- Page 1 Mounted Harrow Model 822g Instruction Manual & Operating Guide...
- Page 2 Contents Mounted Harrow - Model 822g Pages Safety Notes and Warnings ............3 Introduction and Intended Use / Specifications ......4 Operating in the Field ............... 4 Attaching to Tractor ..............5 Settings ..................6 Cleaning .................. 7 Spare Parts ................7...
- Page 3 Safety Notes and Warnings Allow only experienced tractor drivers to operate this machine. The machine is recommended for use with a 4 wheel drive tractor. Only operate this machine from the tractor seat (work station). Operate only when bystanders are at a safe distance away. When unhitching the machine from the 3 point linkage, ensure that the machine is set down on a firm and level area.
- Page 4 Introduction and Intended Use The Ritchie Mounted Harrow - models 822g has been designed for, and is intended to be used for the renovation of pasture land, and for levelling gravel areas, manéges, and equestrian arenas etc. Deviations from the intended use should not take place without the notice and approval of David Ritchie (Implements) Ltd.
- Page 5 Attaching to the Tractor The implement is fitted with standard Connect the tractor top link to the Harrow headstock using the pin and lynch pin category 1 three point linkage. This linkage combines the Mounted Harrow and the provided. Tractor into a single working unit. Lift and Adjust the top link to ensure the three point position are controlled hydraulically.
- Page 6 Settings Fig 2 The Harrows are fitted with a unique ‘tri-spike casting offering 2 tine lengths and two tine angles. The harrow mat can be easily reversed to utilise either the long or the short tine. Fig 3 To reverse the Harrow Mat:- With the Harrow attached to the tractor and The mat should now be completely free of framework lowered into the working position...
- Page 7 Cleaning Use a high pressure water jet to remove residue from the machine at the end of each working day. Spare Parts Tri-spike Part No. 814-27 Harrow Ring Part No. 814-9 Replacement Harrow Mat - Part No. 822g-A05...
- Page 8 Model 824g David Ritchie (Implements) Ltd, Carseview Road, Forfar, Scotland, DD8 3BT Tel: 01307 462271 fax: 01307 464081 e-mail: agrisales@ritchie-uk.com www.ritchie-uk.com...
