Product Overview; Front & Back View - BALCO PrintMaker Instruction Manual

Product Overview

2.1 Front & Back View
1
2
3
4
5
10
11
12
1.
Bowden tube
2.
Bowden quick coupler
3.
Extruder base
4.
Cooling Fan
5.
Removable nozzle
6.
Extruder cables
7. Clip
8.
Led light
9.
Turbo Fan Baffle
8
6
7
8
9
13
15
14
10. Front door
11. Y-Axis sliding slot
12. Print base
13. Removable print bed
14. Touch-screen
15. USB stick input
16. Power switch
17. Power input
18. Spool holder
21
20
19
18
17
16
25
26
19. Filament cover
20. Filament cover handle
21. Motor
22. Filament intake
23. Filament feeding wheel
24. Top cover
25. Air outlet
26. Ethernet input
23
22
24
