Codan CP-SC-3 Instruction Manual

Codan CP-SC-3 Instruction Manual

Synthesizer channel programmer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SyntheSizer Channel
Programmer
inStruCtion manual
© 1994–2013 Codan Limited.
No part of this guide may be reproduced, transcribed, translated into any
language or transmitted in any form whatsoever without the prior written
consent of Codan Limited.
CODAN™, NGT™, Easitalk™, CIB™ and CALM™ are trademarks of
Codan Limited. Other brand, product, and company names mentioned
in this document are trademarks or registered trademarks of their
respective holders.
The English version takes precedence over any translated versions.
Document Number:
IM51-CPSC3
Revision:
4-0-0
Revision Date:
Jan 2013
Security Classification:
PUBLIC
Covers Models:
CP-SC-3
Codan Radio Communications
Victoria, BC
PRINTED IN CANADA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP-SC-3 and is the answer not in the manual?

Questions and answers

Summary of Contents for Codan CP-SC-3

  • Page 1 Codan Limited. CODAN™, NGT™, Easitalk™, CIB™ and CALM™ are trademarks of Codan Limited. Other brand, product, and company names mentioned in this document are trademarks or registered trademarks of their respective holders.
  • Page 2 Document revision history is provided at the back of the document. NOTE The user’s authority to operate this equipment could be revoked through any changes or modifications not expressly approved by Codan Limited. The design of this equipment is subject to change due to continuous development.
  • Page 3 FCC/IC MPE limits. This exclusion is subject to the limits specified in FCC 47 CFR §§ 1.1307 (b), 1.1310 and IC RSS-102 Issue 2 Sect 4. Codan Radio Communications has no reason to believe that the excluded transmitter encompasses exceptional characteristics that could cause non-compliance.
  • Page 4 This Page Intentionally Left Blank Synthesizer Channel Programmer Instruction Manual IM51-CPSC3-4-0-0...

  • Page 5: Table Of Contents

    Programming a Channel Code Number ........... Troubleshooting ..................Illustrations and Schematics ..........CP-SC-3 Exploded View ................CP-SC-3 Front Panel Board Component Layout ........CP-SC-3 Mainboard Component Layout ..........CP-SC-3 Mainboard Schematic Diagram ..........Parts List ................CP-SC-3 Mainboard Electrical Parts ............
  • Page 6 This Page Intentionally Left Blank Synthesizer Channel Programmer Instruction Manual IM51-CPSC3-4-0-0...

  • Page 7: General Information

    The CP-SC-3 Synthesizer Channel Programmer is designed to interface with all Codan MT-3 Repeater System of synthesized receivers and transmitters. The main feature of the CP-SC-3 Synthesizer Channel Programmer is to permit the user to program any of the 15 desired channels and view all 16 channels.

  • Page 8: Performance Specifications

    Motherboard Connections (+9.5 VDC and ground) are made through a 48-pin, gold plated, Type F connector on the rear of the CP-SC-3 programmer module. User connection made through mated ‘motherboard’ assembly of the repeater subrack. Type F standard connector complies with DIN 41612 Level 2 (200 mating cycles, 4-day 10 ppm SO2 gas test with no functional impairment and no change in contact resistance).

  • Page 9: Theory Of Operation

    The CP-SC-3 Synthesizer Channel Programmer Main PCB requires a +9.5 VDC supply. The current drawn from this supply varies from typically 250 mA for the CP-SC-3 programmer plus the current draw from the specific synthesized RF module. An optional fuse for the +9.5 VDC line can be used in cases where...

  • Page 10: Cp-Sc-3 Programmer Modes Of Operation

    Once the programming has finished, the CP-SC-3 programmer retrieves the new data The CP-SC-3 programmer operates in four and waits for a user key press. The CP-SC-3 different modes. programmer permits data retrieval from a fully programmed synthesized RF module and allows...

  • Page 11: Cp-Sc-3 Programmer Standard Factory Settings

    S tan d a r d fa C tory Baud Rate: 9600 S et t In G S Data Bits: Parity: None The CP-SC-3 programmer is configured at the Stop Bits: factory with the following jumper configurations: Handshake: None Installed +5 VDC Supply to U2...
  • Page 12 This Page Intentionally Left Blank Synthesizer Channel Programmer Instruction Manual IM51-CPSC3-4-0-0...

  • Page 13: Installation And Operation

    InStallatIon and oPeratIon ba SI C o Pe r atI o n To aid in operation of the CP-SC-3 programmer, the nomenclature in this manual differs slightly from that of any synthesized RF module manual. This manual refers to the memory locations in a synthesized RF module as channels (i.e.,...

  • Page 14: Setup

    After power-up or RESET, the display window indicates the status of the CP-SC-3 Programmer. While the CP-SC-3 is waiting to receive data, the display will read ‘Data Wait’. In normal operation, the channel number will be displayed above the corresponding code number.

  • Page 15: Front Panel Description

    The RS232 I/O Mini-8 DIN connector permits communication with a host terminal. The TX/RX DATA I/O DB-9 connector permits communication with any synthesized RF module (via Type F to DB-9 cable). The display window informs the user of the status of the CP-SC-3 programmer module. See Figure 2.

