Airbag

High strength

zone

DO NOT CUT ANY ORANGE COLORED HIGH VOLTAGE CABLES.

CADILLAC LYRIQ

5 Door Hatchback

2023 -

Stored gas inflator

Battery low voltage

Seat belt

SRS control unit

pretensioner

High voltage

High voltage power

battery pack

cable component

Identification Number

1GY-22101

Gas strut/

Preloaded spring

Cable Cut Location

Version Number

Page Number

Page 1 of 4

Table of Contents

Need help?

Do you have a question about the LYRIQ 2023 and is the answer not in the manual?

Page 1 CADILLAC LYRIQ 5 Door Hatchback 2023 - Seat belt Gas strut/ Airbag Stored gas inflator SRS control unit pretensioner Preloaded spring High voltage High voltage power High strength Battery low voltage Cable Cut Location zone battery pack cable component Identification Number...
Page 2 1. Identification / recognition Lack of engine noise does not mean vehicle is off: vehicle movement capability exists until vehicle is fully shut down. Always wear appropriate PPE. Emblems and Badging First Responder Information Label 2. Immobilization / stabilization / lifting IMMOBILIZE VEHICLE: 1.
Page 3 VEHICLE AT CHARGE STATION: If able, terminate charging by removing the charge handle from the vehicle. If enabled, the vehicle’s anti-theft alarm may activate. If the charge handle will not release, a manual release loop is located underhood, near the First Responder Information label under an access panel.
Page 4 Potential for Battery Re-Ignition. 7. In case of submersion The high voltage battery is isolated from the vehicle chassis. If the vehicle is immersed in water, you will not be electrocuted by touching the vehicle. After the vehicle was removed from the water, do the following: Allow the vehicle to dry out.
