Summary of Contents for HENNING liftpc HT1
- Page 1 Hand-Held Terminal HT1 Operating Instructions...
- Page 2 © Copyright 2011 by Henning GmbH, Loher Str. 26a – 30a, 58332 Schwelm Warranty This description has been drawn up by Henning GmbH to the best of their knowledge. All technical statements have been carefully established and checked. They correspond to the state of the art. Changes and errors excepted.
-
Page 3: Table Of Contents
Menu item Date / Time ................. 12 Menu item Language ................... 13 EVALUATION ....................13 TRANSFER OF MEASUREMENTS TO THE mobile Diagnose SOFTWARE ....................14 CHARGING OF THE HAND-HELD TERMINAL ........... 14 ERROR MESSAGES ..................15 TECHNICAL DATA ..................16 Seite 3 Henning GmbH... -
Page 4: Scope Of Delivery
Capacity 256 MB for approx. 250 min measurements Capacity 512 MB for approx. 500 min measurements (Illustration similar) Car charging adapter Stabilized switch mode power pack Output 12 V for max. 2 A With cigar lighter connector (Illustration similar) Seite 4 Henning GmbH... -
Page 5: Control Elements
QS2 sensor Resetting key Sound-input Jack receptacle for the connection of the sound level meter Display Enter key Arrow key down Arrow key up Control LED's for the charging operation Charging socket CompactFlash Card slide-in Seite 5 Henning GmbH... -
Page 6: Short Description Of Measurement
CompactFlash Card. Step 8: The measurement will be terminated by pressing the Enter key again. Seite 6 Henning GmbH... -
Page 7: General Operating Instructions
After the switching-on operation two messages appear on the display one after the other: German English Software version Opening text Date / Time Residual accumu- lator capacity Status text Free memory on the CF Card in minutes Seite 7 Henning GmbH... -
Page 8: Main Menu
Handterminal 6 MAIN MENU German English Menu item Measurement Menu item Status Menu item Date / Time Menu item Language Seite 8 Henning GmbH... -
Page 9: Menu Item Measurement
Indication of velocity, refer to chapter Evaluation After pressing the Enter key the measurement is finished. After the measurement the ID, under which this measurement is stored on the CompactFlash Card, is shown once more Seite 9 Henning GmbH... -
Page 10: Submenu Id Change
(arrow up) by One or decreased (arrow down) by One. German English Increases or decreases the current place (flashing) by One. Increases or decreases the current place (flashing) by One. Increases or decreases the current place (flashing) by One. Return to menu item Measurement Seite 10 Henning GmbH... -
Page 11: Menu Item Status
Free storage space on the CompactFlash Card in minutes, in which you can still carry out measurements until the memory area of the CompactFlash Card is fully used. Current accumulator voltage in volt Current voltage of the sound input Seite 11 Henning GmbH... -
Page 12: Menu Item Date / Time
(flashing) by One. Increases or decreases the current place (flashing) by One. Increases or decreases the current place (flashing) by One. Increases or decreases the current place (flashing) by One. Return to main menu Seite 12 Henning GmbH... -
Page 13: Menu Item Language
Any deviations between the online evaluation and the later evaluation by the software result from the limited computing capacity of the micro- mobile Diagnose controller of the Hand-Held Terminal. The Hand-Held Terminal cannot replace a velocity measuring device. Seite 13 Henning GmbH... -
Page 14: Transfer Of Measurements To The Software
Rapid charging operation is initialized, (flashing) accumulator is being prepared Rapid charging operation running Rapid charging operation finished During the charging operation the Hand-Held Terminal has to be switched off and the senor QS2 has to be disconnected! Seite 14 Henning GmbH... -
Page 15: Error Messages
3. LiftPC QS2 sensor not connected Possible causes 1. No QS2 sensor is connected to the Hand-Held Terminal 2. At least one of the connectors is not locked in the corresponding socket 3. The connection cable is defective Seite 15 Henning GmbH... -
Page 16: Technical Data
2 h, if accumulator is completely discharged QS2 socket: RJ12 data socket Sound socket: Jack receptacle 3.5 mm Charging socket: DC-Power Jack with 2.5 mm pin CF slide-in: For use with CompactFlash media type I Seite 16 Henning GmbH...
