Page 2 Table of contents General instructions Installation instructions Product description Service and support Maintenance Appendix System Documentation © InoNet Computer GmbH...
Page 3: Qualified Personnel
No claims for changes to products already supplied can be made on the basis of the information, illustrations and descriptions in this documentation. System Documentation © InoNet Computer GmbH...
Page 4 If multiple levels of risk occur, the warning is always used for the highest level. If a warning triangle warns you of a personal injury, you may also be alerted against damage in the same warning message. System Documentation © InoNet Computer GmbH...
Page 5: Installation
"do not open". 7. Installation The installation of the device must be carried out in accordance with local/regional electrotechnical regulations for the installation of data processing facilities by qualified and authorized personnel. System Documentation © InoNet Computer GmbH...
Page 6 Do not operate the device if the humidity is outside the limits specified in the user manual. 13. Liability The manufacturer assumes no liability for any damage caused by non-observance of the operating instructions. System Documentation © InoNet Computer GmbH...
Page 7: Operating Personnel Requirements
The operator shall ensure that only sufficient qualified and authorized personnel open the housing. 1.8 Operating personnel requirements Every user of the industrial PC must have read these operating instructions and know all the functions of the software installed on the System Documentation © InoNet Computer GmbH...
Page 8 Avoid extreme environmental conditions as far as possible.  Protect your equipment from moisture, dust and heat, as well as shock  and vibration. Do not expose your system to direct sunlight.  System Documentation © InoNet Computer GmbH...
Page 9 2.4 Extension/upgrading of the system If your system is equipped with your own expansion cards, it is important to pay attention to the ESD protection! Please also note the additional manuals included with the expansion cards. System Documentation © InoNet Computer GmbH...
Page 10: Requirements For Commissioning
Before you switch on the system, the peripheral devices mouse, keyboard, monitor as well as the power supply must be connected. Since the system is designed for headless operation in the vehicle, these components are optional. System documentation © InoNet Computer GmbH...
Page 11: Connecting Devices
 Connect the keyboard/mouse or a KVM device to the ports of the device. If necessary, secure the cables against unintentional disconnection.  Connect the monitor cable or KVM device to the connector of the graphics port. Tighten the screws of the monitor cable hand-tight. System documentation © InoNet Computer GmbH...
Page 12: Switching On For The First Time
 Now the computer runs through the power on self test. The BIOS boot message then appears on the screen. If the computer does not report on the screen, please check the cabling again and make sure that the sockets carry power. If this also System documentation © InoNet Computer GmbH...
Page 13: Switch Off
According to the Electrical and Electronic Equipment Act (ElektroG) applicable in Germany, every manufacturer is obliged to provide a reasonable opportunity for the return of old equipment from users other than private households. System documentation © InoNet Computer GmbH...
Page 14 2. Installation Possibility to return and dispose of old equipment You can professionally recycle an electrical device purchased from InoNet Computer GmbH by commissioning a transport company of your choice or a suitable parcel service at your expense and returning the old electrical devices to us for recycling.
Page 15 Power supply QuickTray ® Interfaces Description RS-232 port 2x USB 3.0 port 2x USB 3.0 port 1Gbps LAN RJ-45 connector for IPMI/BMC (management port) 1Gbps LAN RJ-45 connector (LAN1) 1Gbps LAN RJ-45 connector (LAN2) System documentation © InoNet Computer GmbH...
Page 16 VGA port. A VGA monitor can be connected here if there is no other graphics card installed in the system. UID/BMC reset button Elements on the back Description Control panel and connection panel for liquid cooling System documentation © InoNet Computer GmbH...
Page 17 Activity of the onboard LAN adapter 1 is displayed. LED LAN 2 (green) Activity of the Onboard LAN Adapter 2 is displayed. LED Power (white/blue) This LED lights up when the system is switched on. System documentation © InoNet Computer GmbH...
Page 18  Designed as a screw connection with M8 screw. The connection cable is screwed on here with a ring cable lug. It must be ensured that the insulation underneath the cable lug is completely removed. System documentation © InoNet Computer GmbH...
Page 19  Position "0" - device is disconnected from the power supply.  Position "1" - device is supplied with power, power button is active. Power supply connection  IEC socket according to EN 60 320 / C19 System documentation © InoNet Computer GmbH...
Page 20 System disk An M.2 NVMe slot is available on the mainboard, which is usually occupied by the operating system SSD. System documentation © InoNet Computer GmbH...
Page 21 The expansion tank of the combination has a slotted G1/4" blind plug on its upper side. This plug must be removed (with a coin or similar) to refill System documentation © InoNet Computer GmbH...
Page 22 The correct fluid level is reached when no more coolant can be filled into the expansion tank. Operation of the external radiator/pump combination For more detailed information on the operation of the external radiator/pump combination, please refer to the manufacturer's documentation: Manual Koolance ALX Series. System documentation © InoNet Computer GmbH...
Page 23 2. Set the time or date in the Setup not correct menu. Time/date are Buffer battery is In this case, contact our service incorrect even empty department. after correct setting in BIOS setup System Documentation © InoNet Computer GmbH...
Page 24 4.2 Spare parts & accessories A large number of accessories and spare parts are available for your computer system. Please contact our service department if necessary. E-Mail: support@inonet.com Tel: +49 (0)89 / 666 096-40 System Documentation © InoNet Computer GmbH...
Page 25 7. If the warranty has expired, we will contact you and you will receive a cost estimate. 8. If you accept it, we will repair the device and send it back to you. See also: https://www.inonet.com/unternehmen/kontakt/ System Documentation © InoNet Computer GmbH...
Page 26 Storage drives with removable media should also be cleaned regularly to ensure reliable operation. Only use the accessories recommended by the manufacturer of the drive. If you have questions about this topic, contact your supplier or the drive manufacturer. System Documentation © InoNet Computer GmbH...
Page 27: Inspection And Maintenance Schedule
Type Interval Execution test on: semi- Hard disks Functional test annually Visual and semi- Fans functional check annually BIOS Voltage check yearly battery every two Chassis Cleaning years Liquid Visual inspection monthly cooling level System Documentation © InoNet Computer GmbH...
Page 28 Outside in radiator/pump combination expansion tank and pump Certified Microsoft ® Windows 10/11 Enterprise (64 bit) operating Microsoft ® Windows Server 2016/2019/2022 (64 bit) systems Microsoft ® Hyper-V Server 2019 (64 bit) Linux , VMWare ® ® System documentation © InoNet Computer GmbH...
