Summary of Contents for Crary Bear Cat DL10
- Page 1 OWNER’S MANUAL 570cc Briggs & Stratton ® P/N: 78449-00 Revision 20230223 Serial Range: N01312 - Current Companion to P/N: 78506-00 BEARCATPRODUCTS.COM// 888.625.4520 ENGLISH...
- Page 2 ® Thank you for purchasing an Crary Bear Cat product. The Crary Bear Cat line is designed, tested, and manufactured to give years of dependable performance. To keep your machine operating at peak efficiency, it is necessary to adjust it correctly and make regular inspections.
- Page 3 In the event of a failure, return the product, at your cost, along with proof of purchase to the selling Crary Bear Cat dealer. Crary Industries, Inc. will, at its option, repair or replace any parts found to be defective in material or workmanship.
-
Page 4: Table Of Contents
TABLE OF CONTENTS SAFETY ................................... 1 1.1 SAFETY ALERT SYMBOL ..............................1 1.2 FIRE HAZARD INFORMATION ............................1 1.3 BEFORE OPERATING ................................1 1.4 OPERATION SAFETY ................................2 1.5 MAINTENANCE/STORAGE SAFETY ..........................2 1.6 SAFETY DECALS ................................. 3 1.7 SAFETY DECAL LOCATIONS ............................. 4 ASSEMBLY................................ -
Page 5: Safety
SAFETY Section equipment in affected areas, it must be equipped with a 1.1 SAFETY ALERT SYMBOL spark arrestor in continuous effective working order. The spark arrestor must be attached to the engine exhaust system in such a manner that flames or heat from the system will not ignite flammable material. -
Page 6: Operation Safety
SAFETY 7. Do not operate this equipment in the vicinity of 5. Check rotor housing to verify it is empty before bystanders. Keep the area of starting the machine. operation clear of all persons, 6. The fan will continue to rotate after being disengaged. particularly small children. -
Page 7: Safety Decals
SAFETY 5. Never store this machine with fuel in the fuel tank inside a building where fumes may be ignited by an open flame or spark. Ignition sources can be hot water and space heaters, furnaces, clothes dryers, stoves, electric motors, etc. 6. -
Page 8: Safety Decal Locations
SAFETY 1.7 SAFETY DECAL LOCATIONS The numbers below correspond to the decals in Section 1.6. Make certain that all safety and operating decals on this machine are kept clean and in good condition. Decals that need replacement must be applied to their original locations. 10 INCH VACUUM SHREDDER... -
Page 9: Assembly
ASSEMBLY Section WARNING If any bolts or nuts are dropped in the machine, be sure to remove them before starting the machine. 2.1 ATTACH VACUUM HOSE 1. Attach the hose assembly (1) to the fan intake weldment with the two provided knobs (2) and 5/16" × 3/4" carriage bolts (3). -
Page 10: Attach Discharge Tube
ASSEMBLY 2.2 ATTACH DISCHARGE TUBE 2.3 ADD OIL TO ENGINE 1. Loosely assemble spacers (3) and one clamp (2) Check the oil level and, if needed, fill the engine crankcase to the discharge tube (5) using two knobs (4) and with the type and amount of oil specified in the engine carriage bolts (1). -
Page 11: Features & Controls
FEATURES & CONTROLS Section Understanding how your machine works will help you achieve the best results when using your vacuum shredder. The following descriptions define the features and controls of your machine. REFER TO ENGINE OWNER’S MANUAL FOR FURTHER ENGINE OPERATING INSTRUCTIONS. 1. -
Page 12: Operation
OPERATION Section 10. Gradually move the choke lever to the OFF position WARNING as the engine warms. 11. Gradually move the throttle to the full throttle position. Before operating your machine, be sure you read and understand all safety, controls and operating 4.3 STOPPING THE MACHINE instructions in this owner’s manual and on your machine. -
Page 13: Service & Maintenance
SERVICE & MAINTENANCE Section 5.1 MAINTENANCE SCHEDULE The items listed in this service and maintenance schedule WARNING are to be checked, and if necessary, corrective action taken. This schedule is designed for units operating under To prevent personal injury or property damage: shut normal conditions. -
Page 14: Replacing The Wear Liner
SERVICE & MAINTENANCE WARNING BEFORE INSPECTING OR SERVICING ANY PART OF THIS MACHINE, SHUT OFF POWER SOURCE, AND MAKE SURE ALL MOVING PARTS HAVE COME TO A COMPLETE STOP. 5.4 REPLACING THE WEAR LINER The fan housing wear liners are replaceable. To replace 4. -
Page 15: Lubrication
Visit https://qrco.de/CBCGreaseZerks to learn how to properly locate grease points and grease your Crary Bear Cat machine for maintenance. -
Page 16: Troubleshooting
Section Before performing any of the corrections in this troubleshooting chart, refer to the appropriate information contained in this manual for the correct safety precautions and operating or maintenance procedures. Contact your dealer or Crary Bear Cat for service problems with the machine. -
Page 17: Specifications
SPECIFICATIONS Section DESCRIPTION ENGLISH METRIC Engine Briggs & Stratton Vanguard 570cc ® ® Hose size 10" diameter × 12.5' 25.4 cm diameter × 3.8 m Fan size 16.25" × 6.13" 41.3 cm × 15.6 cm Discharge size 8" diameter 20.3 cm diameter Discharge rotation 360 degrees Maximum CFM (cubic ft./min) -
Page 18: Bolt Torque
SPECIFICATIONS 7.1 BOLT TORQUE The tables below are for reference purposes only and their use by anyone is entirely voluntary, unless otherwise noted. Reliance on their content for any purpose is at the sole risk of that person and any loss or damage resulting from the use of this information is the responsibility of that person. -
Page 19: Parts & Options
8.1 REPLACEMENT PARTS FOR MACHINE SERVICE OR PARTS For service assistance, contact your nearest authorized Crary Bear Cat dealer or the factory. For parts, contact your authorized dealer. The parts manual for your machine is available at bearcatproducts.com/Product-Support/Find- A-Product-Manual. Your dealer will need to know the serial... - Page 20 • 237 12th St. NW, West Fargo, ND 58078 ® ® For customer service or for your nearest Crary Bear Cat dealer call 888.625.4520 | For International call 701.282.5520 BEARCATPRODUCTS.COM ©2023 Crary Bear Cat, a subsidiary of Crary Incorporated. All Rights Reserved. Printed in the U.S.A...
