Summary of Contents for SmartRoom SR-ZSWDPW-UART-01
- Page 1 SmartRoom Wired-Wireless Translator Quick Guide （Dry contact type serial port ) You can read software instruction to get more information.
- Page 3 Copyright © Nanjing IOT Sensor Technology Co.,Ltd. 2013 Publication Number：2013-0627.1 The manual is issued by Nanjing IOT Sensor Technology Co., Ltd. It is without warranty. We reserve the right to change and modify misprinted and incorrect information and improve programs or devices at any time without notice. Such modifications will be written in the new- edition of the manual.
- Page 4 Trademark SmartRoom, IOT Sensor, Wulian are all the registered trademarks of Nanjing IOT Sensor Technology Co., Ltd. Usage of these trademarks is strictly prohibited without the written authorization and permission from Nanjing IOT Sensor Technology Co., Ltd. Legal action will be taken against unauthorized use of these trademarks.
-
Page 5: Basic Function
Basic Function Support ZigBee/SmartRoom protocol Small size, save more space. New appearance design, closer to home life. Simple structure, easy to use. -
Page 6: Function Illustration
Function Illustration Wiring Terminal 485 Signal 232 Signal System Light Multi-function Key Power Supply DC12V Earth Line... -
Page 7: Installation Steps
Installation Steps 1. According to the chart, plug into a power supply; DC 12V Earth Line... - Page 8 Installation Steps 2. Press on the wiring terminal and connect the line to corresponding input point and public terminal; loosen the wiring terminal, then it can be installed successfully. cross link...
-
Page 9: Network Settings
Network Settings 1.Before settings, please make sure the wireless gateway (additional purchase) ZigBee network to work normally. At the same time, please confirm that this product is in the current state, and within the effective communication range in wireless gateway. Please note: for more details, please refer to the instructions of the wireless gateway. - Page 10 Network Setting 2. Click the multi-function button four times quickly and apply to join the ZigBee network. While searching for the network, the system light will flicker. After it joins ZigBee network successfully, the system indicator long brights and goes out after 2 seconds. Click 4 times quickly,the click interval time should be not less than1 second...
- Page 11 Network Setting 3. Long pressing the multi-function button for 10 seconds, restore to factory settings and exit the ZigBee network at the same time. Go out after flickering for 4 times Long press for 10 seconds...
-
Page 12: Directions For Use
Directions for use 1.It will transmit wired transmission signal to wireless output signal through the ZigBee protocol and provide for the use of other equipment, playing the role of a communication bridge. 2.It is more convenient to remotely control by wireless technology through all kinds of mobile intelligent terminal. -
Page 13: Product Specification
Product specification Communication mode IEEE802.15.4 Communication distance 100m (visual) Interface A serial port Configuration 232/485 Working temperature -10℃-+55℃ Power requirement 12V DC Weight Net weight Color white... -
Page 14: Order Information
Order information Order name Wired-wireless Translator Model SR-ZSWDPW-UART-01 Item No SRPN1448401... - Page 16 B11 Software Valley, NO.15, Fengji Avenue, Yuhuatai District, NanJing Service hotline ：400-928-9288 www.wulian.cc/english/...
