Summary of Contents for RCS FS-381
- Page 1 FS-381...
-
Page 2: Safety Instructions
Install at flat place, not bending curved. 1. Installation nach folgenden Richtlinien: Do not install near the water and moisture. - Stellen Sie den FS-381 immer auf eine ebene und stabile Locate power amplifier away from heat source. Unterfläche. Do not drop objects or spill liquids into the inside of - Wählen Sie eine trockene Umgebung und stellen Sie... -
Page 3: Front Panel Controls
FS-381 FRONT PANEL CONTROLS VORDERSEITE 1. Ein- /Ausschalter 1. Power Switch Nach Betätigen dieses Schalters ist das Gerät betriebs- Provides power to the unit. bereit. 2. Buzzer Off Switch 2. Buzzer ON/OFF Buzzer makes sound automatically when amplifier is out of Schalter um den akustischen Alarm bei Verstärkerausfall zu... -
Page 4: Rear Panel Controls
FS-381 REAR PANEL CONTROLS RÜCKSEITE 1. Audio Input Terminal 1. Symmetrischer Audio Eingang This is for input terminal of mixer or pre amplifier. Hier wird das Audio Signal angeschlossen, z. B. Mixer, Vorverstärker, CD-Wechsler o.ä.. 2. AMP Input 2. Anschluß für Eingang Verstärker This is terminal for connection of signal input of amplifier. -
Page 5: System Connections
FS-381 SYSTEM CONNECTIONS... -
Page 6: Block Diagram
FS-381 BLOCK DIAGRAM... -
Page 7: Specifications
FS-381 SPECIFICATIONS TECHNICAL Capacity 8 Main Amplifiers 1 Stand-by Amplifier Audio input / AMP INPUT 1 : 1 AMP output / SPK LINE 1 : 1 Power Consumption GENERAL Power(option) 230V AC 50~60Hz 24VDC Dimensions 483(W)x133(H)x350(D) mm Weight(kg) NOTE Specifications and design subject to change without notice for improvements. - Page 8 FS-381 Electromagnetic compatibility and low-voltage guidelines: RCS leaves all devices and products, which are subject to the CE guidelines by certified test laboratories test. By the fact it is guaranteed that you may sell our devices in Germany and in the European Union domestic market without additional checks.
