Summary of Contents for GTD GTD-W512TX-4
- Page 1 Four-way Wireless Transmitter GTD-W512TX-4 User’s Manual Guangzhou GTD Lighting Technology Co., Ltd. Tel: +86-20-61808296 Fax: +86-20-61812282 www.gtd-lighting.com http://...
- Page 2 © 2017 GTD all rights reserved. Information, specifications, diagrams, images, and instructions herein are subject to change without notice. GTD logo and identifying product names and numbers herein are trademarks of GTD. Copyright protection claimed includes all forms and matters of copyrightable materials and information now allowed by statutory or judicial law or hereinafter granted.
-
Page 3: Table Of Contents
GTD-W512TX-4 User Manual Contents Safety instructions ..................................3 General guidelines ..................................4 Packing and shipping .................................. 4 Unpacking ....................................... 4 Packing after use..................................... 4 Accessories ....................................5 Product introduction .................................. 5 Power / Control connection ............................... 5 Control panel ....................................6 Panel description .................................... -
Page 4: Safety Instructions
GTD-W512TX-4 User Manual Safety instructions WARNING! Before using the fixture, read the latest version of the product user manual, paying particular attention to the safety instructions. Please check www.gtd-lighting.com for the latest revision/update of the user manual. The manufacture of this fixture, are not responsible for damages, resulting from misuse of this fixture, due to the disregard of the information printed in this user manual. -
Page 5: General Guidelines
Broken or damaged cables can only be fixed or changed by certified technicians, certified local distributors or the manufacturer to ensure operational safety. Do not modify the fixture or install other than GTD manufactured parts. For questions regarding safety operation, please contact our technical personnel or call the service hotline +8620 61808296. -
Page 6: Accessories
GTD-W512TX-4 User Manual Accessories Item Unit Notes User Manual 1.5*1.5mm PVC 70 Power cable Notes Accessories are subject to change without any prior written notice. Product introduction Power input Wireless antenna Function button Control Panel DMX input (female) Power/ Control connection The fixture has 5-pin or 3-pin XLR for DMX input and output. -
Page 7: Control Panel
GTD-W512TX-4 User Manual Control panel Panel description LED indicators: Power LED: When power is applied to the fixture, the Red power LED indicator will come on. DMX LED: When the fixture is receiving a DMX signal, the DMX output indicators of each way will come on in Green. -
Page 8: Description Of Wireless Dev Function On Lamp Menu
GTD-W512TX-4 User Manual When ERROR indicator (red) and MODE indicator (green) flash slowly, it means the transmitter enters the receiving mode then you need to make the following settings (Disconnect the power and after 5s or longer, press FUNCTION button and connect the power in simultaneously, making sure the red and green indicator is off continuously). -
Page 9: Method Of Erasing The Connection With The Original Wireless Transmitter (T1) And Reconnecting To A New One (T2)
GTD-W512TX-4 User Manual The second transmitter controls the second set of lamps After the lamps (11-20) are powered on and reset, the display screens on the lamps flash unremittingly, meaning there is no signal and they are waiting for receiving signal. -
Page 10: System Wiring Diagram
GTD-W512TX-4 User Manual Thermal Operating range: 14˚F to 113˚F (-10˚C to +45˚C) Startup range: 5˚F to 113˚F (-15˚C to +45˚C) Storage range: -40˚F to 140˚F (-40˚C to +60˚C) Humidity: ≤85% Transmission distance: 300m (in open space) ... - Page 11 GTD-W512TX-4 User Manual Appendix 1...
- Page 12 GTD-W512TX-4 User Manual Notes: P/N: 1502011070A Time: September 20 , 2017...
