On-Board Programming
Step 1. Begin Program Mode
A.
Press Enter
Step 2. If Ring Down (No Dial Tone)
A.
Press 1, 9, Enter, 2
Note: This will automatically set the Timer for 3 minutes
*Skip Step 3
Step 3. Program Emergency Numbers
A.
Press 1, Enter, (Phone Number), Stop
Note: Press 2-5 In Step 3A For Emergency Numbers
2-5 As Needed
Step 4. Program Location Message
A.
To Turn On Message Press 1, 3, Enter, 2
B.
Press 6, Record, (Speak Your Message), Stop
(To Replay Message Press 6, Play/Pause)
C.
Program Frequency of Message Press 1, 3, Enter, _
1= Plays Message (1) Time
2= Plays Message (2) Times (Default)
3= Plays Message Until Receiving Party Presses *
On Their Phone
D.
For No Message Press 1, 3, Enter, 0
Step 5. Program Talk Timer
A.
Press 8, Enter, (3 Digit Number in Minutes)
Ex: 2 Minutes = 002
Note: After Talk Timer Expires, Phone Will Prompt Called Party
to Extend Call for 3 Minutes
Step 6. Change Telephone Security Code (Default 1111)
A.
Press 2, 2, Enter, (Desired 4-digit code)
Note: Cannot Be 0000
Step 7. To Exit Program Mode
A.
Press Stop For 3 Seconds
SmartPhone VI Consolidator Feature (Capability of 10 Phones/One Line)
Step 1. Begin Program Mode
A.
Press Enter
Step 2. Program ID Numbers for Phones 1-5
A.
Press 7, Enter
B.
Press *, 1-5 For Corresponding Elevator (1-5)
Step 3. Program ID Numbers for Phones 6-10
A.
Press 7, Enter
B.
Press #, 1-5 For Corresponding Elevator (6-10)
Made in the USA
3 Year Warranty
Standard Operations
(Detailed Programming Instructions)
N56 W24720 N. Corporate Circle
800-451-1460
262-246-4828 (fax)
Remote Programming
Step 1. Begin Program Mode
A.
Call Into Phone
B.
After 1st Simulated Ring Press #, #
C.
Key in Security Code (Default is 1111)
Step 2. If Ring Down (No Dial Tone)
A.
Press 1, 9, *, 2
Note: This will automatically set the Timer for 3 minutes
*Skip Step 3
Step 3. Program Emergency Numbers
A.
Press 1, * (Phone Number), *, #
Note: Press 2-5 In Step 3A For Emergency Numbers
2-5 As Needed. For "Pause" Press #, *
Step 4. Program Location Message
A.
To Turn On Message Press 1, 3, *, 2
B.
Press 6, *, (Speak Your Message), #, *, #
(To Replay Message Press 6, #)
C.
Program Frequency of Message Press 1, 3, *, _
1= Plays Message (1) Time
2= Plays Message (2) Times (Default)
3= Plays Message Until Receiving Party Presses *
On Their Phone
D.
For No Message Press 1, 3, *, 0
Step 5. Program Timer
A.
Press 8, *, (3 Digit Number in Minutes)
Ex: 2 Minutes = 002
Note: After Talk Timer Expires, Phone Will Prompt Called
Party to Extend Call for 3 Minutes
Step 6. To Exit Program Mode
A.
Press *, #, 0 (You Will Hear Beep, Beep) *, #
Step 4. Program Emergency Numbers
A.
Press Stop For 3 Seconds
Step 5. Confirm Consolidator Operation
A.
Dial Phone Number SmartPhones are Installed on:
All Phones Will Answer
B.
To Select Individual Phone
Press *1 (Phone #1) Press #1 (Phone #6)
Press *2 (Phone #2) Press #2 (Phone #7)
Press *3 (Phone #3) Press #3 (Phone #8)
Press *4 (Phone #4) Press #4 (Phone #9)
Press *5 (Phone #5) Press #5 (Phone #10)
Press *0 (All Phones)
Sussex, WI 53089
www.rathmicrotech.com
SmartPhone VI
RP8200910
Revision 1
05/10
