Summary of Contents for DAYLIFF SUNFRIDGE 55
- Page 1 SUNFRIDGE Energy Efficient Solar Refrigerator SUNFRIDGE 55 SUNFRIDGE 128/ 233...
-
Page 3: Table Of Contents
SPECIFICATIONS 2. SYMBOLS & WARNINGS 3. EQUIPMENT CONTENTS 4. INSTALLATION 4.1 Connection 4.2 Direct Connection to the Battery 4.3 Connection to a Charge Controller 5. OPERATING INSTRUCTIONS 5.1 First Start Up 5.2 Operation Panel Layout & Instruction 5.3 Notes on Freezing & Storage 5.4 Features 5.5 Cleaning 6. -
Page 4: Specifications
• Low maintenance and easy to clean Featuring the latest cooling technology in combination with optimized electronic regulation and compressor speed control, Dayliff SUNFRIDGE provide optimal use of energy which results in lower input power requirements and the highest standards of... -
Page 5: Symbols & Warnings
TECHNICAL SPECIFICATIONS SUNFRIDGE SUNFRIDGE SUNFRIDGE MODEL Storage Volume (Litres) Operating Temperature Range -20 C to +10 C Ambient Temperature >0 C, <32 C Nominal Solar Power Requirement 125W 150W Energy Consumption per 24hrs 0.302kWhr 0.46kWhr 0.6kWhr Battery Size Requirement 100Ah 150Ah Charge Controller Requirement Power Supply... - Page 6 Always ensure that the correct voltage and current is applied to the fridge. The voltage and current ratings are indicated on the nameplate underneath the fridge. WARNING Ensure power supply is rated correctly. WARNING Do not carry corrosives or solvent material in the fridge. WARNING Do not obstruct vents as they supply necessary airow to...
- Page 7 The device is intended for cooling and freezing food and for preparation of ice products for small scale. The applicable commercial regulations must be observed when the device is WARNING used in a commercial environment. Do not store explosive substances or spray cans with inammable materials, such as propane, butane, pentane etc., in the fridge.
-
Page 8: Equipment Contents
3. EQUIPMENT CONTENTS Gasket Door Lock Bulb Hinge Divider DC Socket Latch Vents Operational Panel Door Lock Door LED Light LED Light Hinge Beam Shelf Latch DC Socket Vent Body Caster Operation Panel Fig 2: Parts of the Fridge 4. INSTALLATION Before installation;... -
Page 9: Connection
Ÿ The minimum clearance between the ventilation grill and the wall should be 20 cm. This clearance must always be maintained and the ventilation grill must not be covered. Ÿ Do not alter the outer cladding of the device. A minimum all-round clearance of 20 mm must be maintained to ensure adequate heat dissipation. - Page 10 PV Panel Charge Controller Fridge Battery Fig 3: Battery Connection 4.3 Connection to a charge Controller with Deep Discharge Protection If the deep discharge protection of the charge controller completely switches off the cabinet power, then the control unit also receives no power. When the device is switched on again automatically, the integrated power outage indicator will display you of the internal temperature reached.
-
Page 11: Operating Instructions
Ÿ Press once to adjust the temperature by ±1°C Ÿ Maximum cool setting is -19°C Ÿ For Sunfridge 128/233, use MAX/ECO mode switch to select quick freezing and power savings mode 5.2 Operation Panel Layout and Instruction SUNFRIDGE 55 Down SUNFRIDGE 128 Temperature Display Max/Eco Switch... - Page 12 Meaning Operation Method Press the button for 3 seconds Power on/off switch to switch on or switch off product Frozen Cabinet temp readout Readout Cold Cabinet temp readout Readout Voltage Readout Readout Press once to control temperature of first cabinet, and press once Setting for cabinet temp setting more to control the temperature of second cabinet.
-
Page 13: Notes On Freezing & Storage
5.3 Notes on Freezing and Storage Ÿ Store the same types of cooled / frozen products together. Ÿ The following products are suitable for freezing: meat, game, poultry, fresh fish, vegetables, fruit, dairy products, bread, cakes and pastries, convenience food. Ÿ... -
Page 14: Cleaning
Never use a mechanical device or any other articial aid for d e f r o s t i n g, o t h e r t h a n t h o s e r e c o m m e n d e d b y t h e manufacturer. - Page 15 Storage Ÿ When storing theSunfridge it is recommended that the lid is left slightly open. This will prevent mould from forming and will keep stale odors out of the fridge. It is recommended to clean the equipment before storage. Cleaner Sunfridge does not need to be cleaned before initial use though if desired, the below steps can be followed;...
-
Page 16: Trouble Shooting
7. TROUBLE SHOOTING SUNFRIDGE 55 Plug fridge firmly into socket or cigarette Loose contact between lighter. plug and unit socket Check whether unit is plugged into power C o o l i n g f u n c t i o n... - Page 17 SUNFRIDGE 128/223 LED display “Err 0” M a l f u n c t i o n o f Check that power supply conforms to unit not running temperature sensor product nameplate LED display “Err 1” Over voltage or under Check battery voltage and correct as unit not running necessary...
-
Page 18: Terms Of Warranty
I) General Liability • In lieu of any warranty, condition or liability implied by law, the liability of Dayliff (hereafter called the Distributor) in respect of any defect or failure of equipment supplied is limited to making good by replacement or... - Page 20 INS502A-12/22...
