- Page 1 HYDRAULIC CROCODILE JACK - 10 TONS PN: R3102 RHINOMOTIVE LTD - UK 71-75 Shelton Street, London, United Kingdom Scan QR Code www.rhinomotive.com...
- Page 2 • Use suitable wheel chocks to stop the vehicle from moving. • Make sure that there is no obstruction that will prevent a clean lift. •Make sure that all personnel are in a safe position before you lift the vehicle. www.rhinomotive.com...
- Page 3 • Make sure that the axle stands are in good condition and that they can hold the load. • Ensure that the axle stands cannot move when supporting the load. • DO NOT jerk the handle, make sure that it lowers slowly and in a controlled manner on to the axle stands www.rhinomotive.com...
- Page 4 5. Make sure the load is taken by the full saddle and that the point of lift on the load, is strong enough to support the load adequately. 6. Do not work under the raised vehicle until it is supported by suitable means e.g. axle stands, NEVER rely on the jack to support the vehicle by itself. www.rhinomotive.com...
- Page 5 Low oil level See “Changing the Oil” instructions Air in the hydraulic system See “BLEED THE HYDRAULIC SYSTEM” instructions Jack will not lower completely Return spring may be faulty Should be checked by a professional 11. PARTS LIST DRAWING www.rhinomotive.com...
- Page 6 Hand Wheel Rubber Pad Hand Sleeve Cove Board Washer Screw Screw Rise Arm Axe Check Ring Connecting Axle Spring Bolt M10*25 Handle Caster Stop Lever Washer (Diameter:16) Lock Washer Fix Shaft Nut M16 Mandril Check Ring Scan QR Code www.rhinomotive.com...
