- Page 1 Renaissance Excel 300 Installation Instructions...
- Page 2 This provides detail of the electric installation requirements and procedure, and also important information regarding the operation of the bath. Panel Fitting and Final Finishing – Pages 4-6 Information on panel fitting and the final aesthetic touches to finishing the installation. Excel 300 Installation Instructions – v1.4...
- Page 3 4. If the bath is not level, wind down the grub screws (in the 4 corners of the frame only) in order to lift the bath where required to make it level. At least one corner should remain flush with the Excel 300 Installation Instructions – v1.4...
-
Page 4: Important Notes
• The seat can still be moved outside of the bath • The seat cannot be moved inside of the bath • An audible intermittent beep will be present whenever the bath or seat moves, to indicate that the bath is in ‘emergency’ state Excel 300 Installation Instructions – v1.4... - Page 5 The panel is also secured to the bath framework at the bottom using M6 x 25 countersunk bolts which screw into the threaded holes on the bath frame. These screws are also finished off with a white cap. Woodscrews into timber on bath Countersunk bolts into bath frame Excel 300 Installation Instructions – v1.4...
- Page 6 Step 2. When there is a detachable seat present, it is important that the side panel which contains the pre-fixed magnets is fitted to the ‘seat swing’ side, as shown. ‘Seat Swing Side’ Magnets pre-fitted to side panel Excel 300 Installation Instructions – v1.4...
- Page 7 There should also be a gap of approximately 3mm between the bottom of the panel and the floor. Woodscrews into timber on bath Thread insert in these holes Countersunk bolts into bath frame Excel 300 Installation Instructions – v1.4...
- Page 8 Then using a small amount of silicone to secure it, push the washer down carefully and hold into position. Shaft collar Cover washer Excel 300 Installation Instructions – v1.4...
- Page 9 4. Silicone should also be used around the cover washer to provide a neat finish and to prevent water ingress. 5. Further silicone can also be used around the joint between the rim of the bath and the panels for a neat finish. Renaissance Baths, Pennywell Industrial Estate, Sunderland SR4 9EN Excel 300 Installation Instructions – v1.4...
