- Page 1 Fan Coil Thermostat FCT.2350.T User Manual Thermostats...
- Page 2 Warnings Before using the device, read the user manual the user to turn off the energy at the supply input of the carefully and follow the instructions. device. Responsibility for damages, losses and personal It is necessary to check the supply voltage range of the accidents caused by not following the warnings in the device and apply the appropriate supply voltage.
- Page 3 1. Fan Coil Thermostat 1.1. FCT.2350.T Series Thermostats 3.2” LCD Display Manual Fan Operation Heating/Cooling/Auto Modes Keylock 5pcs Relay Digital Outputs Can be integrated into building management systems via Modbus/RTU (Optional) Real Time Clock (Optional) ...
-
Page 4: Technical Dimensions
2. Technical Dimensions: 40mm 86mm Doc: 04-11-22, v1.0,r1 www.havkon.com... -
Page 5: Technicial Specifications
3. Technicial Specifications Supply AC230V ±%10 Electrical Data Power consumption Max 1VA Connection 1,5mm² Terminal Connektor Fan Relay Outputs 3pcs Digital Relay Output (Max 1A) Functions Heating/Cooling Relay 2pcs Digital Relay Output (Max 1A) Outputs Mounting Type Wall Mounting Physical Data Dimensions W86XH86xY40mm Weight... -
Page 6: Functional Features
4. Functional Features: Heating, Cooling and Auto Mode Manual Fan Mode 5 pcs Digital Relay Outputs (Fan Control&Valve Control) 3 Stage Fan Speed Control Real Time Clock Weekly Program Automatic Fan Speed Can be Integrated in to Building Management Systems Via Modbus/RTU ... - Page 7 5. Room Panel Use On/Off Button Manages the ON/OFF functions of the device. Mode/OK Button Selects the operating mode of the device (Automatic Heating/Automatic Fan/Manual). Up Button Increases Set Temperature Down Button Decreases Set Temperature Setting Fan Button Changes Fan Level How to Set Weekly Schedule? ...
-
Page 8: How To Set Date And Time
How to Set Date and Time? Press the M(MODE/OK) button through the panel for 2 seconds while the device is on. Point to parameter 1 with the UP button and press the M(MODE/OK) button. Select the DAY and MONTH setting with the UP and DOWN button and proceed using the M(MODE/OK) button. - Page 9 How to Change Set Temperature? When the device is on, the device is adjusted in manual or automatic heating or cooling mode with the UP or DOWN buttons. How to Turn Off Key Lock On? The key lock is unlocked by pressing the FAN button for 5 seconds when the device is on.
- Page 10 How to Adjust Screen Brightness? When the device is on, press the M(MODE/OK) button for 2 seconds. On the screen that opens, set parameter '2' with the UP or DOWN button and press the M(MODE/OK) button. You can adjust the brightness time between 0-10 values with the UP or DOWN buttons on ...
-
Page 11: Using The Service Menu
6. Using The Service Menu To enter the user service menu: While the device is off, press the UP and DOWN button for 2 seconds. Enter the user password on the screen that opens and press the M(MODE/OK) button. ... - Page 12 FCT.2350.T PARAMETERS LIST V1.0 Factory Par No Description Detail Settings You can callibrate the room temperature by Sensor Calibration pressing up and down buttons. You can sellect the right system for your fan coil system. System Sellection 0==> 2 Pipe Fan Coil System 1==>...
- Page 13 You Can Select Fan/Valve Opening and Fan/Valve Time Clossing Time Settings With This Feature You can select Temperature location and Window / Door Contact output with the up and down buttons. Door Contact Function 00- Panel Temp Selection 01- External Temp Selection 02- Panel Temp Selection+Window Contac You can activate the key card function by pressing up and down buttons.
- Page 14 7. Schematic Neutral 2 Pipe System Fan Coil Wiring Neutral 4 Pipe System Fan Coil Wiring Doc: 04-11-22, v1.0,r1 www.havkon.com...
