Curved Back Sofa
BEFORE ASSEMBLING:
Ensure all hardware and pieces are removed
from the packaging before discarding the box.
Make sure all pieces are accounted for before
beginning installation.
To protect your piece, we recommend
assembling it on a blanket or a flattened box.
Pay close attention to all holes on each panel as
they are directional. Follow the included
diagrams closely.
Components List
No. Description
Sketch
Sofa back
A
and seat
cushion
B
Front legs
C
Back legs
D
Bolt *60mm
E
Flat Washer
F
Spring Washer
G
Bolt *30mm
H
Allen Key
Questions? Contact support@steadfurniture.com
Assembly Instructions
STEP 1
Lay seat (A) on a soft surface
Qty
STEP 2
01
Attach front legs (B) with 5 bolts (D), 5 spring washers (F), and 5 flat washers (E), in the center of the
01
frame, using the allen key (H) to tighten
02
05
07
07
02
01
A
E
E
B
F
F
D
D
G
H
PAGE 1/3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for stead Curved Back Sofa
Summary of Contents for stead Curved Back Sofa
- Page 1 Curved Back Sofa Assembly Instructions BEFORE ASSEMBLING: STEP 1 Ensure all hardware and pieces are removed Lay seat (A) on a soft surface from the packaging before discarding the box. Make sure all pieces are accounted for before beginning installation.
- Page 2 STEP 3 Attach the corner brackets on the front legs (B) with 2 bolts (G), 2 spring washers (F), and 2 flat washers (E), using the allen key (H) to tighten STEP 4 Attach back legs (C) turn clockwise to tighten Questions? Contact support@steadfurniture.com PAGE 2/3...
- Page 3 FINISH Flip over, sit down, and enjoy! Questions? Contact support@steadfurniture.com PAGE 3/3...
