COMPLEX RADIO CONTROL SYSTEM
4

Receiver setup

There are two receiver setup modes. The first is receiver setup via
the JETIBOX, JETIBOX profi or JETIBOX emulation in the DC/DS
transmitters, the second one is direct setup of the receiver with a
DC/DS transmitter (device explorer).

4.1 Receiver set-up via the DC/DS transmitter

A l l s e t t i n g s c a n b e m a d e i n t h e t r a n s m i t t e r m e n u
"Menu/Model/Device explorer/REX".
4.1.1 Main Setting
Output Period - signal period setting
for servos. At lower values, the servos
have a faster response and more
consumption. For analog servos, the
recommended period is 20ms, for
digital "Auto".
Number of channels - setting the
number of channels for PPM output.
27
