Summary of Contents for Whittemore Enterprises Inc. WE-200
- Page 1 Whittemore Enterprises, Inc. 11149 Arrow Route Rancho Cucamonga, CA 91730 909-980-2452 - 800-999-2452 Fax 909-989-9976 WE-200 VIDEO ENDOSCOPE OPERATION MANUAL...
- Page 2 CONTENTS Endoscope Nomenclature Pg. 2 Leak Test Preparation Pg. 3 Cleaning and Disinfecting Pg. 4 Endoscope Specifications Pg. 5 WE-200 Setup Pg. 6 WE-200 Bulb Replacement Pg. 6 WE-200 Functions and Features Pg. 7...
- Page 3 Endoscope Functions and Features...
- Page 4 Preparing the endoscope for leak testing Before Leak Testing, remove the (optional) LCD screen. Then screw on the water-resistant cap attached the top of operating handle. Leak Testing...
- Page 5 Cleaning and Disinfecting Endoscopes Always attach the water resistant cap and leak tester before leak testing and cleaning! Dry Leak Test : Attach leak tester to endoscope connector, tighten knob, pump until dial is at 12:00 position, if dial remains in place for 2 minutes, there are no leaks.
- Page 6 Plug the endoscope light guide connector into the WE-200 and plug the water bottle into the water bottle connection. Attach the air / water cleaning adapter cap (attached to the diagram card) to the air / water cylinder.
- Page 7 WE-200 Semi Portable Processor / Light Source The WE-200 processor is a combination of image, light and air. The digital images are reproduced in very high resolution. The outputs on this device enable the video image to be sent to a variety of displays.
- Page 8 Air Output: When the endoscope is connected to the WE-200 and the pump switch is in the ON position the air and water feature is enabled.
