Summary of Contents for RetroTINK RGB2COMP
- Page 1 RGB2COMP COMP2RGB User Manual Revision 1.0 February 1 , 2020 Copyright RetroTINK LLC 2020 Page All Rights Reserved...
- Page 2 Introduction The RGB2COMP and COMP2RGB are simple, high-quality transcoders for converting RGB video signals via SCART to component video signals via RCA and vice versa. Copyright RetroTINK LLC 2020 Page All Rights Reserved...
- Page 3 3. microUSB power input. Connect to any microUSB power source capable of supplying 500 mA or more. Note: The RGB2COMP has an advanced power input filtering circuit and is tolerant of virtually any USB power source. The COMP2RGB operates at a higher voltage and has a more limited power input filter and may be more sensitive to poorly regulated and/or noisy supplies.
- Page 4 Note: The COMP2RGB exhibits a short (~100 ms) delay when switching between SDTV and HDTV resolutions to power cycle the conversion chip. Resolution switches within standard definition modes (e.g., 240p <-> 480i) are not affected. Copyright RetroTINK LLC 2020 Page All Rights Reserved...
- Page 5 240p, 288p, 480i, 576i, 480p, 576p, 720p, 1080i and 1080p Conversion Matrix Rec. 601 for SDTV/EDTV, Rec. 701 for HDTV, automatic detection Latency Effectively zero Power < 200 mA over microUSB, 500 mA PTC fuse for overcurrent protection Copyright RetroTINK LLC 2020 Page All Rights Reserved...
- Page 6 Disposal If your RetroTINK malfunctions, please contact the place of purchase via e-mail or through their website to arrange repair or replacement. All RetroTINK units come with one years warranty. Outside of warranty, resellers may also offer repair services at their discretion.
