Page 1 Model 9641 ICB HV Power Supply User’s Manual 6231711C...
Page 2 Copyright 2016, Mirion Technologies (Canberra), Inc . All rights reserved. The material in this document, including all information, pictures, graphics and text, is the property of Mirion Technologies (Canberra), Inc. and is protected by U.S. copyright laws and international copyright conventions.
Page 3: Table Of Contents
Power Requirements ........................12 Physical............................13 Environmental ..........................13 Cables ............................13 B. Rear Panel Connectors ..............14 HV Output ............................ 14 10 Output ............................14 Inhibit ............................14 ICB Interface Connector ....................... 14 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 4 C. Setup Diagram ................16 D. Installation Considerations ............17 E. FCC Notice ..................18 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 5 Product complies with appropriate current EU directives (Low Voltage & EMC). Product complies with appropriate current FCC /UL / CSA 61010-1 directives (Low Voltage & EMC). Manufacturer’s Address Mirion Technologies (Canberra), Inc. 800 Research Parkway Meriden, CT 06450 USA 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 6 Notes 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 7: Introduction
V and a current level of 1 mA or less. The 9641 allows the user to select from two outputs, one ranging from ±15 to ±2000 V dc and the other derived from the first but attenuated by a factor of 10 giving ±1.5 to ±200 V dc.
Page 8: Controls And Connectors
Chapter 2 Controls and Connectors 2. Controls and Connectors Front Panel This is a brief description of the 9641’s front panel indicators. For more detailed information, refer to Appendix A, Specifications. Figure 1 Front Panel Indicators 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 9: Rear Panel
Rear Panel Rear Panel This is a brief description of the 9641’s rear panel connectors. For more detailed information, refer to Appendix A, Specifications. Figure 2 Rear Panel Connectors 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 10: Internal Controls
Chapter 2 Controls and Connectors Internal Controls This is a brief description of the internal jumpers. For more detailed information, refer to Appendix A, Specifications. Figure 3 Internal Controls 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 11: Operation
NIM Bin which complies with all applicable safety requirements. The Model 9641 can be operated where the ambient air temperature is between 0 °C and +50 °C (+120 °F maximum). Perforations in the top and bottom sides permit cooling air to circulate through the module.
Page 12: Programmable Controls
ICB Address Selection The 9641's ICB address is set using a 16-position PC mounted rotary switch. This switch is accessed through a hole in the left side cover. Using a small screwdriver, set the address to a value of 0-F but unique from other modules connected to the Instrument Control Bus (ICB).
Page 13: Setup
The front panel bar graph will display the HV OUTPUT voltage in kilovolts (kV). Connectors The 9641 has four connectors on the rear panel: HV Output and ÷10 Output, Inhibit, and ICB. HV Output and 10 Output The 9641 has two rear panel output SHV connectors: HV OUTPUT and ÷10 OUTPUT.
Page 14 This input allows an external control signal to enable/disable the HV output. A logic low will disable the output. ICB Connector This connector provides bidirectional data to, and accepts control signals from, the ICB Master. Control of the 9641 is via this port. 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 15: Circuit Description
4. Circuit Description A functional schematic of the Model 9641 can be ordered from Canberra. The high voltage module is basically a dc to dc converter which converts low voltage dc power to a high voltage dc output. This output voltage is highly regulated and filtered, and can be varied by programming the control DAC.
Page 16: Specifications
SHV connector. ÷10 OUTPUT – ±1.5 to ±200 V dc, programmable in 0.195 V increments; output impedance 20 MΩ; rear panel SHV connector. ICB - Provides feedback on the 9641's status: Inhibit, Overload, Polarity, ON/OFF and HV setting. Manual Controls ADDRESS –...
Page 17: Front Panel Indicators
RESOLUTION – 1.95 V increments (0.195 V for the ÷10 output). Connectors HV OUTPUT – Rear panel SHV ÷10 OUTPUT - Rear panel SHV INHIBIT – Rear panel BNC ICB – Rear panel, 20-pin ribbon header. 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 18: Icb Programming Summary
Power Requirements +24 V dc – 15 mA +12 V dc – 55 mA –24 V dc – 10 mA –12 V dc – 50 mA +6 V dc – 350 mA 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 19: Physical
Tested to the environmental conditions specified by EN 61010, Installation Category I, Pollution Degree 2. Cables A 12-port connecting cable is supplied with each Model 556 AIM; if the cable is ordered separately, specify Model C1560 12-port ICB Connecting Cable. 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 20: Rear Panel Connectors
Appendix B Rear Panel Connectors B. Rear Panel Connectors This appendix lists the details of the 9641’s rear panel connector. HV Output SHV connector supplies 0 to 2000 volts adjustable in increments of 1.95 volts. 10 Output SHV connector supplies 0 to 200 volts adjustable in increments of 0.195 volts.
Page 21 LSRQ* OUTPUT (System Request): This signal is set when the slave requires service from the ICB master. 1, 4, 7, DC common for all interface signals. 10, 13, 15, 17, 19 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 22 C. Setup Diagram This block diagrams is included to help you set up your system. Setup Diagram for 9641 Manual 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 23 Any maintenance should be performed by a qualified Mirion Technologies (Canberra) service representative. Operating Protection Impairment Mirion Technologies (Canberra) is not liable for any operational malfunctions or personal injuries due to mishandling or unauthorized repair and maintenance not detailed in this manual.
Page 24 Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. 9641 ICB HV Power Supply User’s Manual – 9231711C...
Page 25 Request for Circuit Information The Schematics and Block Diagrams may be available for this unit directly from Mirion Technologies (Canberra). Request can be made by calling, faxing, or emailing: Training and Technical Services Department Mirion Technologies (Canberra), Inc, 800 Research Parkway, Meriden, CT 06450 Telephone: (800) 255-6370FAX: (203) 639-2067 Email: techsupport@canberra.com...
Page 27 _____________________________________________________ Warranty Mirion Technologies (Canberra) Inc. (we, us, our) warrants to the customer (you, your) that for a period of ninety (90) days from the date of shipment, software provided by us in connection with equipment manufactured by us shall operate in accordance with applicable specifications when used with equipment manufactured by us and that the media on which the software is provided shall be free from defects.
Page 28 Overload, inhibit and polarity ■ level of 1 mA or less. status indicators The Model 9641 allows the user to select from two outputs, Inhibit and overload latching ■ one ranging from ±15 to ±2000 V dc and the other derived circuits from the first but attenuated by a factor of 10 giving ±1.5 to...
Page 29 ■ Voltage Polarity 0.195 V increments; output impedance 20 MΩ; rear panel SHV connector. Inhibit Logic Levels ICB – Provides feedback on the Model 9641’s status: ■ Inhibit, Overload, Polarity, ON/OFF and HV setting. Latch Inhibit Mode manUal ContRolS Latch Overload Mode ADDRESS –...
Page 30 Overload, inhibit and polarity ■ current level of 1 mA or less. status indicators The Model 9641 allows the user to select from two outputs, Inhibit and overload latching ■ one ranging from ±15 to ±2000 V dc and the other derived circuits from the first but attenuated by a factor of 10 giving ±1.5...
Page 31 Mirion products listed herein are registered trademarks or trademarks of Mirion Technologies, Inc. or its affiliates in the United States and other countries. Third party trademarks mentioned are the property of their respective owners.
