Summary of Contents for MMB Thread Mesh Extender
- Page 1 MMB Thread Mesh Extender Quick Start Guide March 8, 2023 MMB Networks 25 Adelaide St. E, Suite 400 Toronto, Ontario, Canada M5C 3A1 (416) 636-3145...
- Page 2 Consult the dealer or an experienced radio/TV European Health and Safety Compliance (CE) technician for help. The MMB TME device has been tested against the relevant harmonized/designated standards and are in conformity Federal Communications Commission (FCC-US): with the essential requirements and other relevant This device complies with Part 15 of the FCC rules.
-
Page 3: Getting Started
Getting Started Guide | MMBNetworks.com/mmb-tbr Getting Started MMB TME Device Overview Box Contents 1. MMB TME Device 2. USB-C Power Adapter 3. Screws and wall plugs 4. Mounting guide Rev 0.2 MMB Networks 2023 QSG MMB TME | 3... - Page 4 Joined to a Thread Network Device Control Using Front Panel Buttons (on MMB TME only) Start Thread Factory Reset on Mesh Joiner with PSKD (Press > 20 seconds) (Toggle: Press < 2 seconds) Rev 0.2 MMB Networks 2023 QSG MMB TME | 4...
- Page 5 Thread network’s on or off mesh commissioner. 4. On the rear of the MMB TME, connect the USB-C- Power Adapter. Wait for the Status LED to turn Solid Green. Rev 0.2 MMB Networks 2023 QSG MMB TME | 5...
- Page 6 - if so, you can press the ‘Thread ON/OFF’ button to re- enter the joiner mode. 6. The TME’s ‘Thread Network’ LED will light solid when joining is complete. Rev 0.2 MMB Networks 2023 QSG MMB TME | 6...
-
Page 7: Mounting Instructions
Placement and Orientation The MMB TME can be mounted on walls or ceilings. The ideal orientation is vertically on a flat wall, with Power and Ethernet cables facing down. A clearance of 2cm on all sides should be maintained. -
Page 8: Installing The Mounting Bracket
MMB TME in mounting bracket. respect to the Mounting bracket can be seen below. When choosing a location for the mounting bracket, ensure final placement of the device is not obstructed. Rev 0.2 MMB Networks 2023 QSG MMB TME | 8... - Page 9 Do not overtighten screws. Screws must be flush with the mounting bracket. Use # 4 Flat Head screws only. The mounting bracket should be level and installed flush to the wall or ceiling surface material. Rev 0.2 MMB Networks 2023 QSG MMB TME | 9...
- Page 10 Once the mounting bracket is correctly installed, and with Ethernet and Power cables connected to the MMB TME, slide the MMB TME onto the bracket from left to right to mount. Rev 0.2 MMB Networks 2023 QSG MMB TME | 10...
