KNOW YOUR PRODUCT
AIR HYDRAULIC
RIVETER
• SUITS 2.4 / 3.2 / 4.0 /
4.8 MM RIVETS
• 11KN PULL FORCE
• 17MM STROKE LENGTH
• 1/4 NITTO STYLE MALE
SWIVEL CONNECTOR
INSTRUCTION MANUAL
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electrical shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
0721
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Full Boar FBAHR-032
- Page 1 KNOW YOUR PRODUCT AIR HYDRAULIC RIVETER • SUITS 2.4 / 3.2 / 4.0 / 4.8 MM RIVETS • 11KN PULL FORCE • 17MM STROKE LENGTH • 1/4 NITTO STYLE MALE SWIVEL CONNECTOR INSTRUCTION MANUAL WARNING: Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electrical shock, fire and/or serious injury.
-
Page 2: Specifications
SPECIFICATIONS - MODEL NO. FBAHR-032 Blind Rivet Capacity: 2.4, 3.2, 4.0, 4.8 mm Stroke Length: 17mm Pull Force: 8.1-11 Kn Air Inlet: 1/4 Nitto Style Male Swivel Connector Operating Pressure: 5 - 7 bar (72.5 - 101.5 psi) Maximum Pressure: 7 bar (101.5 psi) - Page 3 KNOW YOUR PRODUCT 1. 4.8 mm Nose Piece 5. Handle 2. Trigger 6. Hydraulic Revisor 3. Air Cylinder 7. Rivet Barrel 4. 1/4 Nitto Style Male Swivel Connector...
-
Page 4: Table Of Contents
TABLE OF CONTENTS SPECIFICATIONS............Page 02 KNOW YOUR PRODUCT........... Page 02 INTRODUCTION............Page 05 SAFETY INSTRUCTIONS........... Page 06 SET UP AND PREPARATION........Page 10 OPERATION............... Page 12 MAINTENANCE............Page 13 TROUBLE SHOOTING ..........Page 14 DESCRIPTION OF SYMBOLS........Page 15 CONTENTS.............. -
Page 5: Introduction
INTRODUCTION Congratulations on purchasing a Full Boar Air Hydraulic Riveter. Fitted with a powerful hydraulic piston to handle various tasks such as assembly and repairs in the workshop or work site. Read and understand the Owner’s Manual before operating the Hydraulic . -
Page 6: Safety Instructions
GENERAL AIR TOOL SAFETY WARNINGS WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. 1. Work area safety a. - Page 7 GENERAL AIR TOOL SAFETY WARNINGS (cont.) such cases of misuse. • Please read and observe these operating instructions before using the tool. Basic safety measures should always be strictly followed to protect against damage to the equipment and personal injury to the user or other people working in the vicinity of operation.
- Page 8 AIR HYDRAULIC RIVETER SAFETY WARNINGS WARNING! Disconnect the tool from the air supply before inspecting the air tool. Failure to do so could result in serious personal injury. • Read and understand instruction manual before using. • Always wear impact-resistant eye protection during the operation of the air tool.
- Page 9 AIR HYDRAULIC RIVETER SAFETY WARNINGS • Check prior to each operation that the safety and triggering mechanism is functioning properly and that all nuts and bolts are tight. • Do not carry out any alterations to the air tool. • Avoid weakening or damaging the tool, for example by: –...
-
Page 10: Set Up And Preparation
KNOW YOUR PRODUCT SET UP & PREPARATION WARNING! Ensure the tool is in the off position before connecting to the air supply. Connecting air supply 1. Wrap Teflon tape (not supplied) around the Nitto Style Fitting approximately 4 to 5 times to ensure a leak free seal. 2. - Page 11 KNOW YOUR PRODUCT SET UP & PREPARATION (cont.) WARNING! Do not attempt to modify this tool or create accessories not recommended for use with this tool. Any such in a hazardous condition leading to possible serious personal injury. Changing Air Riveter Nose Piece 1.
-
Page 12: Operation
OPERATION Driving Rivets 1. Select the nose piece you require for the size of rivet being used. 2. Using a drill, drill into the material you wish to rivet. Note: When drilling rivet holes, use the same diameter drill bit as the outer diameter. -
Page 13: Maintenance
KNOW YOUR PRODUCT MAINTENANCE General Cleaning • If the enclosure of the tool requires cleaning, do not use solvents but a moist soft cloth only. Never let any liquid get inside the tool; never immerse any part of the tool into a liquid. •... -
Page 14: Trouble Shooting
KNOW YOUR PRODUCT TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY Air leak near the top of Loose screws Tighten screws the tool or in the trigger area. Warn or damaged Check and replace o-rings or seals O-rings Air leak near the base of Loose screws Tighten screws the tool... -
Page 15: Description Of Symbols
DESCRIPTION OF SYMBOLS Revolutions or reciprocations /min No load speed per minute Wear eye, ear & breathing Wear hearing protection protection Wear breathing protection Wear eye protection Read Instruction Manual Warning CARING FOR THE ENVIRONMENT Power tools that are no longer usable should not be disposed of with household waste but in an environmentally friendly way. -
Page 16: Contents
CONTENTS KNOW YOUR PRODUCT 1 x Hydraulic Air Riveter 1 x Hydraulic Oil Syringe 1 x Spanners 4 x Nose Pieces Note: The manufacturer’s liability shall be deemed void if the tool is modified in any way and the manufacturer shall therefore accept no liability for any damages arising as a result of modifications. -
Page 17: Warranty
WARRANTY YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS WAREHOUSE (see www.bunnings.com.au or www.bunnings.co.nz for store locations) WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE: Australia 1800 951 371 New Zealand 0800 647 840...
