BIO CART 13 HEPA-UVC PREMIUM

USER GUIDE

Table of Contents

Need help?

Do you have a question about the Air-Care Bio Cart 13 Premium and is the answer not in the manual?

Questions and answers

Summary of Contents for DPL Air-Care Bio Cart 13 Premium

Page 1 BIO CART 13 HEPA-UVC PREMIUM USER GUIDE...
Page 2 BIO CART 13 HEPA-UVC PREMIUM Division of D.P.L. Enterprises Inc. 3868 East Post Road, Las Vegas, Nevada 89120, (702) 454-5515, FAX (702) 454-5225 Website: www.air-care.com; E-mail: cs@Air-Care.com...
Page 3: Table Of Contents
PAGE 3 TABLE OF CONTENTS CHAPTER PAGE Introduction to Portable Containment Units Unpacking and Inspecting the Air-Care Bio Cart 13 Video Camera/Monitor Testing the Bio Cart 13 Operating the Bio Cart 13 Safety Maintenance Compliance Specifications Warranty Rev. January 2023 - Part Number FG0273...
Page 4: Introduction To Portable Containment Units
PAGE 4 INTRODUCTION During construction, maintenance or when inspections are performed in an area that may contain dust, dirt or biological contaminates, there is always the possibility for those contaminates to be released into the room and picked up by the air currents and spread to additional areas. When major remodeling or repairs are performed it has been standard practice to install a long term, but temporary containment area with spring poles and plastic film using HEPA air scrubbers to filter out the contaminates and exhaust clean air out of the contained area and provide a NEGATIVE PRESSURE in the...
Page 5 PAGE 5 UNPACKING DO NOT ACCEPT A PALLET THAT SHOWS VISIBLE DAMAGE. • Report damage to driver, Delivery Company • Take photos of the damage • Refuse the shipment • Contact Air-Care at 800.322.9919 or cs@air-care.com. Remove packing from exterior of Bio Cart HEPA-UVC 13 and pallet. Do not dispose of packing until you have completed your inspection of the Bio Cart HEPA-UVC 13 inside and out.
Page 6: Video Camera/Monitor
PAGE 6 VIDEO CAMERA/MONITOR A front facing camera (Image 1) is mounted on the exterior, so the operator can see what is directly in the path of the Bio Cart HEPA-UVC 13 as it navigated down hallways. The HD image is displayed on the 10”...
Page 7 PAGE 7 TESTING The Bio Cart HEPA-UVC 13 has mechanical, electronic, camera and display functions to test. If any of these tests fail, contact Air-Care Immediately. 800-322-9919 or cs@air-care.com. The Bio Cart HEPA- UVC 13 may require the ladder to be removed to perform some of the tests. Turn off all switches in the Bio Cart HEPA-UVC 13 before connecting to AC power.
Page 8 PAGE 8 TESTING 8. Step inside the Bio Cart HEPA-UVC 13 to test the electrical system. If the AC red LED (Image 7) does not light up when the power cord is in a live, properly grounded outlet, check the 2 door locks on the (Image 7) back exterior door (Image 8).
Page 9 PAGE 9 TESTING 11. The last control to be tested on the panel is the power lift . The Bio Cart HEPA-UVC 13 has a maximum height of over 13 feet, so you may not be able to fully raise it at this time. Press the UP (TOP) of the Rocker switch (Image 11) on the control panel.
Page 10 PAGE 10 TESTING 13. Next, remove the Pre-Filter (Image 14) in the Air scrubber section and note the location of the Circuit Breaker Button (Image 15) on the side of the Retractable Power Cord on the Right side of the Air Scrubber.
Page 11 PAGE 11 OPERATION The Bio Cart HEPA-UVC 13 is the simplest portable containment cart to operate, and offers more features than other carts. The Bio Cart HEPA-UVC 13 should first be moved to the area to be contained. Position under a ceiling tile or light fixture so that all 4 sides of the Bio Cart HEPA- UVC 13 are outside that area.
Page 12 PAGE 12 OPERATION Ladder Set-Up Your Bio Cart comes with a telescoping extension ladder. During shipping the ladder is secured to the bottom of the unit (Image 21). To use the ladder, unstrap the ladder and slowly extend the ladder to your desired length (the ladder can fully extend up to 15 feet).
Page 13: Unpacking And Inspecting The Air-Care Bio Cart
PAGE 13 OPERATION Climb the ladder and move the ceiling tile out of the way and store it to the side of the opening. For re-lamping light fixtures, you will not normally need to remove any ceiling tiles. If power tools are required, plug them in to the power outlet located on the control panel. KEEP THE AIR SCRUBBER RUNNING DURING THE ENTIRE PROJECT AND EVEN WHEN YOU EXIT THE Bio CART.
Page 14: Safety
PAGE 14 SAFETY INFORMATION Air-Care Bio Carts are designed to minimize hazards from dust and debris released from the Ceiling area when work is performed there. The Bio Cart HEPA-UVC 13 has electrical power and components around which common sense and normal safety procedures must be followed to minimize exposure to any possible dangers.
Page 15: Maintenance
PAGE 15 MAINTENANCE The single most important maintenance activity for the Bio Cart 13 is keeping them clean. Since the Bio Cart will be used in a variety of environments, the degree of cleaning will vary with each environment. The cleaning protocol for each area that the Bio Cart will be used must be understood prior to transporting it to those areas.
Page 16 PAGE 16 MAINTENANCE ballast. And dispose of the bulb in the proper manner for other Fluorescent bulbs with mercury. It is best to replace both bulbs at the same time. Do NOT touch the glass on the new bulb with your hands, oil from your fingers will cause local heating and early failure of the bulb.
Page 17: Compliance
PAGE 17 COMPLIANCE Bio Cart HEPA-UVC 13 complies with all relevant health and safety guidelines for portable, negative air, dust containment carts used in healthcare facilities such as ICRA 1 through 4, and others listed below. Because the occupants of healthcare facilities are often more susceptible contaminates introduced into the air by routine maintenance work to and above the ceilings, the Center for Disease Control (CDC) has created strict guidelines for how this work must be performed while minimizing the risks to sensitive individuals in its guidelines for Infection Control in Healthcare Facilities (ICRA).
Page 18: Specifications
PAGE 18 SPECIFICATIONS SPECIFICATION DESCRIPTION 150 Watt halogen work light. 5 LED portable head band light with magnetic Accessories holder and batteries. 880 CFM@300 watt • 62 Db at maxspeed with variable speed control capable Air Scrubber Fan of reachlng up to 6 air changes per minute. Fire retardant black and yellow vinyl that Is 3 Inches high when collapsed and Bellows 90 Inches extended.
Page 19: Warranty
PAGE 19 LIMITED WARRANTY Bio Cart Premium HEPA 13 Air-Care warrants this product to be free from defects in materials and workmanship to the original purchaser for a period of Five (5) years from the date of purchase. Components listed below are excluded from this Five year period and are covered for periods described below: PART COVERAGE...
