- Page 1 TUB DOORS SHOWER DOORS TUB DOORS: SHOWER DOORS: LBTDA6062 LBSDA4876 LBSDA6076 Version 5.0...
- Page 3 MODELS: LBTDA6062 1 7/8" Min. Threshold Threshold Requirement (Size): 1 7/8" Requirement SAFETY IMPORTANT NOTE: Installation of shower or bathtub door requires to be installed only on smooth and flat surface of both walls and threshold base (shower base or bathtub).
- Page 4 MODELS: LBSDA4876 LBSDA6076 1 7/8" Min. Threshold Threshold Requirement (Size): 1 7/8" Requirement SAFETY IMPORTANT NOTE: Installation of shower or bathtub door requires to be installed only on smooth and flat surface of both walls and threshold base (shower base or bathtub).
- Page 5 Upper Guide Rail 1 pc Round Head Self-tapping screw M4X60 6 pc Wheel 4 pc Towel Bar 2 pc Wall Profile 2 pc Wool Tops 1 pc Rubber Bumper 4 pc Bottom Track 1 pc Glass Door 2 pcs Guide Block 1 pc Wall Anchor Round Head Self-tapping Screw M3.5X10...
-
Page 6: For Example
1. Measure the distance between the two finished walls. This distance is marked as W. See Figure 1 for details Figure 1 2. Your Upper Guide Rail (1) and Bottom Track (10) have been precut for your shower model opening width: 48” or 60”. If W-width of your wall-to-wall opening is equal to the size of your shower model, it is unnecessary to cut the upper guide rail and bottom track and you can continue to Step 3. - Page 7 back edge ∅8 back edge Figure 4 4. Wall Profile and Rubber Bumper Installation. 4.1 Place the Wall Profile (3) vertically against the wall and insert it into the Bottom Track (10). Using a level to level the Wall Profile upright, mark 3 pre-drilled holes on the wall, using a pencil or marker, to prepare for drilling.
- Page 8 6. Towel Bar and Wheel Installation. 6.1 Install the Towel Bars (8) onto the Glass Doors(5). IMPORTANT: Make sure CLEAR RUBBER GASKET are in between the glass door and towel bar; between the cap and glass door. Mark sure CLEAR RUBBER SLEEVE are inside the glass hole.
- Page 9 7.Guide Block and Glass Door Installation 7.1 Hang the Glass doors installed with Wheels and Towel Bars to the Upper Guide Rail (1). Note: Hang the wheels to the small slot inside the Upper Guide Rail per image b. 7.2 Insert the Guide Block (11) to the Bottom Track (10), make sure that the two Glass Doors are inside the two slots of the Guide Block.
-
Page 10: Maintenance And Care
TUB DOORS • SHOWER DOORS ULTRA-A MAINTENANCE, USE, AND CARE Maintenance & Care IMPORTANT! DO NOT USE: Abrasive cleaners such as: acid, ammonia, bleach, and simmilar solutions. Use of such solutions may cause corrosion, finish peeling, and/or dull the surface. DO NOT USE: Abrasive sponges or cloth.
