- Page 1 F1 / F1+ / F1N User Manual User Manual (REV 2.0) 2021.03 Copyrightⓒ 2021 by Dadam Micro Inc. All Rights Reserved. No part of this document may be quoted, or reproduced for distribution without prior written approval from Dadam Micro Inc.
-
Page 2: Main Function
Before using the product, read all instructions and Warning Main Function cautionary markings in this manual. · Use this item only for its designed purpose. Sterilization · Do not disassemble the product. It is very dangerous to open or disassemble Strong sterilization by photocatalyst honeycomb unit the product when power is being applied. - Page 3 Main Body Components (Front View) Main Body Components (Side View) Status LED Air quality monitor LED Mood Light Button · F1 / F1+ : VOC sensor · F1N : VOC sensor Temp. / RH sensor Power / Operation Mode Button Frame Type Main Body Components (Rear View) Bottom grill...
- Page 4 Inside Main Body & Function Purified Air Polluted Air PCO Mesh Unit PCO Honeycomb Module · Sterilization · Removal of VOCs · Fine dust removal · Deodorization · Removal of VOCs...
- Page 5 How to install PCO Mesh Unit 1. Detach the grill from the main body 3. Insert the bottom grill Hold the left/right grill handles placed at the bottom and pull it down to detach Check the TOP marked on the grill and push it back in the direction of the arrow. the grill from the main body.
- Page 6 How to connect AC power adapter Plug the AC power adapter into the power connector located in the back of the main body.
- Page 7 How to install (Stand Type) 1. Stand Short-Leg Fasten the stand short-leg to the right lower part of the product with the enclosed screw. Fasten the stand short-leg to the other side with the enclosed screw. 2. Stand Long-Leg After fitting the stand long-leg at the hole on the rear of the product, fix it with enclosed two screws.
- Page 8 Using puripot more effectively To increase the air cleaning efficiency, install puripot in the position facing ※ The two grooves of the bracket are designed to provide two different mounting the window, air conditioner or fan.
- Page 9 AUTO → Lighting 25% → Lighting 50% → Lighting 75% → Lighting 100% → OFF ※ The previous saved settings are valid even after the power of the puripot is 2. AUTO mode turned off and on. When the puripot enters to AUTO mode, upper 3 LED blinks every 1 second in order.
-
Page 10: Air Quality Monitor
Air Quality Monitor Color of Mood Light LED The color of the mood light is also changed to one of the 4 colors based on The F1 series models have a VOC(Volatile Organic Compounds) sensor. the air quality. (F1+ / F1N) It measures the density of the harmful VOC gases in the air. - Page 11 How to clean PCO Mesh Unit FAQs 1. Remove the PCO mesh unit. The power doesn’t turn on. Check if the plug or adapter is properly connected. The mood light does not turn on even when the power is turned on. Check the mood light level.
-
Page 12: Specifications
(Excluding discount or promotional code purchases) If the warranty Air quality monitor period has expired or does not apply to the scope of warranty and restrictions, Dadam Micro Inc. may return the device back to the user. loT function Lighting : 1~4 level...
