NE360 Handheld & Tablet Cases
CT3120 Installation
1
Slide the locking tab on the
payment device case to the
unlocked position using the
provided small screwdriver.
5
Slide the locking tab to the locked
position.
2
Remove the cover from the
payment device case.
CT3121 Installation
6
Slide the locking tab on the
payment device case to the
unlocked position using the
provided small screwdriver.
3
Slide the payment device into the
case.
7
Remove the cover from the
payment device case.
1
4
Replace the cover onto the case.
8
Remove the back cover from the
E285 payment device.
For technical assistance call
NA / LATAM // 704.752.6513 • 888.55.INVUE
EMEA // +31.23.8900150
APAC // +852.3127.6811
