06.1 Before installation Read the Instruction Manual, especially the section relating to Safety. Always engage the following protection elements on the iControlStandard: • Differential switch “if present”: Personal protection against possible electrical ground or equipment leakage. (ID4/40/300mA) • Three-pole thermal-magnetic circuit-breaker “if present”: This protects the installation against excessive consumption or overheating at 16 or 25A, depending on the pivot size.
  • Page 22 CIRCUIT DIAGRAM 06.2 Diagrams 6.2.1 Cabling from panel to pivot...
  • Page 23 CIRCUIT DIAGRAM 6.2.2 Panel components Item Part # Description AC/DC HOUR METER, THREE HOLES CASE 1/4" MODEL 3410-1000; 12-869014 TRUMETER; 8826948 (ALT. 95.41010) 12-95.40089 VOLTMETER, 600V 12-401044 PERCENTAGE TIMER 60 SEC., MACROMATIC TRANSFORMER, INPUT: 380/400/415VAC, OUTPUT: 120VAC, 12-860144 50Hz : SIEMENS : MT05001 SWITCH DISCONNECT, SINGLE THROW, 30AF, 50kAIC : 12-860154 SIEMENS : CFS361J5...
  • Page 24 CIRCUIT DIAGRAM...
  • Page 25 CIRCUIT DIAGRAM...
  • Page 26 CIRCUIT DIAGRAM...
  • Page 27 CIRCUIT DIAGRAM...
  • Page 28 www.icontrolremote.com...
