Breathing hoses do not need to be in straps on test apparatus
1.
Use only exact replacement parts in the configuration as specified by the
manufacturer.
Instructions)
2.
The battery is to be changed in fresh air only.
3.
MSHA approved for use with one of the following 9-Volt batteries only:
Eveready
Panasonic
Rayovac
Duracell
(Remote Monitoring System MSHA Electronic Approval Page)
4.
Never substitute, modify, add or omit parts.
5.
Prior to using the BioPak 240 Revolution it must be determined that the
user is medically fit.
Instructions)
6.
Always handle oxygen cylinders with care to prevent damage.
7.
Do not open the cylinder valve in the presence of open flame, sparks or
high radiant heat.
8.
Oxygen will enhance the combustion of other materials so that materials
that normally will not burn in air may burn in oxygen-rich atmospheres;
and, materials that do burn in air will burn more vigorously and at a
higher temperature in oxygen-rich atmospheres.
9.
Oxygen will not cause materials to ignite without the presence of an
ignition source.
10.
The use of an SCBA will add to the workload and stress of the user.
11.
The BioPak 240 Revolution is suitable for respiratory protection entry
into and escape from oxygen deficient atmospheres with a temperature
as low as -5 degrees F (-5F) (-20C).
STATEMENTS OF FACT
BENCH BIOPAK 240-R CONTEST
User/Benchman: Cautions and Limitations, Special or Critical
User/Benchman: Cautions and Limitations, Special or Critical
User/Benchman: Cautions and Limitations, Special or Critical
User/Benchman: Cautions and
User/Benchman: Cautions and
User/Benchman: Cautions
(Users/Benchman Cautions and Limitations
10
2

Advertisement

loading
Need help?

Need help?

Do you have a question about the BIOMARINE BIOPAK 240 Revolution and is the answer not in the manual?

