First Watch Security 1110 Instructions

INSTRUCTIONS
CAUTION: Do not unscrew small retaining screw on rear of
lock body. Use only dry lubricant (graphite) on locks.
Keep keyway clear of foreign objects.
1. At desired height bore the hole for the cylinder 1-1/4"
diameter, with center at a distance of 2-3/8" from edge
of door.
2. Put key in lock. Insert cylinder and ring from the outside
of door and place back plate on inside of door. Connect
back plate to cylinder with two connecting screws. Cut
screws to proper length relative to door thickness. Adjust
screw tension so that lock operates.
1110
SATISFACTION GUARANTEED
(See website for details www.hickoryhardware.com)
Belwith Keeler Décor Solutions
3100 Broadway SW, Grandville, MI 49418
Night Latch
®
in China
3. Cut off connecting bar so that it projects 3/8" beyond
inside of door.
4. Place lock on door so that connecting bar enters slot.
Mark holes. Remove lock and drill 1/8" pilot holes. Attach
lock to door by inserting screws through lock into door.
5. Place strike plate on door jamb. Mark holes. Remove
strike plate and drill 1/8" pilot holes.
6. As needed, use chisel to cut door jamb so that strike is
flush with door jamb. Install strike plate.
