Summary of Contents for BRN babyway
- Page 1 MANUAL...
-
Page 2: Prior To Assembly
MANUAL Please keep this Owner’s Manual for future reference. PRIOR TO ASSEMBLY Please read this Owner’s Manual completely before assembling or operating this pro- duct. This product should be assembled by an adult. IMPORTANT SAFETY INFORMATION Meets ASTM /ENStandards: F1975-09/ EN 15918Bicycle Trailer Designed for Human Passengers F833-13b/EN 1888 Safety Performance Specifications for Carriages and Strollers Certified by Mechanicals and Hardgoods Lab. - Page 3 SAFE TOWING TIPS • WARNING Make sure your bike brakes work properly! Braking distance is increased when pulling a trailer! • WARNING This trailer is wide! Allow extra clearance near curbs, signs, parked cars, and other obsta- cles! • WARNING A bicycle with trailer attached requires a wide turning radius! Do not turn sharply! •...
-
Page 4: Key Features
Please Read all instructions and examine contents carefully before assembly. Impor- tant – Keep these instructions for future reference. Key Features • Quick Assembly, take down and storage • Forward facing two passenger seating • Five-point seating harness with quick lock and release •... -
Page 5: Safety Guidelines
Inspect bike and trailer condition before each use HELMETS ON! Insure rider and child helmets are on and secure Check tire air pressure. Always maintain between 35 and 40 PSI The bicycle to which the trailer will be attached should be inspected by a qualified bicycle mecha- nic before attaching the trailer to it. - Page 6 • Never assume you will be given the right of way. • Do not try to predict the actions of car drivers. • Do not travel on highways, busy streets, or in areas unsafe for bicycling. • Avoid riding at night. If you must ride at night, use lights and bright, reflective clothing.
- Page 7 MAIN CABIN FRAME AND ASSEMBLY Remove the trailer, wheels, hitch arm and walking kit from the box. Set the walking kit small swivel wheel aside, as you will install this later. Lay the trailer on the ground with the black fabric side down.
-
Page 8: Installing Wheels
INSTALLING WHEELS Your Kuji trailer uses simple and convenient push button qui- ck-release wheels. To install the wheel, first push the button on the outside of the wheel hub, and insert the axle through the hanger bracket on the frame as shown. Push all the way in and release the pushbutton. -
Page 9: Parking Brake Operation
Depress the spring pin and insert the hitch arm in the bracket on the frame as shown. Once the spring pin locks in place in the hole in the bracket, Locate the quick release pin, attached by nylon strap to the trailer frame, then Insert the pin through the bracket and into the hole in the tow arm. The pin should go completely through the tow arm and bracket. -
Page 10: Installation
INSTALLING WHEEL GUARD Your trailer is equipped with a wheel guard for added safety. The wheel guard helps to deflect the tire from obstructions that might stop the trailer and result in an accident. Installing the wheel guard Hex Key 1 ea / Screws 4 ea / Wheel guard 2 ea Installation Unpack polybag and check that all parts are included located the 2 holes in the front of the side frame, just in front of the wheel. - Page 11 USING FIVE-POINT HARNESS Unclip the straps and place your children in the seat(Fig1). Adjust the upper buckles to fit snugly above your child’s shoulders (Fig2). The crotch strap buckle should come just below your child’s belly button, where a normal belt could lay. Adjust the ladder lock so the buckle is in the correct position.. Buckle the two side straps(Fig3) to the crotch strap and adjust snugly(Fig4) so you can fit average size fingers between belt and your child.(Fig 5).
- Page 12 REMOVAL OF PASSENGERS Before removing children or cargo from the trailer, stop the bicycle, and lock the trailer parking brakes on both wheels. Then open the passenger compartment window, release the safety harness, and allow the passengers to exit the trailer. Take care the bicycle attached to the trailer does not fall over during loading or unloading.
-
Page 13: Trailer Maintenance
ATTACHING TRAILER TO BICYCLE Your trailer is designed to attach easily to just about any full-size bicycle. The hitch fitting must be atta- ched to the rear axle of the bike. Do not attach to any cycle where it cannot attach to the axle. It is re- commended that the bicycle(s) to which the trailer will be attached undergo a safety check by a qualified bicycle mechanic before attaching the trailer to it. - Page 14 of wear or needed adjustment. As needed Trailer can be clean with mild detergent and water. Do not remove the seat or cover for washing. Do not use harsh chemicals or cleaners, as they may damage the fabrics or the frame materials or surfaces. FITTING LIGHTSETS It is not recommended to use your trailer at night.