Questions and answers

Summary of Contents for CSE BIOMARINE BIOPAK 240 Revolution

  • Page 1 Breathing hoses do not need to be in straps on test apparatus STATEMENTS OF FACT BENCH BIOPAK 240-R CONTEST Use only exact replacement parts in the configuration as specified by the manufacturer. Instructions) The battery is to be changed in fresh air only. User/Benchman: Cautions and MSHA approved for use with one of the following 9-Volt batteries only: Eveready...
  • Page 2 The BioPak 240 Revolution is approved when the oxygen cylinder is fully charged with compressed medical or aviation grade oxygen at 3000 psi. Allow the oxygen cylinder to cool after filling to determine the correct pressure. Instructions) A foreign gas may cause cylinder corrosion. User/Benchman: Cautions and Instructions) Always check for a current hydrostatic test date.
  • Page 3 Turn-Around maintenance procedures should be performed as soon as possible after each use. (Benchman Section 3.1) It is acceptable to leave the oxygen cylinder in place until after washing and (Benchman Section 1.2) disinfecting has been completed. Immediately after completion of BioPak use, remove the used CO2 scrubber canisters.
  • Page 4 (User/Benchman: Cautions and Limitations, Special or To prevent mold growth remove the moisture control foam pads after each (Benchman: Section 1.3) Do not pre-pack any BioPak that will be stored at temperatures at or below 32 degrees F. (Benchman: Section 1.12) Pre-packing the BioPak 240 R with carbon dioxide scrubbers is only permitted when utilizing Orbsorb carbon dioxide scrubber.
  • Page 5 wrapping. (Benchman: Section 3.3) The Turn-Around Maintenance Tag should be attached to the apparatus in a prominent location to show completion of all maintenance steps. (Benchman: Section 1.1) In addition to normal Turn-Around Maintenance, the SCBA shall be visually inspected and pressure tested on a monthly basis if the apparatus is being used at least once a month or is placed in long term storage.
  • Page 6 Personnel who intend to use protective breathing equipment in a dangerous atmosphere must have the proper training, temperament and experience. (User/Benchman: Cautions and Limitations, Special or Instructions) A clean shaven user will significantly increase the chances of achieving an adequate face seal. (User/Benchman: Cautions and Limitations, Special or Critical The ongoing effectiveness and reliability of any protective breathing the equipment.
  • Page 7 BioPak weight fully charged is 34 pounds. (Benchman: Section 6) Do not re-use CO2 scrubber chemical. (User/Benchman: Cautions and Limitations, The flow test results at 0-5280 feet at a cylinder pressure of 1500-2000 shall be 1.8- 2.4 liters per minute. (Benchman: Section 1.8) During an alarm test the LED indication should turn to a flashing red with a horn sounding when the pressure gauge reads between 650-1000 psi.
  • Page 8 Epilepsy-Grand Mal or Petit Mal could limit or prevent the use of the BioPak 240 Revolution. Instructions) Use the ¼ inch hex driver from the service Kit to remove the flow restrictor. (Benchman Section 3.5) NOTE: The References listed above for the Statements of Facts can be down loaded for free from Bio-...
  • Page 9 BioPak 240 Revolution Complete Cons. No. Designation Cons. No. Designation Upper Housing Assembly Harness Assembly Coolant Lid Ice Canister Freeze Form Ice Canister Facemask Storage Plug Breathing Hose PCM Heat Exchanger O2 Cylinder Moisture Absorbent Pad Set Lower Housing Assembly...
  • Page 10 Lower Housing Assembly Cons. No. Designation Cons. No. Designation Lower Housing Shell Latch Foam Pad Diaphragm Springs Oxygen Cylinder Hold-Down Strap External Oxygen Knob Carrying Handle Vent Spacer...
  • Page 11 Pneumatic Assembly Cons. No. Designation Cons. No. Designation Bypass Feed Tube Oxygen Regulator Assembly Bypass Return Tube Remote Gauge Shut Off Assembly Oxygen Feed Tube Remote Gauge Assembly Bypass Valve Push Button Remote Gauge Feed Tube Assembly Bypass Valve...
  • Page 12 Manifold Assembly Cons. No. Designation Cons. No. Designation Manifold Block w/ Pressure Switch Swivel Elbow Fitting Constant Add Flow Restrictor Assembly...
  • Page 13 Center Section Assembly Cons. No. Designation Cons. No. Designation Lid O-Ring Demand Valve Gasket Demand Feed Tube Demand Valve Assembly Center Section Body Assembly Flexible Diaphragm Constant Add Fitting Diaphragm Clamp Demand Add Fitting...
  • Page 14 Center Section Lid Assembly Cons. No. Designation Cons. No. Designation Coolant Lid Flow Baffle Center Section Lid Self-Tapping Screws...
  • Page 15 Diaphragm Assembly Cons. No. Designation Cons. No. Designation Flexible Diaphragm Vent Seat O-Ring Vent Cap Vent Valve Spring Vent Body O-Ring Vent Valve Seat Vent Body...
  • Page 16 Breathing Hose Cons. No. Designation Cons. No. Designation Breathing Hose Stepless Ear Clamp Worm Gear Hose Clamp...
  • Page 17 Ice Canister Freeze Form Cons. No. Designation Cons. No. Designation Base Assembly Top Plate Freeze Tube Wing Nut...
  • Page 18 Oxygen Cylinder Assembly Cons. No. Designation Cons. No. Designation Green Cylinder Interior O-Ring Exterior O-Ring Valve Assembly Valve Collar...
  • Page 19 RMS Monitoring System Cons. No. Designation Cons. No. Designation Battery Door Battery Door Warning Label Battery Door Gasket 9Vdc Battery...
  • Page 20 AV3500 Facemask-Complete Facemask Assembly Cons. No. Designation Cons. No. Designation Interface Tube Locking Pan Head Screw Interface Gasket Hose Adapter O-Ring Interface Fitting AV3500 Hose Adapter Clip Facemask Magnetic Wiper Button Chin Condensation Pad Cowling Lens...
  • Page 21 Tool Kit Cons. No. Designation Cons. No. Designation Case Assembly Center Section Pneumatic Plug Leak Check Adapter Fitting Combination Pick Tool Flow Test Fixture 1/4 - Inch Hex Driver Test Key Leak Detection Fluid Vent Valve Wrench 3/8 Inch OD Rubber Tubing...
