SOUTHPAW 6550 Instruction Sheet

Instruction Sheet
VP - Linear Glider 6550
Take time to familiarize yourself with the use and maintenance of this equipment before using. Please file
this Instruction Sheet in an accessible location: the Instruction Sheet must be read and familiar to anyone
who is using Southpaw Enterprises Equipment.
IMPORTANT: Please check equipment immediately for any damage
that may have resulted during shipping. If any damage has occurred,
please contact Southpaw Enterprises, Inc. immediately.

MATERIALS LIST

1 - Linear Glider with Loop Pads
1 - Vinyl Pad
2 - Safety Snaps
1 - Set of Pull Handles
IMPORTANT: KEEP ALL PARTS TOGETHER.

MINIMUM HEIGHT REQUIREMENT AND SPACE NEEDED

Height Requirement: 8 feet.
Space needed: Assure a clear distance of 6 feet from walls and other obstacles.

HEIGHT ADJUSTER OR SAFETY ROTATIONAL DEVICE NEEDED

•
Southpaw Height adjuster (5000) is recommended but not included for ease of adjustment to proper height.
•
Southpaw Safety Rotational Device (2000) must be used if suspended from a single point. Be sure to use
Southpaw Therapy Rope (150) and Eye Splice (151) with Southpaw Height Adjuster (5000).
WORKING LOAD: 450 lbs.

SUSPENSION PROCEDURES

•
Attach your Linear Glider to your support eye bolts with the Safety Snaps provided.
•
To suspend your Linear Glider from two points: Suspension points for a Standard Linear Glider must be between
3-1/2 feet and 4-1/2 feet apart. Suspension points for the Adult Linear Glider must be between 4-1/2 feet and
5-1/2 feet apart.
•
To suspend your Linear Glider from four points: To suspend your Linear Glided from four points you will need two
additional Safety Snaps. The first suspension points for the Standard Linear Glider should be between 3-1/2 feet
and 4-1/2 feet apart and the second set of suspension points one to two feet parallel to the first. For the Adult
Linear Glider suspension points should be 4-1/2 feet to 5-1/2 feet apart with the second set parallel.
•
To suspend your Linear Glider from one point: A Southpaw Safety Rotational Device must be used to prevent
damage by rotation.

MAINTENANCE CHECKLIST

All of the following wear points should be checked on a monthly basis and recorded on the checklist enclosed.
•
Check Safety Snaps for wear. See the enclosed Safety Snap Instruction Sheet for inspection guidelines.
•
Check the ropes for loose or missing splice locks.
NOTE: A splice lock is the metal rope staple near both ends of the rope.
Warning: Failure to properly install a forged
steel eyebolt (1/2" or 5/8") may result in serious
injury or death.
about the installation of the forged steel
eyebolt, please contact Southpaw Enterprises
Customer Service at 1-800-228-1698.
1 - Instruction Sheet
1 - Safety Snap Instruction Sheet
1 - Pull Handle Instruction Sheet
1 - Maintenance Checklist
Store these instructions in a safe place or
with the enclosed maintenance checklist
If you have any questions
