Important notes
• Shunt (or terminal) truck required
• Only trained and authorized shunt truck operators may use this product
• Product intended to prevent trailer up-ending and tip-over by shouldering the
weight in heavy-duty loading dock environments
• Use only original Ideal Warehouse Innovations, Inc. parts to service this product
Before you begin
• Complete a visual inspection of the Shuntable 2.0 Trailer Stand and Lifting
Device for any obvious maintenance issues
• Check that the area is clear and safe before moving the Shuntable 2.0 Trailer
Stand
Shuntable 2.0 Trailer Stand
Operator instructions
Original Instructions
1-866-828-6737 idealwarehouse.com 2023-02-24
Advertisement
Summary of Contents for Ideal Warehouse Shuntable 2.0
- Page 1 Before you begin • Complete a visual inspection of the Shuntable 2.0 Trailer Stand and Lifting Device for any obvious maintenance issues • Check that the area is clear and safe before moving the Shuntable 2.0 Trailer Stand 1-866-828-6737 idealwarehouse.com 2023-02-24...
-
Page 2: Operation
Operation Step 1: Start with the lifting arm in the down position, approach the trailer stand square, straight and with the two orange flag markers lined up. The orange markers will allow you to be as centered as possible on the lifting device. Step 2: Drive in slowly and touch the trailer stand with the bottom pusher bar of the lifting device. - Page 3 Step 4: Drive up to the front nose of a trailer slowly, square, straight and parallel. Position the trailer stand approximately in the center of the trailer. When you are about 1 foot away from the trailer, stop. Press the down rocker switch on the dash of the shunt truck for approximately 4 seconds.
- Page 4 Removing the Shuntable 2.0 Trailer Stand • Approach the trailer stand square, straight, as parallel as possible and with the two orange flag markers lined up. The lifting arm should be in the down position at this time. • Idle forward slowly until the bottom pusher bar of the lifting device touches the trailer stand gently.
- Page 5 Shuntable 2.0 Trailer Stand Parts Listing DESCRIPTION QTY. SHUNTABLE 2.0 WELDMENT STS LAMINATED BUMPER ASSEMBLY LAMINATED RUBBER BUMPER LVB410-12 ALIGNMENT FLAG, 48" 3M REFLECTIVE STICKER REFLECTIVE STICKER SHUNTABLE 2.0 LABEL WASHER, 3/4" LOCKNUT, 3/4"-10 LOCKNUT, 1/4"-20 HEX HEAD BOLT, 1/4"-20 x 1" LG.
- Page 6 Lifter Device Parts Listing DESCRIPTION QTY. SHUNTABLE 2.0 LIFTING FRAME LIFTING BAR CONTROL BOX ASSEMBLY WINCH COVER TYCO AND CAPACITY MOUNTING PLATE ALIGNMENT FLAG, 36" WINCH STRAP SMALL SHUNTABLE STICKER SERIAL NUMBER STICKER CONTROL BOX STICKER WINCH ROUND REFLECTOR STICKER...
- Page 7 Test the lifting device by lifting the Shuntable 2.0 trailer stand. Does the limit switch turn off the lifting motor when the trailer stand reaches its upper most travel off the ground? The motor should not be running if the trailer stand has reached its hard stop.
- Page 8 Ideal Warehouse Innovations, Inc. No person is authorized to give any other warranties or to assume any other liability on behalf of Ideal Warehouse Innovations, Inc. unless made or assumed in writing by Ideal Warehouse Innovations, Inc.
