Amphenol K2100E100 Quick Start Manual

This shipment contains ______ K2100E100 Shaker kit(s).
Each kit includes one of each item in this section as noted.

Available Accessories/Options

_____ 2050A Lateral Excitation Stand
_____ PCB 288D01 ICP® Impedance Head
_____ PCB 208 Series ICP® Force Sensors. Indicate Model: __________________
_____ Type 2120Gxx threaded (10-32) stainless steel rod stingers.
_____ Model 8032S Air Ride Test Support
DS-0156 revB
K2100E100 Shaker Kit Selection and Quick Start Guide
2100E11 Shaker mounted
on trunnion base with
EasyTurn™ handles.
Typically ships in Pelican
case (2100E20). Cable to
amplifier included.
2100E18 Amplifier with
power cord. Used for 100 lbf
output.
☐
120 V
_____ Power Plug Type
2000X04 Cooling vacuum for
2100E11 shaker. Includes
vacuum hose, adaptors, and
muffler.
115 V/60 Hz ☐
230 V/60 Hz ☐
230 V/50 Hz ☐
_____ Power Plug Type
Job # _______________________________
Customer ____________________________
_____ 2100E11-001 Shaker accessory kit. Includes:
1
2
3
4
5
6
7
8
9
10
11
12
13
☐
230 V
14
15
16
17
18
Circle length:
www.modalshop.com | 513-351-9919 | rentalteam@modalshop.com
Stinger Kit 2155G12 - 3/32"
Stinger Kit 2150G12 - 1/16"
Stinger Thumb Nuts (qty 6)
K2160G - Piano Wire Stinger Kit
5.5 mm Wrench and Turnbuckle
M6 Nuts (qty 5)
Two-part Chuck
M6 to 10-32 Adaptor
Hex Wrench
Flexure Supports (qty 16)
Hex Wrench
0.5 mm Collet
1.0 mm Collet
1.6 mm Collet
2.5 mm Collet
3.5 mm Collet
Fuse (qty 2)
Wrench – 13mm (qty 2)
9" 12" 18"