  • Page 16: Programming A Channel Code Number

    Installation and Operation P r oG r a m m In G a C h a n n el C o d e n u m b er Select a Channel 1. Press the FCTN key until the presently displayed channel number is flashing on and off. 2.
  • Page 17 Installation and Operation Program Example Following is an example for programming Code Number 5617 into memory Channel 14. C h 0 1 After power up or RESET, the display window shows Channel 1 with code 1 2 3 4 number 1234. C h 1 4 1.
  • Page 18 5. Press PRGM. NOTE: As long as the RESET is not pressed; or a code number is not changed; or power to the CP-SC-3 programmer is not interrupted, the data for Channels 2 through 16 will be retained. 6. Steps 3–5 can be repeated for as many times as required.

  • Page 19: Troubleshooting

    Installation and Operation tr o u b l e Sh o otI n G error Codes The CP-SC-3 Synthesizer Channel Programmer will display error messages on the following conditions: Error Code Cause Overrun Error Flag / Framing Error Input Data Buffer Overflow...
  • Page 20 This Page Intentionally Left Blank Synthesizer Channel Programmer Instruction Manual IM51-CPSC3-4-0-0...

  • Page 21: Illustrations And Schematics

    (PCB) numbering convention in which the last two digits of the circuit board number represent the circuit board version. All PCBs manufactured by Codan Radio Communications in Canada are identified by one of the following numbering conventions: PCB number 43-912010 Indicates circuit board Version 1.0...

  • Page 22: Cp-Sc-3 Exploded View

    5 Slide out circuit board. ON ALL SWITCHES. Front Panel Circuit Board Removal: DANIELS Remove screws 'E'. ELECTRONICS LTD. TITLE: CP-SC-3 EXPLODED VIEW DATE: Sept. 2003 DRAWN BY: David Borg DWG No: B0317 REV DATE: DANIELS Synthesizer Channel Programmer Instruction Manual IM51-CPSC3-4-0-0 ELECTRONICS LTD.

  • Page 23: Cp-Sc-3 Mainboard Component Layout

    TP11 22uF 221R 1N4148 22uF 1N4148 B A B DANIELS U4 SELECT COMPONENTS ELECTRONICS LTD. TITLE: CP-SC-3 SYNTHESIZER PROGRAMMER MAIN BOARD DESIG. 68HC811E2 68HC711E9 Synthesizer Channel Programmer Instruction Manual DATE: 23 NOVEMBER 1994 BOARD NO: 43-933611 IM51-CPSC3-4-0-0 JU15 Not Installed...

  • Page 24: Cp-Sc-3 Mainboard Schematic Diagram

    CD40106 CD40106 HIGHEST REFERENCE DESIGNATORS J4, JU15 DANIELS R22, RFC5 TP13,TRZ1 ELECTRONICS LTD VICTORIA BC. TITLE: CP-SC-3 SYNTHESIZER PROGRAMMER BOARD SCHEMATIC DIAGRAM UNUSED REFERENCE DESIGNATORS U4 SELECT COMPONENTS DATE: 12 JANUARY 1994 DWN BY: BRAD KOSIANCE APRVD: ----- ----- ----- DESIG.

  • Page 25: Parts List

    C P -S C -3 m a In bo ar d el eC tr IC a l Part S Part Number Description Qty. Narration CP-SC-3 PROGRAMMER, MT-3 SYNTH CHANNEL 1008-5B104K5R CAP/1206,100nF CER,10%,50V,X7R C1, C5, C10, C17, C18 1008-3B102K1G CAP/1206, 1nF CER,10%,100V,C0G...

  • Page 26: Cp-Sc-3 Front Panel Mainboard Electrical Parts

    Parts List CP-SC-3 Mainboard Electrical Parts (Continued) Part Number Description Qty. Narration 1150-5B8253FP RES/1206, 825K, 1%,1/4W,100ppm 1150-6B1004FP RES/1206, 1M00, 1%,1/4W,100ppm 1151-7B0106JG RES/1206, 10M0, 5%,1/4W,400ppm 1306-T361F2D5 FILTER, SM, EMI/LPF, 360pF,FER RFC1, RFC2, RFC3, RFC4, RFC5 2120-BC817025 TRANSISTOR/NPN, GEN PURP,SOT23 2144-D5P06V00 MOSFET/POWER,P CHAN,38W,D-PAK...

  • Page 27: Cp-Sc-3 Mechanical Parts

    COVER, TUNING, MT-3 SERIES 3702-62301105 COVER, WRAP AROUND,MT-3 SERIES 2018-D457618R DISPLAY, 4 CHAR,5x7 DOT MATRIX 3702-10000614 HANDLE, FRONT PANEL, 14HP,GRAY 3537-40511005 LABEL, HP92, CP-SC-3 F/P DISP. 5814-2M5LK00S LOCKWASHER,M2.5,SPLIT,A2 STEEL 5814-3M0LK00S LOCKWASHER, M3, SPLIT,A2 STEEL 5814-3M0LK00S LOCKWASHER, M3, SPLIT,A2 STEEL 5813-2M5HX50S NUT, M2.5, HEX, 5.0mm FLATS,A2...
  • Page 28 This Page Intentionally Left Blank Synthesizer Channel Programmer Instruction Manual IM51-CPSC3-4-0-0...

  • Page 29: Revision History

    Updated the manual to the new template 4-0-0 Jan 2013 6773 Replacement of colour-coded, DE-branded Lexan label with silkscreened Codan-branded plate • Updated CP-SC-3 mechanical BOM • Delete handle colour specification Updated to Codan template Synthesizer Channel Programmer Instruction Manual IM51-CPSC3-4-0-0...
  • Page 30 This Page Intentionally Left Blank Synthesizer Channel Programmer Instruction Manual IM51-CPSC3-4-0-0...
