FSC FMC/MCDU Series
Installation / Configuration Manual
Rev. 2.2 - 10/2020
FULL COMPATIBILITY WITH
SKU
PRODUCT
208101
A320 MCDU Multi-Function Control Display Unit
384954
737NG FMC Flight Management Computer
208103
B747-400 FMC Flight Management Computer
ENGLISH
ME155912
www.fsc.it
Official website for information and support:
Advertisement
Table of Contents
Summary of Contents for FSC FMC Series
- Page 1 FSC FMC/MCDU Series Installation / Configuration Manual Rev. 2.2 - 10/2020 FULL COMPATIBILITY WITH PRODUCT 208101 A320 MCDU Multi-Function Control Display Unit 384954 737NG FMC Flight Management Computer 208103 B747-400 FMC Flight Management Computer ENGLISH ME155912 www.fsc.it Official website for information and support:...
-
Page 2: Table Of Contents
5. CONFIGURING CLIENT SOFTWARE: PMDG 737NGX* ......8 6. CONFIGURING CLIENT SOFTWARE: X-Plane 11 with ZIBO mod ....9 DISCLAIMER All product names, logos, and brands are property of their respective owners. © FSC is a Research & Development Division of Pro... -
Page 3: Introduction And Specifications
Installation / Configuration Manual 1. INTRODUCTION AND SPECIFICATIONS Thanks for having chosen FSC FMC. The purpose of this guide is to illustrate how to connect and configure the FMC, including hardware and the most common FMC client software. To know how to actually operate an FMC throughout the flight, please refer to the documentation shipped with the client software you are using. -
Page 4: Configuring The Fmc
FSC FMC/MCDU Series 2. CONFIGURING THE FMC This equipment is interfaced via LAN only and therefore it doesn’t require any USB or VGA connection. Before having the FMC unit recognized by your LAN, you will need to set manually an IP address, accordingly to the base address of your network (the IP address assigned to the FMC must be unique and not used by any other computer or device of your network). - Page 5 You can change it for specific purposes. Press RSK-6 to select EXIT, thus confirming and saving the configuration. If you operate multiple FMC units, repeat the above steps for the additional units, making sure to use an unique IP and MAC address for each unit. www.fsc.it...
-
Page 6: Configuring Client Software: Project Magenta
Before the FMC can be used by a client software, usually you will have to configure such software, enabling FSC FMC hardware support and specifying IP address & port accordingly to FMC setup previously explained. Please consult the documentation shipped with the client software to know how to configure it properly. -
Page 7: Configuring Client Software: Prosim-Ar
Before the FMC can be used by a client software, usually you will have to configure such software, enabling FSC FMC hardware support and specifying IP address & port accordingly to FMC setup previously explained. Please consult the documentation shipped with the client software to know how to configure it properly. -
Page 8: Configuring Client Software: Pmdg 737Ngx
- If using two CDUs, run fsc-cdu-right application to control the right-side (first officer) CDU* If you own two CDUs and would like to use both, just run fsc-cdu- left and fsc-cdu-right applications, making sure that each CDU has its own unique IP address and Port, as explained in the hardware setup chapter. -
Page 9: Configuring Client Software: X-Plane 11 With Zibo Mod
You have 2 units Start X-plane and select B737-800X aircraft Select X-Plane menu Plugins -> FSC MCDU Driver for Zibo – CP (FO) Unit -> Status The following window will be displayed: This window shows the status of the MCDU unit. Please make sure that the IP address and Port is correctly configured (to change it, please follow the instructions provided in the status window). - Page 10 © FSC is a Research & Development Division of Professional Show SpA HEADQUARTERS MILAN Branch via Praimbole, 15 bis via Santa Maria, 83/85 35010 Limena (PD) ITALY 20093 Cologno Monzese (MI) Ph. +39 049 8657111 Ph. +39 0225397214...
